2017 Lamborghini AVENTADOR S ARABIA A/C COMPRESSOR (145.02.00)

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 145.02.00 - A/C COMPRESSOR

2017 Lamborghini AVENTADOR S ARABIA A/C COMPRESSOR (145.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		REF.:-47X1,75	0 req
0		15)	0 req
0		15)	0 req
1	8K0260805H	AIR CONDITION COMPRESSOR LP700 A/C COMPRESSOR	1 req	Avail to order Our Price: $1,153.83
2		BRACKET (VALID UP TO MODEL YEAR 12)	0 req
3	470260810E	PULLEY A/C PULLEY (FROM VIN DLA1411 INTERCHANGEA BLE 1 TO 1)	1 req	Avail to order Our Price: $1,070.59
4	470260877	COVER COVER	1 req	Avail to order Our Price: $244.69
5	470260095A	SHAFT COMPRESSORE INPUT SHAFT (FROM VIN DLA1411 INTERCHANGEA BLE 1 TO 1)	1 req	Avail to order Our Price: $454.93
6		GROOVED BALL BEARING (CANNOT BE SOLD SEPARATELY, INCLUDED IN REF.:-	1 req
7		SEAL RING (CANNOT BE SOLD SEPARATELY, INCLUDED IN	1 req
8	WHT005222	SLOTTED ROUND NUT UNION NUT	1 req	Avail to order Our Price: $53.60
9	N10531802	HEXAGON HEAD BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M8X100)	2 req	Avail to order Our Price: $29.57
10	N10561102	HEXAGON FLANGE BOLT HEX COLLARED BOLT (10X142X45)	1 req	Avail to order Our Price: $8.47
11	470260845	Spacer LENGTH-MEASURING DEVICE	1 req	Avail to order Our Price: $1,211.23
12	07K260817	SEE PN 03L260817 CENTRE SLEEVE (11,15X6,5)	2 req	Avail to order Our Price: $2.00
13		WASHER (VALID UP TO MODEL YEAR 12-8X16X2)	0 req
14	N10406602	SCREW OVAL HEXAGON SOCKET HEAD BOLT (M5X8)	4 req	Current Stock: 6 Our Price: $2.00
15	470198001	AUXILIARY ENGINE STUFF BRACKET REPAIR SET	1 req	Avail to order Our Price: $1,542.73
16		OVAL HEXAGON SOCKET HEAD BOLT (VALID UP TO MODEL YEAR 12-M5X10)	0 req
17		WARM AIR DEFLECTOR PLATE (VALID UP TO MODEL YEAR 12)	1 req
18		OVAL HEXAGON SOCKET HEAD BOLT (VALID UP TO MODEL YEAR 12-M6X12)	0 req
19	470260963	SHIELD GUARD PLATE	1 req	Avail to order Our Price: $426.23
20	470260081	BRACKET ARM	1 req	Avail to order Our Price: $134.19
21	N90737804	HEXALOBULAR SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M6X14.0)	3 req	Avail to order Our Price: $2.00
22	N90809103	O-RING 16X2-N SEAL RING	1 req	Current Stock: 9 Our Price: $3.01
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
