2000-2001 Lamborghini Diablo 6.0 USA Doors (72.02.00)

Maintenance Parts:

Belts

PN	Item	Diagram
004534071	Compressor Belt Compressor Belt		Avail to order Our Price: $142.21
07M109565	WATER PUMP PULLEY STOCK WATER PUMP PULLEY - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES		Current Stock: 1 Our Price: $399.00

Brakes

PN	Item	Diagram
410615115D	E-Brake Pad - Late Diablo - Murcielago Sold Each E-Brake Pad Murcielago and late Diablo Sold Each		Current Stock: 3 Our Price: $57.74
0032000561	Brake Pad Kit -Front - Late Diablo - Murcielago -4 Pads - 2 Per Rotor Brake Pad Kit 4 Pads per kit. Front same part number. For Full set of Front , need qty 2.		Current Stock: 1 Our Price: $1,154.58

Common repairs and upgrades

PN	Item
0079004387	SHOCK ABSORBER SHOCK ABSORBER FOR ANTERIOR COWLING	Current Stock: 2 Our Price: $139.59
0092004388	shock absorber for engine cowling shock absorber for engine cowling	Current Stock: 4 Our Price: $252.98
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48
429837987	DOOR DAMPING DOOR DAMPING	Current Stock: 2 Our Price: $129.73

Drivetrain

PN	Item
002137138	Balanced Assembly (Pressure Plate and flywheel) - Late Model Diablo Balanced Clutch 002137138 Clutch wheel sold seperately	Avail to order Our Price: $2,170.00
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
002135367	Throw Out Bearing - Late Diablo Thrust Bearing Valeo952112lo	Avail to order Our Price: $515.72
002136948	Slave Clutch Cylinder Diablo / Countach Slave Clutch Cylinder	Current Stock: 3 Our Price: $134.36
002134687a	1995 - 2001 Diablo Clutch Rod This is an aftermarket Clutch rod upgrade for Diablo's manufactured after 1994 (1995 - 2001) These rods are very prone to breakage. For full article and installation visit: http://lamboweb.com/Repairs_Section/Diablo_Repairs_Broken_Clutch_Rod.htm http://www.lamboweb.com/Repairs_Section/Repairs_Clutch_Connecting_Rod.htm	Avail to order Our Price: $631.15
0017002472	Water Pump 1995 2001 - READ DESCRIPTION Coolant Pump Complete - This Pump fits Diablos from 1995 to 2001 - HOWEVER there are TWO pulley types, you must double check how your power steering is connected. The other version is PN 0017001862	Avail to order Our Price: $3,329.31
0017001862	WATER PUMP COMPLETE 1995 2001 - READ DESCRIPTION WATER PUMP COMPLETE 1995 2001 - READ DESCRIPTION HOWEVER THERE ARE TWO PULLEY TYPES, YOU MUST DOUBLE CHECK HOW YOUR POWER STEERING IS CONNECTED. THE OTHER VERSION IS PN 0017002472	Avail to order Our Price: $4,079.91
002135365R	CLUTCH DIABLO 1995 and up - Reconditioned CLUTCH DIABLO 1995 and up - Reconditioned PRESSURE PLATE ONLY	Current Stock: 1 Our Price: $678.73
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 13 Our Price: $146.53

Fuel-Air

PN	Item
07M133843	Air Filter - LM002, Countach, Diablo, Murcielago Please Check your Part Manual for a Description For performance filters see PN: 07M133843A	Current Stock: 4 Our Price: $31.73
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.16
AMAIRD	Hi-Performance aFe Air Filter - Diablo/Murcielago - SPORT Air Filter Murcielago - Diablo After Market aFe Air Filter 30-10133	Current Stock: 1 Our Price: $145.65
002024396	FUEL INJECTOR (Sold Ea) Manifold Upper CoverInjector	Avail to order Our Price: $405.49
002024398	Fuel Pump Fuel Pump	Current Stock: 6 Our Price: $760.98
07M133843KN	K&N Air Filter - LM002, Countach, Diablo, Murcielago K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $70.48
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $782.63
410805396	FILTER BOX Please Check your Part Manual for a Description	Current Stock: 1 Our Price: $151.86
410820367A	PARTICULATE FILTER PARTICULATE FILTER	Current Stock: 2 Our Price: $71.62

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006329695	BULB FOR FOGLIGHT BULB FOR FOGLIGHT	Current Stock: 1 Our Price: $19.35
006329450	Bulb Headlight Bulb Headlight	Current Stock: 1 Our Price: $32.48
006137479	250a Maxi Fuse 250a Maxi Fuse	Current Stock: 3 Our Price: $12.70
006138330	ITALAMEC 384 (70A) ITALAMEC 384 (70A)	Avail to order Our Price: $34.90
006138003	DRL relay DRL relay	Avail to order Our Price: $37.24
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006038006	Micro Relay Micro Relay	Avail to order Our Price: $22.27
0063005578	LAMP LAMP	Current Stock: 6 Our Price: $4.66
006329698	Bulb Bulb	Avail to order Our Price: $9.04
0063005579	LAMP LAMP	Avail to order Our Price: $10.77
410947413	RED DOOR LIGHT RED DOOR LIGHT - NLA (No Longer Available) TO ORDER FROM FACTORY PLEASE CONTACT US FOR OTHER OPTIONS.	Avail to order Our Price: $92.92

Gaskets

PN	Item	Diagram
0R1320002	Diablo REAR Differential Seal Kit Dif Seal Kit		Current Stock: 1 Our Price: $48.52
600940141L	latch Gasket Left latch Gasket Set Left This is the rubber/plastic gasket that is located on the Left side between the outer door latch and the door frame		Current Stock: 5 Our Price: $24.28

Ignition

PN	Item
DiabloWireSet	Spark Plug Wires 1991-1995 Diablo - Aftermarket Spark Plug Wires 1991 through 1995 ONLY for systems using a Distributor cap	Avail to order Our Price: $820.50
0016003036	Spark Plug sold ea - Diablo and Murcielago Spark Plug	Avail to order Our Price: $64.82
DiabloWireSet2	Spark Plug Wires 1996 and up Diablo - Aftermarket Spark Plug Wires for Diablos with coil pack	Avail to order Our Price: $1,650.70
0016003534	IGNITION COIL IGNITION COIL NLA (NO LONGER AVAILABLE TO ORDER FROM FACTORY BUT THEY ARE AVAILABLE) CONTACT US FOR CURRENT STOCK AND AVAILABILTY	Current Stock: 7 Our Price: $212.16
0016004528	Ignition Coil Ignition Coil	Current Stock: 18 Our Price: $61.50

Misc

PN	Item
0071003278	Wiper Blade wiper blade	Avail to order Our Price: $40.56
0061005005	MED 2000 Alarm Remote Control Programmed MED 2000 Alarm Remote Control. You must supply the Cars VIN along with proof of ownership (Registration and photo Identification) scanned and emailed or a copy sent to us.	Avail to order Our Price: $212.41
006134045	DIAGNOSIS RESET CONNECTOR DIAGNOSIS RESET CONNECTOR ALSO SEE 006134045	Current Stock: 1 Our Price: $327.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
001327641	POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO POTENTIOMETER TPS THROTTLE POSITION SENSOR DIABLO	Current Stock: 2 Our Price: $199.83
001536755	OIL TEMPERATURE THERMOSTAT OIL TEMPERATURE THERMOSTAT - also used on Diablo 91-93 2wd and 94	Current Stock: 1 Our Price: $544.16
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $375.19
0017006576	THERMOSTAT FOR DIABLO WATER THERMOSTAT - -NLA (No Longer Available) DIRECT FROM LAMBORGHINI CONTACT US TO VERIFY AVAILABILITY FROM OTHER SOURCES	Current Stock: 3 Our Price: $541.02
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $697.10
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
0051001139	NLA (No Longer Available) ABS Sensor Wheel Speed Sensor - Diablo/Murcielago	Avail to order Our Price: $294.44
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $130.41
001724565	Fan Motor Thermal Contact Fan Motor Thermal Contact	Avail to order Our Price: $244.48
0R1470156	MURCIELAGO AND DIABLO 6.0 MIN-MAX LIFT SYSTEM SENSORS KIT MURCIELAGO AND DIABLO 6.0 MIN-MAX LIFT SYSTEM SENSORS KIT	Avail to order Our Price: $1,061.50

Tools and Tookits

PN	Item	Diagram
004129973	DIABLO FRONT TOW HITCH ASSEMBLY DIABLO FRONT TOW HITCH ASSEMBLY		Avail to order Our Price: $1,528.22
wheeltool	Wheel install tool Screws into hub for easy installation.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 72.02.00 - Doors

2000-2001 Lamborghini Diablo 6.0 USA Doors (72.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	0072009904	RIGHT DOOR ASSEMBLY	1 req	Avail to order Our Price: $13,038.04
1	0072009906	Left Door Assembly 6.0 Diablo	1 req	Avail to order Our Price: $13,105.03
2	009421604	Rh Door Motor	1 req	Avail to order Our Price: $569.53
2	009421605	Lh Door Motor	1 req	Avail to order Our Price: $569.53
3	009421600	RH Window motor and regulator assembly	1 req	Avail to order Our Price: $695.64
3	009421601	LH Window motor and regulator assembly	1 req	Avail to order Our Price: $2,296.31
4	WHT002961	WASHER	8 req	Current Stock: 38 Our Price: $2.00
5	008700663	Screw M6	8 req	Current Stock: 11 Our Price: $2.00
6	N0211963	HEX.HEAD CLAMPING	8 req	Avail to order Our Price: $2.00
7	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.16
8	009421429	Rh Door Window Plate	2 req	Avail to order Our Price: $16.53
8	009421430	Lh Door Window Plate	2 req	Avail to order Our Price: $290.63
9	N01508213	HEXAGON FLANGE NUT	6 req	Current Stock: 4 Our Price: $2.00
10	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
11	WHT003040	WASHER	8 req	Current Stock: 2 Our Price: $8.16
12	009421428	Pad	4 req	Current Stock: 3 Our Price: $6.03
13	009421607	Pin And Bracket	4 req	Avail to order Our Price: $69.14
14	009421606	Winder Motor Wiring	2 req	Avail to order Our Price: $29.37
15	008830411	Spring	2 req	Current Stock: 1 Our Price: $2.00
16	008830302	Grommet mm 500x113x17	10 req	Avail to order Our Price: $4.36
17	005934448	Door Button Shim	2 req	Current Stock: 3 Our Price: $36.17
18	005934450	DOOR PIN SWITCH	2 req	Avail to order Our Price: $25.09
19	429837987	DOOR DAMPING	2 req	Current Stock: 2 Our Price: $129.73
20	WHT003304	Lock Screw 2.9x16din7981/Cr B	2 req	Current Stock: 20 Our Price: $2.00
21	410837646A	Door Gas Spring Pin	2 req	Current Stock: 1 Our Price: $9.90
22	008101008	Screw M10x30uni 5739/8g/Zd	8 req	Current Stock: 3 Our Price: $17.19
23	008411015	Washer Tab Fiat 1119579	8 req	Current Stock: 8 Our Price: $13.13
24	N01024230	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
25	N90179103	WASHER	8 req	Current Stock: 5 Our Price: $2.00
26	008900401	Elastic Pin 4x20 Din1481	4 req	Current Stock: 5 Our Price: $2.00
27	410837983	Door Hinge Shim 0.8 mm	req	Current Stock: 1 Our Price: $19.52
27	410837983A	Door Hinge Shim 1 mm	req	Avail to order Our Price: $21.65
27	410837983B	Door Hinge Shim 1.2 mm	req	Current Stock: 1 Our Price: $17.77
27	410837983C	Door Hinge Shim 1.5 mm	req	Avail to order Our Price: $21.17
28	009421029	RH Door Hinge	1 req	Avail to order 1 Used Available Our Price: $1,479.02
28	009421030	LH Door Hinge	1 req	Avail to order 2 Used Available Our Price: $1,487.97
29	410837944A	Door Hinge Shim mm.1	req	Avail to order Our Price: $20.68
29	009421381	Door Hinge Shim mm.1.5	req	Avail to order Our Price: $32.87
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
