TAV: 92.01.01 - Engine Hood

1999 Lamborghini Diablo Roadster USA Engine Hood (92.01.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009960001	RH Rear Bonnet Opening Wire Assembly Roadster	1 req	Current Stock: 1 Our Price: $33.85
2	009460003	Bonnet Emergency Lock Wire	2 req	Avail to order Our Price: $28.76
3	0092009720	ENGINE BONNET ASSEMBLY	1 req	Avail to order Our Price: $20,291.25
4	009960265	Upper Roof Pin Centre Bushing	2 req	Avail to order Our Price: $310.12
5	009960500	Roadster Roof Rod Recess On Engine Cover	2 req	Avail to order Our Price: $162.02
6	0092004332	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	N01508213	HEXAGON FLANGE NUT	4 req	Current Stock: 4 Our Price: $2.00
8	008700344	Black Stainless Steel Screw 79	6 req	Current Stock: 4 Our Price: $2.00
9	004137285	Bonnet Lock	1 req	Avail to order Our Price: $688.80
10	008100603	Screw M6x25 Uni 5739-8g Zg	4 req	Avail to order Our Price: $2.00
11	009960203	Bonnet Lock Assembly	2 req	Avail to order Our Price: $102.43
12	410805717A	Headlight Wire Terminal	4 req	Avail to order Our Price: $11.84
13	004137286	Bonnet Lock Striker	2 req	Current Stock: 2 Our Price: $39.22
14	410827421	Bonnet Lock Wire Adjustment	2 req	Avail to order Our Price: $6.55
15	009960251	Bonnet Lock Striker Shim	1 req	Current Stock: 1 Our Price: $49.57
16	009960257	LH Bonnet Lock Striker	1 req	Avail to order Our Price: $336.21
16	009960256	RH Bonnet Lock Striker	1 req	Avail to order Our Price: $240.79
17	008400627	Washer 6.3x16x2 1/26476/78	4 req	Avail to order Our Price: $25.57
18	N02300213	PREV.TORQUE TYPE	4 req	Avail to order Our Price: $2.39
19	008400627	Washer 6.3x16x2 1/26476/78	req	Avail to order Our Price: $25.57
20	008400627	Washer 6.3x16x2 1/26476/78	6 req	Avail to order Our Price: $25.57
21	N01508213	HEXAGON FLANGE NUT	6 req	Current Stock: 4 Our Price: $2.00
22	009960301	RH Hinge	1 req	Avail to order Our Price: $205.75
22	009960302	Lh Hinge	1 req	Avail to order Our Price: $205.75
23	WHT001942	WASHER	4 req	Current Stock: 13 Our Price: $3.51
24	N0111849	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 5 Our Price: $2.39
25	008400627	Washer 6.3x16x2 1/26476/78	6 req	Avail to order Our Price: $25.57
26	N02300213	PREV.TORQUE TYPE	6 req	Avail to order Our Price: $2.39
27	008850304	Pin 3 H8 L=25 Uni 177	1 req	Current Stock: 23 Our Price: $2.31
28	410823537	Internal Door Handle sold ea	1 req	Avail to order Our Price: $1,359.24
29	WHT003091	Screw M5x16 Uni 5933/Z Black	1 req	Current Stock: 7 Our Price: $2.00
30	410837801A	PROTECTIVE COVER	2 req	Current Stock: 3 Our Price: $54.94
31	0092004386	Gas Strut for Diablo Engine Bonnet Roadster	2 req	Current Stock: 4 1 Used Available Our Price: $259.05
32	009960262	Bonnet/Actuator Pipe	2 req	Current Stock: 2 Our Price: $45.99
33	008700433	Lock Screw 2.9x9.5din7981/Cr	8 req	Avail to order Our Price: $2.00
34	07M907327	Actuator	2 req	Avail to order Our Price: $349.12
35	009960003	RH Bonnet Roof Lock	1 req	Avail to order Our Price: $1,370.15
35	009960004	LH Bonnet Roof Lock	1 req	Avail to order Our Price: $1,370.15
36	009960260	RH Lock Cover	1 req	Avail to order Our Price: $310.86
36	009960261	LH Lock Cover	1 req	Avail to order Our Price: $310.86
37	009960002	LH Rear Bonnet Opening Wire Assembly Roadster	1 req	Avail to order Our Price: $115.85
38	009960264	Bonnet Bushing Seal	2 req	Current Stock: 12 Our Price: $3.06
39	009960263	Lower Roof Pin Centring Bushin	2 req	Current Stock: 4 Our Price: $45.77
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
