Maintenance Parts:

Common repairs and upgrades

PN Item Diagram
4T0898201 DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan
PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR
Current Stock: 2
Our Price: $192.37
DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan

Drivetrain

PN Item Diagram
079198405E Oil Filter Gallardo/Huracan LP Series
Oil Filter Gallardo LP Series
Current Stock: 18
Our Price: $67.74
Oil Filter Gallardo/Huracan LP Series

Fuel-Air

PN Item Diagram
420133844D Air filter Gallardo LP 560-4
FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ
Current Stock: 1
Our Price: $93.96
Air filter Gallardo LP 560-4
4F0898438C CABIN FILTER ELEMENT SOLD AS PAIR
FILTER ELEMENT
Current Stock: 4
Our Price: $73.57
CABIN FILTER ELEMENT SOLD AS PAIR
0R1400314 GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit
Avail to order
Our Price: $413.83
GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
420133844DZ Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
FILTER ELEMENT
Current Stock: 2
Our Price: $280.95
Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
4D0906321C FUEL FILTER
FILTER
Current Stock: 3
Our Price: $30.45
FUEL FILTER
4F0201511E Fuel Filter - Gallardo LP 560-4
FUEL FILTER - Gallardo LP 560-4
Current Stock: 4
Our Price: $56.08
Fuel Filter - Gallardo LP 560-4

Misc

PN Item Diagram
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 6
Our Price: $153.78
BATTERY CHARGER ROW BC - EURO
900000382 BATTERY CHARGER USA BC
BATTERY CHARGER USA BC
Current Stock: 1
Our Price: $153.78
BATTERY CHARGER USA BC
0R1400308 Tool Kit Gallardo 2009-2014
Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09
Avail to order
Our Price: $335.60
Tool Kit Gallardo 2009-2014

Sensors

PN Item Diagram
4E0927804 ABS SENSOR RIGHT
ABS SENSOR RIGHT
Avail to order
Our Price: $33.49
ABS SENSOR RIGHT
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 5
Our Price: $33.49
ABS SENSOR LEFT
Open All

Select Group and TAV

TAV: 945.01.00 - LIGHTS

2012 Lamborghini GALLARDO LP 550-2 SPYDER EUROPE LIGHTS (945.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 WASHER (VALID UP TO MODEL YEAR 08) 0 req
2 LH REAR LAMP HEAT SHIELD (VALID UP TO MODEL YEAR 08) 0 req
3 RH REAR LAMP HEAT SHIELD (VALID UP TO MODEL YEAR 08) 0 req
4 REAR LAMP, LH (VALID UP TO MODEL YEAR 08) 0 req
5 REAR LAMP, RH (VALID UP TO MODEL YEAR 08) 0 req
6 407971170F HARNESS,STOP LIGHT HIGH
HARNESS FOR ENGINE HOOD (BRAKE LIGHTS)
1 req Avail to order
Our Price: $225.20
6 407971170G HARNESS,STOP LIGHT HIGH
HARNESS FOR ENGINE HOOD (BRAKE LIGHTS - REAR VIEW CAMERA)
1 req Avail to order
Our Price: $302.70
7 REAR LAMP BRACKET (VALID UP TO MODEL YEAR 08) 0 req
8 REAR LAMP BRACKET (VALID UP TO MODEL YEAR 08) 0 req
9 4B9945097A HIGH-MOUNTED STOP
STOP LAMP
1 req Current Stock: 2
Our Price: $93.23
HIGH-MOUNTED STOP
10 4B9945289 COVER,BRAKE LAMP,
STOP LAMP COVER
2 req Current Stock: 2
Our Price: $2.00
COVER,BRAKE LAMP,
11 SCREW M6X16 (VALID UP TO MODEL YEAR 08) 0 req
12 BULB (VALID UP TO MODEL YEAR 08) 0 req
13 BULB (VALID UP TO MODEL YEAR 08) 0 req
14 BULB (VALID UP TO MODEL YEAR 08) 0 req
15 SCREW M4X16 (VALID UP TO MODEL YEAR 08) 0 req
16 SCREW M6X15.0 (VALID UP TO MODEL YEAR 08) 0 req
17 WASHER (VALID UP TO MODEL YEAR 08) 0 req
18 REAR LAMP BRACKET (VALID UP TO MODEL YEAR 08) 0 req
19 NUT (VALID UP TO MODEL YEAR 08) 0 req
20 NUT M6X20 (VALID UP TO MODEL YEAR 08) 0 req
21 WASHER (VALID UP TO MODEL YEAR 08) 0 req
22 SUPPORT (FOR COUPÈ MODEL) 0 req
23 NUT (FOR COUPÈ MODEL) 0 req
24 SCREW (FOR COUPÈ MODEL) 0 req
25 407971830B BRACKET,PLUG
SUPPORT
1 req Avail to order
Our Price: $29.84
26 N10621601 HEXALOBULAR SOCKET
SCREW M4X12
2 req Current Stock: 5
Our Price: $2.00
HEXALOBULAR SOCKET
27 SUPPORT (VALID UP TO MODEL YEAR 08) 0 req
28 SCREW (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 9) 0 req
29 400945095P REAR COMBINATION LAMP
REAR LAMP, LH
1 req Current Stock: 2
Our Price: $1,857.26
REAR COMBINATION LAMP
30 400945096P REAR COMBINATION LAMP
REAR LAMP, RH
1 req Current Stock: 1
Our Price: $1,857.26
REAR COMBINATION LAMP
31 400813697A BRACKET
LH REAR LAMP BRACKET
1 req Avail to order
Our Price: $71.80
BRACKET
31 400813698A BRACKET
RH REAR LAMP BRACKET
1 req Avail to order
Our Price: $71.80
BRACKET
32 408813391E MOUNTING PART
LH REAR LAMP BRACKET
1 req Avail to order
Our Price: $148.43
MOUNTING PART
32 408813392E MOUNTING PART
RH REAR LAMP BRACKET
1 req Avail to order
Our Price: $312.93
MOUNTING PART
33 408863777 DAMPING
LH REAR LAMP HEAT SHIELD
1 req Avail to order
Our Price: $364.11
DAMPING
33 408863778 DAMPING
RH REAR LAMP HEAT SHIELD
1 req Avail to order
Our Price: $451.85
DAMPING
34 N0116945 washer
WASHER
4 req Current Stock: 61
Our Price: $2.00
washer
35 N01508213 HEXAGON FLANGE NUT
NUT
4 req Current Stock: 7
Our Price: $2.00
HEXAGON FLANGE NUT
36 N90847903 HEXAGON FLANGE
SCREW M6X15.0
4 req Current Stock: 3
Our Price: $2.00
HEXAGON FLANGE
37 8E0806193 RETAINING PART
CLIP
8 req Current Stock: 1
Our Price: $10.85
RETAINING PART
38 N01775311 BULB
BULB (WY5W -12V)
10 req Avail to order
Our Price: $6.13
BULB
39 N10591501 BULB
BULB (W16W -12V)
2 req Avail to order
Our Price: $5.46
BULB
40 N10727901 BULB
BULB (19W -12V)
6 req Avail to order
Our Price: $42.10
BULB
41 420945703 REAR FOG LIGHT
REAR FOG LAMP
1 req Current Stock: 1
Our Price: $128.20
REAR FOG LIGHT
42 400937546 CLUTCH CARRIER
RVC CONNECTION
1 req Avail to order
Our Price: $3.29
43 N10472101 FILLISTER-HEAD
SCREW M6X40
8 req Current Stock: 9
Our Price: $2.00
FILLISTER-HEAD

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
