Lamborghini Aventador LP700 Parts

0 items in your cart
Your Shopping Cart
  • Your cart is empty
Subtotal: $0.00
Shipping: $0.00
Total: $0.00

Maintenance Parts:

Belts

PN Item Diagram
07L903137T RIBBED V-BELT
RIBBED V-BELT
view diagram Current Stock: 3
Our Price: $65.12
RIBBED V-BELT

Brakes

PN Item Diagram
420698451D E-BRAKE PAD SET GALLARDO LP560
SET BRAKE LININGS
view diagram Current Stock: 1
Our Price: $232.34
E-BRAKE PAD SET GALLARDO LP560
420698451B REAR PAD SET GALLARDO LP560
SET BRAKE
view diagram Current Stock: 12
Our Price: $464.68
REAR PAD SET GALLARDO LP560
400698151E SET BRAKE LININGS
SET BRAKE LININGS
view diagram Avail to order
Our Price: $891.36
SET BRAKE LININGS

Common repairs and upgrades

PN Item Diagram
4T0898201 DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan
PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR
Current Stock: 2
Our Price: $192.37
DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan

Drivetrain

PN Item Diagram
07L105269L CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL
CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL
view diagram Avail to order
Our Price: $3,458.33
07L105269K Balanced Clutch Assembly Egear 560
Balanced Clutch Assembly Egear 560
view diagram Current Stock: 7
Our Price: $3,458.33
Balanced Clutch Assembly Egear 560
086141671L THROW OUT BEARING - EGEAR
CONCENTRIC SLAVE CYLINDER *IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3*
view diagram Current Stock: 2
Our Price: $846.33
THROW OUT BEARING - EGEAR
079198405E Oil Filter Gallardo/Huracan LP Series
Oil Filter Gallardo LP Series
view diagram Current Stock: 18
Our Price: $67.74
Oil Filter Gallardo/Huracan LP Series

Fuel-Air

PN Item Diagram
4D0906321C FUEL FILTER
FILTER
view diagram Current Stock: 3
Our Price: $30.45
FUEL FILTER
4F0201511E Fuel Filter - Gallardo LP 560-4
FUEL FILTER - Gallardo LP 560-4
view diagram Current Stock: 4
Our Price: $56.08
Fuel Filter - Gallardo LP 560-4
4F0898438C CABIN FILTER ELEMENT SOLD AS PAIR
FILTER ELEMENT
view diagram Current Stock: 4
Our Price: $73.57
CABIN FILTER ELEMENT SOLD AS PAIR
1J0907543A TEMPERATURE SENSOR
TEMPERATURE SENSOR
view diagram Current Stock: 1
Our Price: $33.29
TEMPERATURE SENSOR
420133844D Air filter Gallardo LP 560-4
FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ
Current Stock: 1
Our Price: $93.96
Air filter Gallardo LP 560-4

Fuses-Bulbs-Relays

PN Item Diagram
N10525502 FUSE STRIP
FUSE STRIP
view diagram Avail to order
Our Price: $4.16
FUSE STRIP
N01713118 FUSE
Please Check your Part Manual for a Description
view diagram Current Stock: 19
Our Price: $2.00
FUSE
N10566103 DISCHARGE LAMP
DISCHARGE LAMP
view diagram Avail to order
Our Price: $247.64
DISCHARGE LAMP
400941107 LIGHT
LIGHT
view diagram Avail to order
Our Price: $17.19
LIGHT
400945119D FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description)
SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)
Current Stock: 3
Our Price: $189.86
FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description)
400945120D FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description)
SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)
Current Stock: 3
Our Price: $189.86
FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description)

Ignition

PN Item Diagram
7P0915105 BATTERY
BATTERY
view diagram Avail to order
Our Price: $433.95
101905631G Spark Plug - Gallardo/Huracan LP Series
Spark Plug Champion
view diagram Current Stock: 48
Our Price: $27.24
Spark Plug - Gallardo/Huracan LP Series
07K905715F PENCIL COIL
PENCIL COIL
view diagram Avail to order
Our Price: $65.12
PENCIL COIL

Misc

PN Item Diagram
401955425C WIPER BLADE (GALLARDO / MURCIELAGO)
WIPER BLADE
view diagram Avail to order
Our Price: $144.26
WIPER BLADE (GALLARDO / MURCIELAGO)
900000382 BATTERY CHARGER USA BC
BATTERY CHARGER USA BC
Current Stock: 1
Our Price: $153.78
BATTERY CHARGER USA BC
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 6
Our Price: $153.78
BATTERY CHARGER ROW BC - EURO

Sensors

PN Item Diagram
07L905163A SEE PN 07L905163C
PHASE SENSOR
Avail to order
Our Price: $27.13
SEE PN 07L905163C
4F0907275D See PN 7PP907275F
WHEEL ELECTRONICS
Avail to order
Our Price: $145.50
059919523A TEMPERATURE SENDER
TEMPERATURE SENDER
view diagram Current Stock: 17
Our Price: $49.24
TEMPERATURE SENDER
086141297 CLUTCH SENSOR
CLUTCH SENSOR
view diagram Current Stock: 4
Our Price: $247.64
CLUTCH SENSOR
086927321 Crank/Flywheel/Timing Sensor
ELECTROMAGNETIC PROBE
view diagram Current Stock: 2
Our Price: $106.31
Crank/Flywheel/Timing Sensor
1K2945511 SWITCH,BRAKE PEDAL
SWITCH,BRAKE PEDAL
view diagram Avail to order
Our Price: $19.67
SWITCH,BRAKE PEDAL
4E0927804 ABS SENSOR RIGHT
ABS SENSOR RIGHT
Avail to order
Our Price: $33.49
ABS SENSOR RIGHT
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 5
Our Price: $33.49
ABS SENSOR LEFT
Open All

Select Group and TAV

TAV: 837.11.00 - DOORS

2013 Lamborghini GALLARDO BLANCPAIN - STS CANADA DOORS (837.11.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 WHT000767 TAPP.SCREW,CSK.
SCREW
4 req Current Stock: 14
Our Price: $2.00
TAPP.SCREW,CSK.
2 400035243 BRACKET
TWEETER SUPPORT BRACKET
2 req Avail to order
Our Price: $8.56
BRACKET
3 400831707 DOOR SEAL INNER
LEFT DOOR WEATHERSTRIP, INNER
1 req Current Stock: 1
Our Price: $205.46
DOOR SEAL INNER
3 400831708 DOOR SEAL INNER
RIGHT DOOR WEATHERSTRIP, INNER
1 req Current Stock: 1
Our Price: $205.46
DOOR SEAL INNER
4 400837967C RUBBING STRIP
DOOR CRASH PAD
1 req Avail to order
Our Price: $52.22
RUBBING STRIP
4 400837968C RUBBING STRIP
DOOR CRASH PAD
1 req Avail to order
Our Price: $52.22
RUBBING STRIP
5 4D0867299A clip
FASTENER
6 req Current Stock: 6
Our Price: $2.00
clip
6 400962107A ROCKER SWITCH,
DOOR LOCK/UNLOCK SWITCH (WITH SERIGRAPHY)
2 req Current Stock: 1
Our Price: $50.68
ROCKER SWITCH,
6 400962107B ROCKER SWITCH,
DOOR LOCK/UNLOCK SWITCH (WITHOUT SERIGRAPHY)
2 req Current Stock: 4
Our Price: $28.01
ROCKER SWITCH,
7 DOOR CLEARANCE LIGHT (VALID UP TO MODEL YEAR 09) 0 req
8 DOOR COURTESY LIGHT (VALID UP TO MODEL YEAR 09) 0 req
9 8N0919238 WARNING LIGHT
ANTITHEFT LED
1 req Current Stock: 1
Our Price: $33.72
WARNING LIGHT
10 8Z0919242 BUSHING
ANTITHEFT LED BUSHING
2 req Current Stock: 5
Our Price: $2.00
BUSHING
11 N10544301 CYL.SCREW
SCREW M 5X25
2 req Current Stock: 17
Our Price: $2.00
CYL.SCREW
12 N01154012 WASHER
WASHER
6 req Current Stock: 14
Our Price: $2.00
WASHER
13 WHT003111 HEXAGON SOCKET
SCREW M 5X16
2 req Current Stock: 23
Our Price: $2.00
HEXAGON SOCKET
14 WHT000778 SPRING LOCK WASHER
WASHER
2 req Current Stock: 2
Our Price: $2.00
SPRING LOCK WASHER
15 N10621601 HEXALOBULAR SOCKET
SCREW M 4X12
2 req Current Stock: 5
Our Price: $2.00
HEXALOBULAR SOCKET
16 PLUG (VALID FOR A MARKET ENGLAND/AUSTRALIA) 0 req
17 400837115A INTERIOR DOOR LH
LH HANDLE KIT (CARBON INTERIOR)
1 req Avail to order
Our Price: $1,331.40
INTERIOR DOOR LH
17 400837115B INTERIOR DOOR
LH HANDLE KIT (DECORLACK PAINTED)
1 req Avail to order
Our Price: $628.80
17 400837116A INTERIOR DOOR LH
RH HANDLE KIT (CARBON INTERIOR)
1 req Avail to order
Our Price: $1,331.40
17 400837116B INTERIOR DOOR
RH HANDLE KIT (DECORLACK PAINTED)
1 req Current Stock: 1
Our Price: $628.80
INTERIOR DOOR
18 JOURNAL (CANNOT BE SOLD SEPARATELY - SEE REF. 29) 0 req
19 SPRING (CANNOT BE SOLD SEPARATELY - SEE REF. 17) 0 req
20 403867105E DOOR TRIM PANEL
LH DOOR PANEL ASSEMBLY (WITH PREDISPOSITION FOR LOUDSPEAKER)
1 req Avail to order
Our Price: $11,740.77
20 403867106E DOOR TRIM PANEL
RH DOOR PANEL ASSEMBLY (WITH PREDISPOSITION FOR LOUDSPEAKER)
1 req Avail to order
Our Price: $11,740.77
21 403837221L40 OPERATING HANDLE LACCIO PORTA SX
LH HANDLE (FOR STS MODEL - RED)
1 req Avail to order
Our Price: $675.90
21 403837221TJ6 OPERATING HANDLE LACCIO PORTA SX
LH HANDLE (STANDARD)
1 req Avail to order
Our Price: $675.90
21 403837222L40 OPERATING HANDLE LACCIO PORTA DX
RH HANDLE (FOR STS MODEL - RED)
1 req Avail to order
Our Price: $675.90
21 403837222TJ6 OPERATING HANDLE LACCIO PORTA DX
RH HANDLE (STANDARD)
1 req Avail to order
Our Price: $675.90
22 403837895 BRACKET VIN REQUIRED
LH BRACKET
1 req Avail to order
Our Price: $636.57
22 403837896 BRACKET
RH BRACKET
1 req Avail to order
Our Price: $636.57
23 N90807405 HEXALOBULAR SOCKET FLANGE BOLT
SCREW M5X18
4 req Current Stock: 19
Our Price: $2.00
HEXALOBULAR SOCKET FLANGE BOLT
24 N10017304 HEXAGON FLANGE NUT
NUT M5
4 req Current Stock: 16
Our Price: $2.00
HEXAGON FLANGE NUT
25 8E0867443 CAP
PLUG
2 req Avail to order
Our Price: $5.76
26 4E0947415 ENTRANCE LIGHT
ROOF LAMP (ADDITIONAL LIGHTS)
2 req Avail to order
Our Price: $9.73
ENTRANCE LIGHT
27 8P0947412 DOOR WARNING LIGHT
REAR LIGHT REFLECTOR
2 req Avail to order
Our Price: $5.46
28 6Y0947411 DOOR WARNING LIGHT
DOOR CLEARANCE LIGHT (ADDITIONAL LIGHTS)
2 req Current Stock: 5
Our Price: $18.57
DOOR WARNING LIGHT

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
