2013 GALLARDO LP 550-2 COUPE - JAPAN

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
7H0906271A-ALT	Fuel Pump Module Assembly Fuel Pump Module Assembly 7H0906271A Fuel Vapor Leak Detection Pump The Factory is no longer providing the original item. This is a compatible replacement	Avail to order Our Price: $300.00

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $352.09
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 121.06.00 - WATER COOLING SYSTEM

2013 Lamborghini GALLARDO LP 550-2 COUPE JAPAN WATER COOLING SYSTEM (121.06.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L121057T	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $20.40
2	N90687101	SPRING CLAMP CLAMP	1 req	Avail to order Our Price: $8.49
3	06B145917	SPRING CLAMP CLAMP	1 req	Current Stock: 4 Our Price: $5.66
4	N10196103	HEXALOBULAR SOCKET SCREW M6X18	2 req	Avail to order Our Price: $2.00
5	07L121133M	ADAPTER CONNECTOR	1 req	Avail to order Our Price: $66.85
6	N90544501	O-RING O-RING 27X3	1 req	Current Stock: 4 Our Price: $4.18
7	07L121030C	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $134.74
8	N90926401	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $4.18
9	07L121131K	ADAPTER CONNECTOR	1 req	Avail to order Our Price: $95.28
10	07C121077H	RETAINING PART BRACKET	1 req	Avail to order Our Price: $89.78
11	N10156206	SCREW SCREW M6X30	1 req	Current Stock: 130 Our Price: $2.00
12	07L121030B	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $153.35
13	07L103121R	GASKET GASKET	1 req	Avail to order Our Price: $17.87
15	N10700201	HEXALOBULAR SOCKET SCREW M6X22	3 req	Current Stock: 17 Our Price: $3.28
17		WATER TEMPERATURE SENSOR (SEE TABLE 1150100)	0 req
18	07L121133J	ADAPTER CONNECTOR	1 req	Avail to order Our Price: $136.97
19	N10124306	HEXALOBULAR SOCKET SCREW M6X20	2 req	Current Stock: 1 Our Price: $2.00
20	07L121237B	CONNECTING PIECE CONNECTOR	1 req	Avail to order Our Price: $58.29
21	07L115009AH	PUMP (FROM VIN DLA12117)	1 req
22	079121115AL	THERMOSTAT HOUSING WATER THERMOSTAT BODY	1 req	Avail to order Our Price: $662.50
23	N10700201	HEXALOBULAR SOCKET SCREW M6X22	13 req	Current Stock: 17 Our Price: $3.28
24	N10451408	HEXALOBULAR SOCKET SCREW M6X16	1 req	Avail to order Our Price: $2.00
25	N91008501	O-RING O-RING 35X3	1 req	Avail to order Our Price: $5.52
26	420121082A	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $76.68
27	N90926501	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $11.02
28	420819370A	HEATING HOSE PIPE	1 req	Avail to order Our Price: $52.26
29	N90687101	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $8.49
30	420121101D	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $105.70
31	N90926501	SPRING CLAMP CLAMP	2 req	Avail to order Our Price: $11.02
32	400121481A	COOLANT HOSE PIPE	1 req	Avail to order Our Price: $1,025.56
33	N91096701	HEXALOBULAR SOCKET SCREW M6X16	3 req	Current Stock: 8 Our Price: $2.00
34	400819371A	HEATING HOSE PIPE	1 req	Avail to order Our Price: $90.67
35	N90686901	CLAMP CLAMP	2 req	Avail to order Our Price: $2.00
36	WHT003874	SCREW PLUG SCREW M6X25	5 req	Avail to order Our Price: $5.96
37	WHT003732	O-RING O-RING 24X3,5	1 req	Avail to order Our Price: $28.59
38	WHT003731	O-RING O-RING 27X3,5	1 req	Avail to order Our Price: $28.59
40	07L115446A	MOULDED SEAL GASKET 26X26X3,5	1 req	Avail to order Our Price: $32.76
41	07L103081	OIL STRAINER FILTER	8 req	Avail to order Our Price: $29.11
42		ALTERNATOR (SEE TABLE 903.10.00)	0 req
43		PIPE (SEE TABLE 121.07.00)	0 req
44	07L121127B	PIPE UNION CONNECTOR	1 req	Avail to order Our Price: $314.88
45	079121119C	SEAL RING GASKET	1 req	Avail to order Our Price: $18.09
46	400121463A	PIPE HOLDER BRACKET	1 req	Avail to order Our Price: $35.73
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
