2017 AVENTADOR SV LP750-4 ROADSTER - USA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 253.01.00 - SILENCER WITH CATALYST

2017 Lamborghini AVENTADOR SV LP750-4 ROADSTER USA SILENCER WITH CATALYST (253.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470251051H	MUFFLER SILENCER WITH CATALYST (ROW)	1 req	Avail to order Our Price: $13,095.27
2	470825709D	HEAT SHIELD,REAR HEAT SHIELD	1 req	Avail to order Our Price: $4,628.19
3	N10680201	DUO HEXAGON FLANGE BOLT HEXAGON COLLARED BOLT WITH MULTI-POINT SOCKET HEAD (DUO) (M10X75)	2 req	Avail to order Our Price: $3.66
4	N10005207	HEX. BOLT WITH HEXAGON HEAD BOLT (COMBI) (M8X18)	4 req	Avail to order Our Price: $7.75
5	470251303C	SUSPENSION RETAINER FOR EXHAUST SYSTEM	2 req	Avail to order Our Price: $106.92
6	7L0253144B	SUSPENSION BRACKET	2 req	Avail to order Our Price: $56.40
7	N0195307	HEXAGON FLANGE HEX COLLARED BOLT (M8X25)	4 req	Avail to order Our Price: $3.01
8	N10433701	SPEED NUT SPEED NUT (4,8X18,6X16)	12 req	Current Stock: 14 Our Price: $2.00
9	N91032702	HEXALOBULAR SOCKET FLANGE BOLT ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD (M6X20)	4 req	Current Stock: 6 Our Price: $2.00
10	470825981	SPACER SPACER SLEEVE	2 req	Avail to order Our Price: $21.89
11	WHT001942	WASHER WASHER	4 req	Current Stock: 13 Our Price: $3.30
12	420251143	CLAMP CLIP	2 req	Avail to order Our Price: $91.28
13	470131850	HOSE VACUUM HOSE	2 req	Avail to order Our Price: $116.39
14	470971796	BRACKET BRACKET (LEFT)	1 req	Avail to order Our Price: $27.77
14	470971806A	BRACKET BRACKET (RIGHT)	1 req	Avail to order Our Price: $63.72
15	470131849	HOSE VACUUM HOSE	2 req	Avail to order Our Price: $115.96
16	059906051A	PRESSURE SENSOR PRESSURE DIFFERENCE SENDER	2 req	Current Stock: 4 Our Price: $132.75
17	3C0131483A	CLIP SPRING BAND CLAMP (13,5X12)	4 req	Avail to order Our Price: $3.01
18	N10569501	HEXALOBULAR SOCKET ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD (M5X16)	2 req	Avail to order Our Price: $2.23
19	3C0131483	CLIP SPRING BAND CLAMP (11,5X8,4)	4 req	Avail to order Our Price: $3.01
20	N10637302	HEXALOBULAR SOCKETFLANGE BOLT OVAL HEXAGON SOCKET HEAD BOLT (M5X20)	2 req	Current Stock: 8 Our Price: $2.00
21	470825613B	HEAT SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $2,791.27
22	N90775001	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,8X16)	12 req	Current Stock: 9 Our Price: $2.01
23		CROSS MEMBER (SEE ILLUSTRATION :- 701-030)	0 req
24	470825497	DIFFUSER HEAT SHIELD	1 req	Avail to order Our Price: $250.43
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
