2017 Lamborghini AVENTADOR S ENGLAND BUMPER, COMPLETE (807.13.00)

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Avail to order Our Price: $104.15

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.19

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $65.74
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL		Avail to order Our Price: $359.54

Open All

Select Group and TAV

< Previous Next >

TAV: 807.13.00 - BUMPER, COMPLETE

2017 Lamborghini AVENTADOR S ENGLAND BUMPER, COMPLETE (807.13.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470807103L	Aventador S Front Bumper BUMPER (REAR VIEW CAMERA WITH PARKING SENSORS-FRONT)	1 req	Current Stock: 2 Our Price: $15,341.44
2	470807103M	BUMPER,FRONT BUMPER (WITHOUT PARK DISTANCE CONTROL AND PARKING SENSORS-FRONT)	1 req	Avail to order Our Price: $14,722.71
3	4T0853745A	LAMBORGHIN SHIELD BULL LOGO EMBLEM FRONT LAMBORGHINI EMBLEM (FRONT-FRONT)	1 req	Avail to order Our Price: $473.43
3	4T0853745	TYPE SIGN LOGO ANT. LAMBORGHINI EMBLEM (FRONT)	1 req	Current Stock: 4 Our Price: $474.11
4	470919267B	MOUNTING,SENSOR SENSOR BRACKET (CENTER, LEFT)	1 req	Avail to order Our Price: $329.76
4	470919268B	MOUNTING,SENSOR SENSOR BRACKET (CENTER, RIGHT)	1 req	Avail to order Our Price: $329.76
5	470919291B	MOUNTING,SENSOR SENSOR BRACKET (SIDE, LEFT)	1 req	Avail to order Our Price: $296.27
5	470919292B	MOUNTING,SENSOR SENSOR BRACKET (SIDE, RIGHT)	1 req	Avail to order Our Price: $329.76
6	1T0919133C	GASKET SEAL RING	4 req	Current Stock: 19 Our Price: $9.09
7	1S0919275C	SENSOR,PARK SENSOR (WITH PRIMER - LATERAL SENSOR)	2 req	Avail to order Our Price: $133.40
7	1S0919275D	SENSOR,PARK SENSOR (WITH PRIMER - CENTRAL SENSOR)	2 req	Avail to order Our Price: $159.30
7	470919824B	SENSOR SENSORE PARCHEGG. POSITION SENSOR	4 req	Avail to order Our Price: $498.73
8	470807059E	FRONT SPOILER SPOILER ANT. FRONT SPOILER	1 req	Avail to order Our Price: $2,333.27
8	470807059F	FRONT SPOILER SPOILER ANT. FRONT SPOILER (CARBON FIBRE)	1 req	Avail to order Our Price: $15,743.98
9	470807697A	GRILLE FR.BUMP.CEN.GR.LOW GRILLE (FRONT CENTER)	1 req	Avail to order Our Price: $3,578.18
10	N10558102	HEXALOBULAR SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M6X18)	2 req	Current Stock: 9 Our Price: $4.54
11	N10657201	FILLISTER HEAD ST6.3X16-R OVAL HEAD PANEL SCREW (6,3X16)	6 req	Avail to order Our Price: $2.00
12	N90698606	FLANGE TAPPING HEXAGON SOCKET HEAD PANEL BOLT (4,2X16)	16 req	Avail to order Our Price: $2.00
13	N10661002	HEXALOBULAR SOCKET HEX SOCKET OVAL HEAD COLLARED (M6X20)	6 req	Current Stock: 18 Our Price: $2.00
14	N01167026	WASHER WASHER (8,4X24X2)	6 req	Avail to order Our Price: $2.00
15	N90170803	SPEED NUT SPEED NUT (4,2X13X11)	35 req	Current Stock: 3 Our Price: $2.00
16	N10637302	HEXALOBULAR SOCKETFLANGE BOLT OVAL HEXAGON SOCKET HEAD BOLT (M5X20)	2 req	Current Stock: 8 Our Price: $2.00
17	470807325F	REINFORCEMENT REINFORCEMENT FOR BUMPER (LEFT)	1 req	Avail to order Our Price: $163.77
17	470807326E	REINFORCEMENT REINFORCEMENT FOR BUMPER (RIGHT)	1 req	Avail to order Our Price: $106.15
18	N90698605	SCREW HEXAGON SOCKET HEAD PANEL BOLT (ST4,2X16)	30 req	Current Stock: 3 Our Price: $2.00
19	N90981701	SPEED NUT SPEED NUT (M5X21.0X15.3)	2 req	Current Stock: 20 Our Price: $2.00
20	N91207701	HEXALOBULAR SOCKETM5X25 TORX LENS FLANGE SCREW (M5X25)	2 req	Avail to order Our Price: $2.00
21	470807481C	ANGLE BRACKET ARM	2 req	Avail to order Our Price: $30.53
22	N0116945	washer WASHER (7X22)	2 req	Current Stock: 50 Our Price: $2.00
23	N10637302	HEXALOBULAR SOCKETFLANGE BOLT OVAL HEXAGON SOCKET HEAD BOLT (M5X20)	2 req	Current Stock: 8 Our Price: $2.00
23	N10738101	HEXALOBULAR SOCKET HEX SOCKET HEAD BOLT (COMBI) (M5X16)	2 req	Current Stock: 6 Our Price: $2.00
24	470807891	FIXING PART ATTACHMENT BARS	2 req	Avail to order Our Price: $67.00
25	N10017304	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M5)	2 req	Current Stock: 16 Our Price: $2.01
26	WHT000778	SPRING LOCK WASHER WASHER (30X36X1)	2 req	Current Stock: 15 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
