TAV: 11.04.00 - Accessories for Left Cylinder Head

2000-2001 Lamborghini Diablo 6.0 USA Accessories for Left Cylinder Head (11.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.10
2	008300611	Stud 6x30 Uni 5911/8g/Z	4 req	Avail to order Our Price: $8.17
3	410819370	CONNECTOR SLEEVE MIN.H2O PUMP	1 req	Avail to order Our Price: $67.58
4	008832003	Clamp	2 req	Avail to order Our Price: $51.54
5	410819159	JOINT	1 req	Avail to order Our Price: $81.47
6	07M103483A	LEFT CYLINDERS HEAD COVER GASKET	1 req	Avail to order Our Price: $249.35
7	008200605	Simmon Nut for urama	1 req	Current Stock: 50 Our Price: $3.10
8	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
9	008300650	Special Stud M6x51	1 req	Avail to order Our Price: $14.00
10	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.10
11	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
12	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.74
13	0011004007	Union	6 req	Current Stock: 13 Our Price: $199.54
14	008602304	O-RING	6 req	Current Stock: 1 Our Price: $10.08
15	008200605	Simmon Nut for urama	1 req	Current Stock: 50 Our Price: $3.10
16	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
17	008300637	Special Stud M6x28	1 req	Avail to order Our Price: $16.73
18	0011006480	CAP	1 req	Avail to order Our Price: $275.87
19	008200605	Simmon Nut for urama	1 req	Current Stock: 50 Our Price: $3.10
20	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
21	008300651	Special Stud M6x24	1 req	Avail to order Our Price: $13.81
22	0011004551	Lh Head Variator Cover Gasket	1 req	Current Stock: 7 Our Price: $35.77
23	0011000038	Intake Phase Variator Bushing	1 req	Avail to order Our Price: $55.64
24	0011009498	PHASE TRANSFORMER COVER ASS.	1 req	Avail to order Our Price: $1,479.02
25	WHT003062	O-RING	1 req	Current Stock: 30 Our Price: $7.09
26	008600905	O RING	1 req	Current Stock: 35 Our Price: $11.09
27	WHT003028	TAP END STUD	7 req	Avail to order Our Price: $22.20
28	WHT000771	SPRING LOCK WASHER	7 req	Current Stock: 10 Our Price: $2.00
29	WHT003022	NUT	7 req	Avail to order Our Price: $138.66
30	WHT003041	Soft Copper Washer 6.4x12x1.5	1 req	Current Stock: 14 Our Price: $2.00
31	008100631	Screw M6x8 Uni 5739 8g	1 req	Avail to order Our Price: $2.00
32	008606205	NLA (No Longer Avialable)	3 req	*See Description
33	N01033520	HEXAGON HEAD BOLT	1 req	Current Stock: 6 Our Price: $2.00
34	WHT000771	SPRING LOCK WASHER	1 req	Current Stock: 10 Our Price: $2.00
35	07M103035	Plug Am26x1.5 Din 764	1 req	Current Stock: 1 Our Price: $67.68
36	WHT003049	Copper Washer 26.25x32x1.5	1 req	Avail to order Our Price: $6.21
37	N90111302	o ring	1 req	Current Stock: 16 Our Price: $2.00
38	008603503	Or Ring	2 req	Current Stock: 281 Our Price: $4.86
39	008604703	O-RING	6 req	Current Stock: 3 Our Price: $9.53
40	0011000988	LH Head Gasket	1 req	Avail to order Our Price: $390.86
41	008400818	Copper Washer	2 req	Current Stock: 9 Our Price: $2.00
42	008100839	Screw M8x10 Uni 5739/8g Z	2 req	Current Stock: 17 Our Price: $2.00
43	07M121091	GASKET	2 req	Avail to order Our Price: $47.00
44	001734153	Flywheel Side Head Coolant Out	1 req	Current Stock: 1 Our Price: $740.23
45	008700644	Screw M6x12 Uni 5931/8g/Zd	1 req	Current Stock: 3 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
