TAV: 701.13.00 - CENTER FRAME ELEMENTS

2008 Lamborghini GALLARDO SPYDER USA CENTER FRAME ELEMENTS (701.13.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	407803221	CROSS MEMBER CROSS MEMBER	1 req	Avail to order Our Price: $742.89
2	408801403	FLOOR PART BOARD	1 req	Avail to order Our Price: $582.11
3	408801404	FLOOR PART BOARD	1 req	Avail to order Our Price: $582.11
4	407803145	CROSS MEMBER BRACKET	1 req	Avail to order 1 Used Available Our Price: $117.62
5	400804210A	INSERT INSERT	1 req	Avail to order Our Price: $356.56
6	407813467	REAR PANEL REAR PANEL	1 req	Avail to order Our Price: $5,374.43
7	407813503	REAR SHELF BOARD	1 req	Avail to order Our Price: $689.30
8	407813504	REAR SHELF BOARD	1 req	Avail to order Our Price: $647.62
9	N90919302	DRILLING SCREW SCREW M5X18	55 req	Avail to order Our Price: $2.00
10	407803227	STRUT LH BRACKET	1 req	Avail to order Our Price: $350.61
11	407803228	STRUT RH BRACKET	1 req	Avail to order Our Price: $350.61
12	407813975	MOUNTING SCREW M8X75	6 req	Avail to order Our Price: $2.00
13	N91000203	HEXALOBULAR SOCKET SCREW M8X25	9 req	Avail to order Our Price: $5.81
14	407201970F	COVER COVER, LH	1 req	Avail to order Our Price: $283.61
15	407201970E	COVER RIGHT COVER, RH	1 req	Avail to order Our Price: $283.61
16	400201621	seal GASKET	1 req	Current Stock: 1 Our Price: $39.16
17	400201621	seal GASKET	1 req	Current Stock: 1 Our Price: $39.16
18	N90847903	HEXAGON FLANGE SCREW M6X15	8 req	Avail to order Our Price: $2.00
19	407803581	ANGLE BRACKET FIXING CORNER	1 req	Avail to order Our Price: $189.82
20	407803582	ANGLE BRACKET FIXING CORNER	1 req	Avail to order Our Price: $189.82
21	407827876	CARRIER PART SUPPORT	1 req	Avail to order Our Price: $31.79
22	N90693702	6-POINT FLANGE M5X20.0 SCREW M5X20	2 req	Avail to order Our Price: $2.00
23	N10347804	HEXALOBULAR SOCKET SCREW M8X20	4 req	Current Stock: 8 Our Price: $2.00
24		BOARD (VALID UP TO MODEL YEAR 08)	0 req
25		BOARD (VALID UP TO MODEL YEAR 08)	0 req
26		COVER (VALID UP TO MODEL YEAR 08)	0 req
27		GASKET (VALID UP TO MODEL YEAR 08)	0 req
28		SCREW M6X16 (VALID UP TO MODEL YEAR 08)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.

Already registered?

Don't Have an Account?

Need Help?

Popular Help Topics

Lamborghini Parts Diagrams

2008 GALLARDO SPYDER - USA

Maintenance Parts:

Belts

Brakes

Common repairs and upgrades

Drivetrain

Fuel-Air

Fuses-Bulbs-Relays

Gaskets

Ignition

Misc

Sensors

Tools and Tookits

Select Group and TAV

TAV: 701.13.00 - CENTER FRAME ELEMENTS

TAV: 701.13.00 - CENTER FRAME ELEMENTS
