2016 AVENTADOR LP700-4 ROADSTER - ARABIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $40.12

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19

Sensors

PN	Item
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $924.67
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 411.01.00 - SUSPENSION

2016 Lamborghini AVENTADOR LP700-4 ROADSTER ARABIA SUSPENSION (411.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470412019P	SHOCK ABSORBER GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED (LIFTING SYSTEM)	2 req	Avail to order Our Price: $6,632.77
2	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. HEXAGON COLLAR NUT SELF-LOCKING (M12X1,5)	4 req	Avail to order Our Price: $2.52
3	N10682501	12-POINT SOCKET FL SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M8X50)	4 req	Current Stock: 6 Our Price: $2.80
4	N10428002	HEXAGON FLANGE HEX COLLARED BOLT (M12X1,5X80)	2 req	Avail to order Our Price: $6.46
5	N10628301	HEXAGON FLANGE BOLT HEX COLLARED BOLT (M12X1,5X90)	2 req	Avail to order Our Price: $6.89
6	470411309D	STABILIZER ANTI-ROLL BAR (FRONT)	1 req	Avail to order Our Price: $376.00
7	420411031A	STABILIZER MOUNTIN ANTI-ROLL BAR BEARING BRACKET	2 req	Avail to order Our Price: $26.05
8	4D0411336G	CLIP CLAMP	2 req	Current Stock: 1 Our Price: $5.53
9	4D0411327J	RUBBER MOUNTING RUBBER BUSH (29MM)	2 req	Current Stock: 1 Our Price: $13.64
10	470411317C	CONNECTING LINK COUPLING ROD (LEFT)	1 req	Avail to order Our Price: $105.20
10	470411318C	COUPLING ROD COUPLING ROD (RIGHT)	1 req	Avail to order Our Price: $105.20
11	470413127	LEVER ARM OUTRIGGER	2 req	Avail to order Our Price: $1,304.51
12		WHEEL BEARING HOUSING (SEE ILLUSTRATION :- 407-020)	0 req
13		WISHBONE (SEE ILLUSTRATION :-UPPER 407-010)	0 req
14		WISHBONE (SEE ILLUSTRATION :-LOWER 407-010)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
