1985 Countach 5000 Quatro - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001613915	ALTERNATOR DRIVE BELT ALTERNATOR DRIVE BELT - NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $661.42

Brakes

PN	Item	Diagram
003113912	BRAKE PAD BRAKE PAD SET NLA FROM LAMBORGHINI WAREHOUSE - SECONDARY SOURCE		Avail to order Our Price: $48.23

Common repairs and upgrades

PN	Item
007021195	SHOCK ABSORBER COUNTACH DOOR SHOCK ABSORBER WITHOUT INTERNAL PARTS YOU MAY ALSO NEED N02214812 X1 HEX.HEAD 007021193 X1 SHOCK ABSOR.FIX.PIN TO DO 007021208 X1 SHOCK ABSORBER SECURPIN A 008580801 X1 O-RING E 8 UNI 7535-75 N01118410 X1 HEX.HEAD CLAMPING NUT WHT002962 X3 WASHER	Current Stock: 7 Our Price: $126.61
007029005	BONNET LIFTER BONNET LIFTER	Current Stock: 4 Our Price: $114.94
007029006	TRUNK LIFTER STRUT TRUNK LIFTER WITH STAB.	Current Stock: 4 Our Price: $89.17
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.47
002136948	SLAVE CLUTCH CYLINDER DIABLO / COUNTACH SLAVE CLUTCH CYLINDER	Current Stock: 3 Our Price: $134.36
002121294	CLUTCH MECHANISM CLUTCH MECHANISM NLA FROM FACTORY CONTACT US FOR CURRENT PRICING AND AVAILABILITY	Avail to order Our Price: $7,000.52
002121675	COUNTACH THOWOUT BEARING THRUST SLEEVE	Current Stock: 1 Our Price: $8,632.38

Fuel-Air

PN	Item
07M133843	AIR FILTER - LM002, COUNTACH, DIABLO, MURCIELAGO PLEASE CHECK YOUR PART MANUAL FOR A DESCRIPTION FOR PERFORMANCE FILTERS SEE PN: 07M133843A	Current Stock: 6 Our Price: $31.73
001628130	NLA (NO LONGER AVAILABLE) RELAY/PRINTED BOARD BOX UNIT. THIS UNIT IS NOT LONGER AVAILABLE FROM THE FACTORY.	Avail to order Our Price: $1,232.20
002021140	WARM UP REGULATOR / HEAT REGULATOR WARM UP REGULATOR / HEAT REGULATOR	Avail to order Our Price: $1,729.41
002021141	COUNTACH EFI FUEL INJECTION PUMP FUEL PUMP	Avail to order Our Price: $799.00
002021142B	FUEL FILTER - COUNTACH - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL FILTER USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE. AS OF 1-3-2024 DOESN'T SHOW AVAILABILITY	Avail to order Our Price: $38.79
002021145	ACCUMULATOR ACCUMULATORS	Current Stock: 1 Our Price: $642.13
002021146	COLD START INJECTOR STARTER INJECTOR	Current Stock: 4 Our Price: $350.83
002021147	FUEL INJECTOR FOR COUNTACH FUEL INJECTOR FOR COUNTACH	Current Stock: 11 Our Price: $318.36
002021170	COUNTACH FUEL DISTRIBUTOR FUEL DISTRIBUTOR 0438100106 (043 8100 106)	Avail to order Our Price: $5,811.46
002021172	FREQUENCY VALVE FREQUENCY VALVE BOSCH 0280150300 (028 0150 300)	Avail to order Our Price: $872.46
002021173	FUEL DAMPERS FUEL DAMPERS	Avail to order Our Price: $518.87
002021173b	FUEL DAMPERS - FOR FUEL INJECTED EFI THIS IS THE ORIGINAL AND SAME FUEL REGULATOR USED ON ALL COUNTACH EFI SYSTEMS. IT HAS A DIFFERENT PART NUMBER, IN ORDER TO QUE THE ORDER FROM ANOTHER VENDOR RATHER THAN THE FACTORY. WE WOULD BE MORE THAN HAPPY TO GET IT FROM ITALY, BUT IT WILL BE THE SAME PUMP AND MUCH MORE EXPENSIVE.	Avail to order Our Price: $339.85
002021174	COUNTACH INJECTION EFI ECU ECU	Avail to order Our Price: $4,741.13
002021176	LAMBDA O2 SENSOR LAMBDA SENSOR *MAY NEED TO USE YOUR EXISTING CONNECTOR	Current Stock: 4 Our Price: $863.20
002021176OE	LAMBDA SENSORS LAMDA SENSORS	Current Stock: 2 Our Price: $126.18
07M133843A	AIR FILTER - SPORT PERFORMANCE FILTER PERFORMANCE FILTER REPLACEMENT FOR 07M133843 AIR FILTER - MURCIELAGO SV LP 670-4	Avail to order Our Price: $782.63
980200016	ADDITIVO X CARB.G 001 700 03 ADDITIVO X CARB.G 001 700 03	Current Stock: 1 Our Price: $16.01

Fuses-Bulbs-Relays

PN	Item
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.86
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.28

Gaskets

PN	Item
001526469	GROMMET AND OIL SEALS SET - COUNTACH QUATRO 5000 CARBURETED GROMMET AND OIL SEALS SET COUNTACH QUATRO 5000 CARBURETED	Avail to order Our Price: $156.07
001526489	ENGINE GASKET SET - COUNTACH QUATRO 5000 CARBURETED ENGINE GASKET KIT - COUNTACH QUATRO 5000 CARBURETED SEE PN 001526469 FOR SEALS	Avail to order Our Price: $2,229.43
001526471	COUNTACH QUATRO VALVE USA - GROMMET & OIL SEALS SET GROMMET & OIL SEALS SET	Avail to order Our Price: $1,333.22
001526491	NLA (NO LONGER AVAILABLE) ENGINE GASKET KIT SEE PN 001526471 FOR SEALS KIT	Avail to order Our Price: $1,431.32

Ignition

PN	Item	Diagram
001630009	SPARK PLUG - 12MM SPARK PLUG		Avail to order Our Price: $39.29
001611403	COUNTACH WIRING HARNESS COUNTACH WIRING HARNESS		Avail to order Our Price: $2,876.02

Misc

PN	Item
006111300	LONG WIPER BLADE LONG WIPER BLADE	Current Stock: 1 Our Price: $54.16
006128790	WIPER SHORT BLADE 13 INCH WIPER SHORT BLADE (PREVIOUS PN 006111019)	Current Stock: 2 Our Price: $20.13
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $373.98

Sensors

PN	Item
002021143	THERMOSTAT SWITCH - EFI COUNTACH ONLY ORIGINAL OEM THERMOSTAT SWITCH - INTERR.TERM.0.280.130.214	Current Stock: 3 Our Price: $872.46
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
001724565	FAN MOTOR THERMAL CONTACT FAN MOTOR THERMAL CONTACT	Avail to order Our Price: $244.48
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $177.89

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 10 - Crankcase

1985 Lamborghini Countach 5000 Quatro USA Crankcase (10)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Countach Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001120924	STUD NUT	28 req	Avail to order Our Price: $42.49
2	008401230	WASHER	28 req	Avail to order Our Price: $57.97
3	001821459	CYLINDER HEAD STUD ON CRANKCAS	1 req	Avail to order Our Price: $104.05
4	008601201	RING 13 MM OR	6 req	Avail to order Our Price: $0.10
5	001120594	NLA (NO LONGER AVAILABLE)	1 req	*See Description
6	001822508	NLA (NO LONGER AVAILABLE)	1 req	*See Description
7	001821070	CRANKCASE & RH CYLINDER HEAD S	1 req	Avail to order Our Price: $4,228.52
8	008850817	REFERENCE PIN 8X28 C40	2 req	Avail to order Our Price: $11.96
9	008200804	NUT	2 req	Current Stock: 7 Our Price: $1.20
10	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.50
11	008300815	SPECIAL STUD M8X33	2 req	Avail to order Our Price: $19.55
12	008300870	SPECIAL STUD M8X158	4 req	Avail to order Our Price: $22.17
13	001820909	CYLINDER LINER SHIM	12 req	Avail to order Our Price: $333.24
14	WHT003085	CYLINDER LINER RUBBER WASHER M	12 req	Avail to order Our Price: $4.66
15	001820907	CYLINDER LINER	12 req	Avail to order Our Price: $1,627.53
16	001822508	NLA (NO LONGER AVAILABLE)	1 req	*See Description
17	001821071	CRANKCASE & LH CYLINDER HEAD S	1 req	Avail to order Our Price: $4,562.97
18	001120593	LH HEAD GASKET	1 req	Avail to order Our Price: $535.21
19	WHT003057	O-RING	4 req	Current Stock: 11 Our Price: $1.50
20	001820995	CRANKCASE CENTRING DOWEL	1 req	Avail to order Our Price: $208.77
21	001820987	This item is no longer available	1 req
22	07L301155	BUSH	14 req	Avail to order Our Price: $62.05
23	008200504	M5 LH. SPECIAL NUT	2 req	Avail to order Our Price: $18.57
24	008410803	WASHER 8.4X17X0.8 DIN 137/B	2 req	Avail to order Our Price: $0.10
25	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $1.60
26	008300878	SPECIAL STUD M8X77	2 req	Avail to order Our Price: $16.53
27	008300877	SPECIAL STUD M8X95	8 req	Avail to order Our Price: $40.45
28	008300817	STUD M8X1X60 UNI 5919 10K	4 req	Avail to order Our Price: $19.55
29	008301235	SPECIAL STUD M12X103	10 req	Avail to order Our Price: $68.75
30	WHT001514	SPRING WASHER	14 req	Current Stock: 9 Our Price: $26.80
31	008200805	M8X1X8 8G/B NUT	12 req	Avail to order Our Price: $0.20
32	001821865	OIL INTAKE PIPE SET	1 req	Avail to order Our Price: $208.77
33	001819519	LOWER BRACKET OIL REDUCTION DO	3 req	Current Stock: 6 Our Price: $27.71
34	001819472	This item is no longer available	1 req
35	008602901	RING 30 MM OR	1 req	Current Stock: 15 Our Price: $0.70
36	001821837	This item is no longer available	3 req
37	001822399	This item is no longer available	2 req
38	008300847	SPECIAL STUD M8X26	28 req	Avail to order Our Price: $0.60
39	001819470	This item is no longer available	1 req
40	008850613	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
41	008301214	SPECIAL STUD M12X94	2 req	Avail to order Our Price: $40.45
42	008301213	SPECIAL STUD M12X98	2 req	Avail to order Our Price: $69.23
43	008701012	SCREW M10X25 UNI 5931/8G/B	1 req	Avail to order Our Price: $8.85
44	008401006	WASHER 22X10.5X2.5 UNI 1734/5S	1 req	Current Stock: 1 Our Price: $0.60
45	008411005	WASHER D.10.5 UNI 1751/F	1 req	Avail to order Our Price: $0.10
46	008841002	HELI-COIL M10X1.25X10	6 req	Avail to order Our Price: $1.80
47	001821887	CRANKSHAFT BULKHEAD	1 req	Avail to order Our Price: $1,746.37
48	008701013	SCREW M10X40 UNI 5931/8G/B	5 req	Avail to order Our Price: $1.10
49	008411005	WASHER D.10.5 UNI 1751/F	5 req	Avail to order Our Price: $0.10
50	008300879	SPECIAL STUD M8X73	2 req	Avail to order Our Price: $16.53
51	WHT003024	NUT	14 req	Avail to order Our Price: $280.62
52	WHT003055	WASHER 13X24X1.2 DIN137/B C72	14 req	Current Stock: 10 Our Price: $0.70
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
