Maintenance Parts:

Common repairs and upgrades

PN Item Diagram
4T0898201 DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan
PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR
Current Stock: 2
Our Price: $192.37
DOOR LIGHT WITH LAMBORGHINI WRITING KIT Huracan

Drivetrain

PN Item Diagram
079198405E Oil Filter Gallardo/Huracan LP Series
Oil Filter Gallardo LP Series
Current Stock: 18
Our Price: $67.74
Oil Filter Gallardo/Huracan LP Series

Fuel-Air

PN Item Diagram
420133844D Air filter Gallardo LP 560-4
FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ
Current Stock: 1
Our Price: $93.96
Air filter Gallardo LP 560-4
4F0898438C CABIN FILTER ELEMENT SOLD AS PAIR
FILTER ELEMENT
Current Stock: 4
Our Price: $73.57
CABIN FILTER ELEMENT SOLD AS PAIR
0R1400314 GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit
Avail to order
Our Price: $413.83
GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit
420133844DZ Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
FILTER ELEMENT
Current Stock: 2
Our Price: $280.95
Pair High Flow K&N Air filter Gallardo LP 550,560-4,570
4D0906321C FUEL FILTER
FILTER
Current Stock: 3
Our Price: $30.45
FUEL FILTER
4F0201511E Fuel Filter - Gallardo LP 560-4
FUEL FILTER - Gallardo LP 560-4
Current Stock: 4
Our Price: $56.08
Fuel Filter - Gallardo LP 560-4

Misc

PN Item Diagram
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 6
Our Price: $153.78
BATTERY CHARGER ROW BC - EURO
900000382 BATTERY CHARGER USA BC
BATTERY CHARGER USA BC
Current Stock: 1
Our Price: $153.78
BATTERY CHARGER USA BC
0R1400308 Tool Kit Gallardo 2009-2014
Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09
Avail to order
Our Price: $335.60
Tool Kit Gallardo 2009-2014

Sensors

PN Item Diagram
4E0927804 ABS SENSOR RIGHT
ABS SENSOR RIGHT
Avail to order
Our Price: $33.49
ABS SENSOR RIGHT
4E0927803 ABS SENSOR LEFT
ABS SENSOR LEFT
Current Stock: 5
Our Price: $33.49
ABS SENSOR LEFT
Open All

Select Group and TAV

TAV: 103.04.00 - TIMING CHAIN COVER ­ PROPELLER SHAFT

2010 Lamborghini GALLARDO LP 550-2 COUPE EUROPE TIMING CHAIN COVER ­ PROPELLER SHAFT (103.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 COVER (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 20) 0 req
2 N10124306 HEXALOBULAR SOCKET
SCREW M6X20.0
13 req Current Stock: 4
Our Price: $2.00
HEXALOBULAR SOCKET
3 WHT000198 STUD
STUD BOLT M10XM12X84
3 req Avail to order
Our Price: $8.75
5 N10261311 HEXAGON FLANGE NUT
NUT M10
9 req Current Stock: 11
Our Price: $2.00
HEXAGON FLANGE NUT
6 07L103051A Main Seal
SEAL RING
1 req Current Stock: 2
Our Price: $55.94
Main Seal
7 N10156206 SCREW
SCREW M6X30.0
10 req Current Stock: 130
Our Price: $2.00
SCREW
8 N91068601 12-POINT SOCKET
SCREW M8X32.0
6 req Avail to order
Our Price: $2.00
9 WHT002302 TAP END STUD
STUD BOLT M10 2MX59
2 req Avail to order
Our Price: $4.74
17 WHT002302 TAP END STUD
STUD BOLT M10 2MX59
2 req Avail to order
Our Price: $4.74
18 WHT000197 STUD
STUD BOLT M10XM12X90
1 req Avail to order
Our Price: $10.93
19 WHT002301 TAP END STUD
STUD BOLT M10 2MX167
1 req Avail to order
Our Price: $21.50
20 07L103171AP SEALING FLANGE
COVER
0 req Avail to order
Our Price: $1,112.90
21 N91119401 SCREW PLUG
PLUG M10X1.00X10.0
1 req Avail to order
Our Price: $2.27
22 N0138063 O-RING
WASHER A10X14
1 req Current Stock: 16
Our Price: $2.00
O-RING
23 ENGINE BLOCK (SEE TABLE 1030100) 0 req
24 07L103037 Seal plug
PLUG (VALID FOR A MODEL 2WD)
1 req Avail to order
Our Price: $4.16

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
