2017 AVENTADOR SV LP750-4 ROADSTER - USA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 407.02.00 - AXLE SHAFT

2017 Lamborghini AVENTADOR SV LP750-4 ROADSTER USA AXLE SHAFT (407.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		601-030)	0 req
1	N10406504	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X12)	10 req	Avail to order Our Price: $2.00
2	N01474011	PAN HEAD BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M6X16)	2 req	Avail to order Our Price: $2.30
3	N91108201	12-POINT SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	12 req	Avail to order Our Price: $3.44
4	470407721B	SHIELD COVER PLATE FOR BRAKE DISC (LEFT)	1 req	Avail to order Our Price: $65.01
4	470407722B	SHIELD COVER PLATE FOR BRAKE DISC (RIGHT)	1 req	Avail to order Our Price: $65.01
5	4E0927803F	SPEED SENSOR SPEED SENSOR (RIGHT)	1 req	Avail to order Our Price: $140.07
5	4E0927804F	SPEED SENSOR SPEED SENSOR (LEFT)	1 req	Current Stock: 1 Our Price: $140.07
6	470407245D	STEERING KNUCKLE WHEEL BEARING HOUSING (UNTIL VIN GLA04209 - CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $763.48
7	470407271B	DRIVE SHAFT DRIVE SHAFT WITH CONSTANT VELOCITY JOINTS (CONTACT YOUR AREA MANAGER)	2 req	Avail to order Our Price: $1,628.84
8	1K0407357C	BACKING PLATE SPACER	6 req	Avail to order Our Price: $1.94
9	WHT000237A	12-POINT SOCKET BALL SCREW (M12X1,5X45)	8 req	Current Stock: 1 Our Price: $6.53
10	4B0407643A	SCREW M16 SHOULDERED BOLT (M16X1,5X72)	2 req	Avail to order Our Price: $17.94
11	4D0407613E	WHEEL HUB WHEEL HUB	2 req	Current Stock: 1 Our Price: $331.51
12	4E0407625E	ANGUL.BALL BEARING DOUBLE (ANGLED) BALL BEARING WITH FLANGE (85MM)	2 req	Avail to order Our Price: $238.95
13	470407613A	WHEEL HUB MOZZO ANT ASSY WHEEL HUB (CENTRAL LOCK WHEEL - FOR SV, AVENTADOR S & CENTENARIO VERSION)	2 req	Avail to order Our Price: $2,253.11
14	WHT007467	WHEEL BOLT M16X1.5X72.0 SHOULDERED BOLT (CENTRAL LOCK WHEEL - FOR SV, AVENTADOR S & CENTENARIO VERSION-M16X1,5X72)	8 req	Avail to order Our Price: $141.64
15		SUSPENSION BLOCKS (FOR SV, AVENTADOR S & CENTENARIO VERSION - SEE ILLUSTRATION :-	0 req
16		TENSIONING NUT - (SEE ILLUSTRATION :- 601-030)	0 req
17	470615315	TANG FOLLOWER	10 req	Avail to order Our Price: $39.40
18	WHT008292	HEXALOBULAR SOCKETM6X30 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (FOR SV, AVENTADOR S & CENTENARIO VERSION-M6X30)	8 req	Avail to order Our Price: $2.01
20	N10328101	RETAINING CLAMP D1-5X15 CABLE CLAMP (FROM VIN CLA01032)	2 req	Avail to order Our Price: $2.23
21	N10714801	HEXALOBULAR SOCKET FILLISTER HEAD BOLT WITH MULTI-POINT SOCKET HEAD (FROM VIN CLA01032-M6X18)	2 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
