TAV: 66.04.01 - Coque Elements-Left Flank

1999 Lamborghini Diablo Roadster USA Coque Elements-Left Flank (66.04.01)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Diablo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	009910203	LH Rear Mudguard Net	1 req	Avail to order Our Price: $134.04
2	009953101	Air Cleaner LH Manifold	1 req	Avail to order Our Price: $342.92
3	009910205	Rear Mudguard LH Net	1 req	Avail to order Our Price: $99.00
4	009907108	LH Cover Quarter gasket Roadster	1 req	Current Stock: 1 Our Price: $20.06
5	400853745D	BULL SHIELD TYPE SIGN SCUDO	1 req	Avail to order Our Price: $427.89
6	009911501	LH Rear Wheelhouse	1 req	Avail to order Our Price: $1,173.35
7	009411513	Left And Right Rear Bulkhead S	1 req	Current Stock: 1 Our Price: $182.07
8	009911503	LH Rear Wheelhouse Apron	1 req	Avail to order Our Price: $887.33
9	WHT000916A	SPEED NUT	17 req	Current Stock: 10 Our Price: $16.53
10	N91109201	WASHER	17 req	Current Stock: 103 Our Price: $2.00
11	008700449	Screw 1/56819/01 Rif. Fiat	17 req	Current Stock: 19 Our Price: $3.43
12	009411511	Rh/Lh Rear W/House Grit Seal	1 req	Avail to order Our Price: $128.07
13	009455518	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	WHT000757	SCREW	13 req	Avail to order Our Price: $5.44
15	008400629	Nylon Washer 6.4x14x1.2 Nfe 27	13 req	Current Stock: 6 Our Price: $2.00
16	009458615	Lh Door Footboard	1 req	Avail to order Our Price: $891.56
17	WHT000757	SCREW	3 req	Avail to order Our Price: $5.44
18	008400629	Nylon Washer 6.4x14x1.2 Nfe 27	3 req	Current Stock: 6 Our Price: $2.00
19	N90327506	SPEED NUT	6 req	Current Stock: 43 Our Price: $2.00
20	WHT002961	WASHER	3 req	Current Stock: 38 Our Price: $2.00
21	008700680	Special Screw M6x1x20	9 req	Avail to order Our Price: $3.42
22	009410311	Lh Skirt Air Intake Front Fin	1 req	Avail to order Our Price: $6,316.81
23	WHT003304	Lock Screw 2.9x16din7981/Cr B	4 req	Current Stock: 20 Our Price: $2.00
24	009410312	Lh Skirt Air Intake Rear Fin	1 req	Avail to order Our Price: $6,316.81
25	WHT003114	PAN HEAD SHEET	6 req	Current Stock: 20 Our Price: $5.88
26	WHT003424	Spring	6 req	Current Stock: 7 Our Price: $2.00
27	009410306	Conditioned Air Valve Lid On R	1 req	Avail to order Our Price: $78.73
28	009910301	LH Skirt Rocker	1 req	Avail to order Our Price: $5,997.25
29	009430148	Lh Sidemember Grid	1 req	Avail to order Our Price: $128.72
30	009453149	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
31	009453126	GASKETS FOR AIR CONV. RAD. OIL	1 req	Avail to order Our Price: $4.69
32	009453125	Seal/Fa Cn/20	2 req	Avail to order Our Price: $6.19
33	009453142	Oil Radiator Air Outlet Duct	1 req	Avail to order Our Price: $126.59
34	N90327506	SPEED NUT	2 req	Current Stock: 43 Our Price: $2.00
35	N10718801	HEXAGON FLANGE BOLT	2 req	Current Stock: 4 Our Price: $2.00
36	009490200	Oil Radiator Air Output Manifo	1 req	Avail to order Our Price: $159.53
37	009910003	LH Rear Quarter Roadster	1 req	Avail to order Our Price: $11,256.35
38	009910208	Air Radiator Vent LHGrid	1 req	Avail to order Our Price: $188.61
39	007090117	Seal	1 req	Avail to order Our Price: $58.42
40	004135636	Lh Coolant Radiator Side Brack	1 req	Avail to order Our Price: $85.44
41	0074001517	L144 Coolant Radiator LH Manif	1 req	Avail to order Our Price: $942.26
42	0074001522	No Description - Please Check your book	1 req	Avail to order Our Price: $10.29
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
