2012 GALLARDO LP 550-2 SPYDER - EUROPE

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 823.02.00 - LUGGAGE BOOT TRIMS

2012 Lamborghini GALLARDO LP 550-2 SPYDER EUROPE LUGGAGE BOOT TRIMS (823.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		RUBBER SUPPORT (VALID UP TO MODEL YEAR 08 )	0 req
3	400815715A	COVER LID, LH	1 req	Avail to order Our Price: $151.41
4	400815716A	COVER LID, RH	1 req	Avail to order Our Price: $151.41
5	400821169B	COVER COVER, LH	1 req	Avail to order Our Price: $117.00
6	400821170B	COVER COVER, RH	1 req	Avail to order Our Price: $431.97
7	400857913C	ANGLE BRACKET FIXING CORNER	1 req	Avail to order Our Price: $250.43
8	400857914B	ANGLE BRACKET FIXING CORNER	1 req	Current Stock: 1 Our Price: $273.39
9	400857161B	COVER COVER PLATE	1 req	Avail to order Our Price: $410.45
10		LUGGAGE COMPARTMENT PANEL FOR USA (VALID FOR A MARKET USA)	0 req
11		LUGGAGE COMPARTMENT PANEL FOR USA (VALID UP TO MODEL YEAR 08)	0 req
12	400863362BA	TRUNK LINING Gallardo 2010-2014 All markets except USA LUGGAGE COMPARMENT ASS	1 req	Avail to order Our Price: $3,860.42
13		CD CHANGER COVER (VALID UP TO MODEL YEAR 08)	0 req
14	400863439B	COVER BATTERY INSPECTION LID	1 req	Avail to order Our Price: $341.56
15		TV TUNER COVER (VALID UP TO MODEL YEAR 08)	0 req
16	401819413D	PLENUM PANEL COVER COWL TOP COVER, LHD	1 req	Current Stock: 1 Our Price: $891.20
17	4B0947415	COURTESY DOOR LIGHT LIGHT	1 req	Avail to order Our Price: $2.37
19		CONNECTOR SUPPORT (VALID UP TO MODEL YEAR 08)	0 req
20	400864669A	SEALING PROFILE FRONT HOOD COMPARTMENT	1 req	Current Stock: 1 Our Price: $327.21
21		CD LOADER SUPPORT BRACKET (VALID UP TO MODEL YEAR 08)	0 req
22	1Z0860505C	ATTACHMENT SCREW SCREW M6X12.0	4 req	Current Stock: 2 Our Price: $2.00
23	1Z0860505C	ATTACHMENT SCREW SCREW M6X12.0	4 req	Current Stock: 2 Our Price: $2.00
24		HOSE (VALID UP TO MODEL YEAR 08)	0 req
25		HOSE (VALID UP TO MODEL YEAR 08)	0 req
26		HOSE (VALID UP TO MODEL YEAR 08)	0 req
27		CONNECTOR (VALID UP TO MODEL YEAR 08)	0 req
28		CLAMP (VALID UP TO MODEL YEAR 08)	0 req
29	1J0955276B	cap COVER	3 req	Current Stock: 5 Our Price: $9.69
31		OUTLET 12V (VALID UP TO MODEL YEAR 08)	0 req
32		PLUG 8X14,5 (VALID FOR A MARKET USA)	0 req
33	N10632202	HEXALOBULAR SOCKET SCREW M6X30	4 req	Current Stock: 2 Our Price: $2.00
34	N01166623	WASHER WASHER	4 req	Avail to order Our Price: $2.00
35		PLUG 8X14,5 (VALID UP TO MODEL YEAR 08)	0 req
36		FASTENER LYS FUSION, YELLOW (VALID UP TO MODEL YEAR 08)	0 req
37		WASHER (VALID UP TO MODEL YEAR 08)	0 req
38		SCREW M5X30.0 (VALID UP TO MODEL YEAR 08)	0 req
39		SCREW M5X12 (VALID UP TO MODEL YEAR 08)	0 req
40		SCREW M5X12 (VALID UP TO MODEL YEAR 08)	0 req
41	N90533005	HEX. BOLT WITH SCREW M6X20 (WITH SIREN)	2 req	Current Stock: 8 Our Price: $1.94
41	N90847903	HEXAGON FLANGE SCREW M6X15 (WITHAUT SIREN)	2 req	Avail to order Our Price: $2.00
42	N90847903	HEXAGON FLANGE SCREW M6X15	2 req	Avail to order Our Price: $2.00
43		WASHER (VALID UP TO MODEL YEAR 08)	0 req
44	400861351A	BRACKET LH SUPPORT	1 req	Avail to order Our Price: $109.64
45	400861352A	BRACKET RH SUPPORT	1 req	Avail to order Our Price: $109.64
46	N91195701	SPEED NUT CLIP	2 req	Avail to order Our Price: $3.30
47	N90944603	HEXALOBULAR SOCKET SCREW M5X12	4 req	Avail to order Our Price: $2.00
48	4E0919299	PLUG SOCKET OUTLET 12V	1 req	Avail to order Our Price: $15.43
49	400863440	TRIM FRAME	1 req	Avail to order Our Price: $43.67
50	400951605	SIREN BRACKET SUPPORT (SIREN)	1 req	Avail to order Our Price: $146.38
51	N10609202	HEXAGON FLANGE NUT NUT M8 (SIREN)	1 req	Current Stock: 12 Our Price: $2.00
52	400971395	HARNESS, LIGHT WIRING HARNESS	1 req	Avail to order Our Price: $171.50
53		SIREN (SEE TABLE 012.01.00 - SEE REF. 19)	0 req
54	893803593A	PLUG PLUG	2 req	Current Stock: 3 Our Price: $4.17
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
