1986 Countach 5000 Quatro - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	ALTERNATOR DRIVE BELT ALTERNATOR DRIVE BELT - NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Current Stock: 7 Our Price: $312.98

Brakes

PN	Item	Diagram
003113912	BRAKE PAD BRAKE PAD SET NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $46.11

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 3 Our Price: $121.15
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $109.98
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 2 Our Price: $85.33
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 6 Our Price: $28.85

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 19 Our Price: $99.09
002136948	SLAVE CLUTCH CYLINDER DIABLO / COUNTACH SLAVE CLUTCH CYLINDER	Current Stock: 7 Our Price: $153.71
002121294	CLUTCH MECHANISM CLUTCH MECHANISM NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $8,016.47
002121675	COUNTACH THOWOUT BEARING THRUST SLEEVE	Avail to order Our Price: $8,261.05

Fuel-Air

PN	Item
07M133843	AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION FOR PERFORMANCE FILTERS SEE PN: 07M133843A	Current Stock: 6 Our Price: $30.43
001628130	RELAY/PRINTED BOARD BOX UNIT. NLA (NO LONGER AVAILABLE) RELAY/PRINTED BOARD BOX UNIT. THIS UNIT IS NOT LONGER AVAILABLE FROM THE FACTORY.	Avail to order Our Price: $1,410.14
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,655.01
002021141RE	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021141	COUNTACH EFI FUEL INJECTION PUMP COUNTACH FUEL INJECTION INLINE FUEL PUMP	Avail to order Our Price: $1,537.30
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $31.41
002021145	ACCUMULATOR ACCUMULATORS	Current Stock: 1 Our Price: $734.75
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $401.29
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $304.68
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $6,654.25
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $998.99
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $495.83
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Current Stock: 1 Our Price: $275.18
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,542.56
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $825.41
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $102.17
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $750.62
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $15.34

Fuses-Bulbs-Relays

PN	Item
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.99
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.47
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.37
006311154	RELAY RELAY	Avail to order Our Price: $53.65
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $19.44
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.40

Gaskets

PN	Item
001526489	ENGINE GASKET SET - COUNTACH QUATRO 5000 CARBURETED ENGINE GASKET KIT - COUNTACH QUATRO 5000 CARBURETED SEE PN 001526469 FOR SEALS	Avail to order Our Price: $2,551.11
001526469	GROMMET AND OIL SEALS SET - COUNTACH QUATRO 5000 CARBURETED GROMMET AND OIL SEALS SET COUNTACH QUATRO 5000 CARBURETED	Avail to order Our Price: $179.15
001526471	COUNTACH QUATRO VALVE USA - GROMMET & OIL SEALS SET GROMMET & OIL SEALS SET	Avail to order Our Price: $1,525.70
001526491	NLA (NO LONGER AVAILABLE) ENGINE GASKET KIT SEE PN 001526471 FOR SEALS KIT	Avail to order Our Price: $1,638.00

Ignition

PN	Item	Diagram
001630009	SPARK PLUG - 12MM SPARK PLUG		Avail to order Our Price: $37.64
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $3,294.14

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Avail to order Our Price: $51.90
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 1 Our Price: $19.28
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.57
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39

Sensors

PN	Item
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $998.99
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $172.55
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $279.92
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $619.08
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $194.30

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 24 - Windows trims and commands

1986 Lamborghini Countach 5000 Quatro USA Windows trims and commands (24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008102515	This item is no longer available	1 req
2	007015002	SEE PN: 7015018 AND 7015019	1 req	Avail to order Our Price: $321.25
3	007015015	This item is no longer available	1 req
4	007015017	COUNTACH WIND SCREEN - SPECIFY WITH OR WITHOUT ANTENNAE READ NOTES	1 req	Avail to order Our Price: $3,899.00
5	007015014	This item is no longer available	1 req
6	006958530	PASSEMBLY TRIM	2 req	Current Stock: 1 Our Price: $35.79
7	007018001	PASSEMBLYCOMP. LOWERREARWINDOW	1 req	Avail to order Our Price: $623.19
8	006124208	EMBLEM WHITE BULL	1 req	Avail to order Our Price: $131.29
8	006121271	EMBLEM BULL DARK BRONZE 3 INCH	1 req	Avail to order Our Price: $219.49
9	006122589	5000 4 BLACK VALVE PLATE	1 req	Avail to order Our Price: $158.54
9	006122590	EMBLEM 5000 QUATTROVALVE IN WHITE	1 req	Current Stock: 1 Our Price: $158.54
10	006111397	EMBLEM LAMBORGHINI SCRIPT IN BLACK	1 req	Current Stock: 1 Our Price: $370.73
10	006122952	EMBLEM WHITE LAMBORGHINI SCRIPT	1 req	Current Stock: 1 Our Price: $151.67
11	006111345	EMBLEM MATTE BLACK COUNTACH SCRIPT	1 req	Current Stock: 1 Our Price: $355.84
11	006122953	EMBLEM WHITE COUNTACH SCRIPT	1 req	Current Stock: 1 Our Price: $227.12
12	006111447	EMBLEM DESIGNO BERTONE	1 req	Current Stock: 7 Our Price: $555.36
13	007059027	GAS SHOCK ABSORB. PIN	4 req	Current Stock: 6 Our Price: $139.85
14	007060043	ENGINE HOOD DAMPER	1 req	Current Stock: 1 Our Price: $166.17
15	008410802	This item is no longer available	4 req
16	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.46
17	007090080	NLA (NO LONGER AVAILABLE)	2 req	*See Description
18	007860035	ENGINE HOOD ADJUSTMENT PLUG	1 req	Avail to order Our Price: $155.78
19	007090080	NLA (NO LONGER AVAILABLE)	2 req	*See Description
20	007090073	COUNTACH LOWER BOTTOM DOOR SEAL - 190 CM	2 req	Avail to order Our Price: $107.18
21	007021110	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
22	007021108	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
23	007059063	BONNET LOCK	3 req	Avail to order Our Price: $374.87
24	007021111	SIDE VELOUR CHANNEL	1 req	Avail to order Our Price: $157.16
25	007017007	RL SIDE BUTT.WINDOW	1 req	Avail to order Our Price: $523.50
25	007017008	RR SIDE BUTT.WINDOW	1 req	Avail to order Our Price: $523.50
26	007060049	BONNET FRONT LEFT GRILLE	1 req	Avail to order Our Price: $714.93
26	007060048	BONNET FRONT RIGHT GRILLE	1 req	Avail to order Our Price: $714.93
27	008700440	LOCK SCREW 2.9X6.5DIN7981/Z B	4 req	Avail to order Our Price: $0.10
28	007029006	TRUNK LIFTER STRUT	1 req	Current Stock: 2 Our Price: $85.33
29	006111684	RADIATOR AIR OUTLET GRILLE	1 req	Avail to order Our Price: $1,077.43
30	WHT003304	LOCK SCREW 2.9X16DIN7981/CR B	4 req	Current Stock: 20 Our Price: $0.80
31	007021109	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
32	007017003	LH UPPER GLASS	1 req	Avail to order Our Price: $1,164.71
32	007017004	RH UPPER GLASS	1 req	Avail to order Our Price: $1,164.71
33	007021107	75 CM VELOUR CHANNEL	4 req	Avail to order Our Price: $129.95
34	007021111	SIDE VELOUR CHANNEL	1 req	Avail to order Our Price: $157.16
35	007017005	NLA (NO LONGER AVAILABLE)	1 req	*See Description
35	007017006	NLA (NO LONGER AVAILABLE)	1 req	*See Description
36	007090067	COUNTACH FRONT BONNET SEAL 1 OF 2 PIECES	1 req	Current Stock: 1 Our Price: $134.29
37	007090088	FRONT BONNET SEAL	1 req	Avail to order Our Price: $124.82
38	008100616	SCREW M6X16 UNI 5739/5S/Z	6 req	Avail to order Our Price: $0.20
39	WHT002961	WASHER	6 req	Current Stock: 38 Our Price: $0.50
40	N01100637	HEX.NUT	3 req	Current Stock: 18 Our Price: $0.40
41	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	3 req	Avail to order Our Price: $1.00
42	007059034	GAS STRUT	1 req	Current Stock: 5 Our Price: $210.51
43	007059012	BONNET CABLE FIX.WASHER	3 req	Avail to order Our Price: $23.30
44	007090057	This item is no longer available	1 req
45	008580702	CIRCLIP 7 9 DIN 6799	1 req	Avail to order Our Price: $20.54
46	WHT002961	WASHER	1 req	Current Stock: 38 Our Price: $0.50
47	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $1.50
48	007090067	COUNTACH FRONT BONNET SEAL 1 OF 2 PIECES	1 req	Current Stock: 1 Our Price: $134.29
49	007059004	BONNET LEFT HINGE	2 req	Avail to order Our Price: $200.65
50	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	4 req	Avail to order Our Price: $1.00
51	007059048	A ENGINE COV EMERG.WIRING	1 req	Avail to order Our Price: $160.52
52	007059047	A ENGINE COV RELEASE WIRING	1 req	Avail to order Our Price: $160.52
53	007015016	This item is no longer available	1 req
54	007021041	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
55	007021034	MOV.GLASS SUPPORT	2 req	Avail to order Our Price: $415.51
56	008100506	SCREW M5X14 UNI 5739	12 req	Avail to order Our Price: $11.40
57	007021035	WINDOW LIFT.CABLE PLATE	6 req	Avail to order Our Price: $83.07
58	007021112	NLA (NO LONGER AVAILABLE)	2 req	*See Description
59	007017001	LH FIXED BUTT.WINDOW	1 req	Avail to order Our Price: $776.95
59	007017002	RH FIXED BUTT.WINDOW	1 req	Avail to order Our Price: $776.95
60	007021113	REAR VELOUR CHANNEL	2 req	Avail to order Our Price: $127.19
61	006405010	FRONT BONNET HANDLE	1 req	Avail to order Our Price: $109.24
62	007021013	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
62	007021012	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
63	007017031	SIDE QUARTER LIGHT BEZEL	1 req	Avail to order Our Price: $108.84
63	007017032	LH LATER. QUARTER LIGHT BEZEL	1 req	Avail to order Our Price: $390.54
64	007090069	COUNTACH UPPER FORWARD DOOR SEAL - 150 CM	2 req	Current Stock: 2 Our Price: $91.99
65	007021096	QUARTER LIGHT BEAM ASSEMBLY	2 req	Avail to order Our Price: $393.80
66	007090080	NLA (NO LONGER AVAILABLE)	2 req	*See Description
67	007021115	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
68	007021114	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
69	007021195	SHOCK ABSORBER COUNTACH DOOR	2 req	Current Stock: 3 Our Price: $121.15
70	007021193	SHOCK ABSOR.FIX.PIN TO DOOR	2 req	Current Stock: 6 Our Price: $191.16
71	007021093	WINDOW FRAME MOLDING LEFT	1 req	Avail to order Our Price: $660.58
71	007021092	WINDOW FRAME MOLDING RIGHT	1 req	Avail to order Our Price: $660.58
72	007021038	DOOR INN. HANDLE CABLE	2 req	Avail to order Our Price: $33.42
73	410837261	COM.SERR.HEAD 78926 /C DOOR PIECE	4 req	Avail to order Our Price: $3.83
74	006558588	DOOR SAFETY LOCK	2 req	Avail to order Our Price: $18.83
75	007021030	R LOCK LEVER SUPPORT	1 req	Avail to order Our Price: $334.44
75	007021031	L LOCK LEVER SUPPORT	1 req	Avail to order Our Price: $334.44
76	007021191	RIGHT DOOR LOCKS	1 req	Avail to order Our Price: $1,626.46
76	007021192	LEFT DOOR LOCK	1 req	Avail to order Our Price: $1,623.11
77	007021130	OPENING LOCK CONTROLLEVER	1 req	Avail to order Our Price: $164.08
77	007021131	OPEN LOCK CONTROL LEVER	1 req	Avail to order Our Price: $199.46
78	007021132	BL OPEN.CONTROL LEVERPLATE	1 req	Avail to order Our Price: $65.89
78	007021129	BLOCK UNLOCK CONTROLLEVERPLATE	1 req	Avail to order Our Price: $131.88
79	007021134	WINDOW CRANK HANDLE COUNTACH	2 req	Avail to order Our Price: $399.00
80	007021135	DOOR TRIM	2 req	Avail to order Our Price: $35.79
81	007017014	NLA (NO LONGER AVAILABLE)	2 req	*See Description
82	006921178	RH/LH INT. HANDLE NLA	2 req	*See Description
83	007021040	OUTS.DOOR SAF.LOCK TIE ROD	2 req	Avail to order Our Price: $66.84
84	007090073	COUNTACH LOWER BOTTOM DOOR SEAL - 190 CM	2 req	Avail to order Our Price: $107.18
85	007021190	NLA (NO LONGER AVAILABLE)	2 req	*See Description
86	007030012	AIR INTAKE LOWER GRILLE	1 req	Avail to order Our Price: $887.70
86	007030013	AIR INTAKE LOWER GRILLE	1 req	Avail to order Our Price: $887.70
87	007059049	NLA (NO LONGER AVAILABLE TO ORDER)	1 req	*See Description
88	007059051	B ENGINE COV RELEASE WIRING	1 req	Avail to order Our Price: $104.71
89	007059052	B ENGINE COV EMERG.WIRING.	1 req	Avail to order Our Price: $160.52
90	008821003	This item is no longer available	1 req
90	410831407A	HINGE HALF LEFT	1 req	Current Stock: 12 Our Price: $558.63
91	008700433	LOCK SCREW 2.9X9.5DIN7981/CR	2 req	Avail to order Our Price: $0.10
92	007021002	STRIKER FIX.PLATE	2 req	Avail to order Our Price: $60.19
93	007059050	ENGINECOVER EMERGENCY ASSE	1 req	Avail to order Our Price: $160.52
94	008700632	SCREW M6X30 UNI 59338G/ZD	8 req	Current Stock: 4 Our Price: $0.20
95	007060006	BONNET HANDLE NLA (NO LONGER AVAILABLE)	1 req	*See Description
96	006105687	CHASSIS NUMBER PLATE PLATE FOR CHASSIS NUMBER FOR COUNTACH	1 req	Current Stock: 2 Our Price: $94.50
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
