2014 AVENTADOR LP700-4 ROADSTER - JAPAN

Group :

Tav :

Maintenance Parts:

Common repairs and upgrades

PN	Item
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Current Stock: 14 Our Price: $71.47
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $58.32
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $27.66
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 6 Our Price: $61.26

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 9 Our Price: $201.60

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $157.26
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $42.69

Ignition

PN	Item	Diagram
470905619C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $100.13
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $99.97

Misc

PN	Item
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $61.49

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $153.21
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $79.44
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62
470998161	COLD JOINT KIT SET OF TWO 470919197C	Avail to order Our Price: $935.21

Tools and Tookits

PN	Item
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 93 Our Price: $15.26
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $314.66
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $474.62
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $434.20
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $611.31

Open All

Select Group and TAV

< Previous Next >

TAV: 251.03.00 - EXHAUST SYSTEM

2014 Lamborghini AVENTADOR LP700-4 ROADSTER JAPAN EXHAUST SYSTEM (251.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10433701	SPEED NUT CLIP	12 req	Current Stock: 4 Our Price: $1.60
2	470825709B	HEAT SHIELD,REAR HEAT SHIELD	1 req	Avail to order Our Price: $4,168.53
3	N10680201	DUO HEXAGON FLANGE BOLT SCREW M10X75	2 req	Avail to order Our Price: $3.89
4	N10005207	HEX. BOLT WITH SCREW M8X18	4 req	Avail to order Our Price: $8.23
5	470251303C	SUSPENSION SUPPORT	2 req	Avail to order Our Price: $113.09
6	7L0253144B	SUSPENSION SUPPORT	2 req	Avail to order Our Price: $57.92
7	N0195307	HEXAGON FLANGE SCREW M8X25	4 req	Avail to order Our Price: $3.27
8	470251051D	MUFFLER SILENCER WITH CATALYST	1 req	Avail to order Our Price: $11,187.37
9	N91032702	HEXALOBULAR SOCKET FLANGE BOLT SCREW M6X20	4 req	Current Stock: 6 Our Price: $1.90
10	470253697C	TRIM,TAIL PIPE EXHAUST TERMINALS COVER	1 req	Avail to order Our Price: $712.91
11	N90780903	SOCKET SCREW SCREW M6X16	2 req	Current Stock: 1 Our Price: $1.10
12	420251143	CLAMP CLIP	2 req	Avail to order Our Price: $96.80
13	470131850	HOSE PIPE	2 req	Avail to order Our Price: $123.01
14	470971796	BRACKET LH BRACKET	1 req	Avail to order Our Price: $29.31
14	470971806A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $67.39
15	470131849	HOSE PIPE	2 req	Avail to order Our Price: $122.57
16	059906051A	PRESSURE SENSOR SENSOR	2 req	Current Stock: 4 Our Price: $136.29
17	3C0131483A	CLIP CLAMP	4 req	Avail to order Our Price: $3.89
18	N10569501	HEXALOBULAR SOCKET SCREW M5X16	2 req	Avail to order Our Price: $2.39
19	3C0131483	CLIP CLAMP	4 req	Avail to order Our Price: $3.63
20	N10637302	HEXALOBULAR SOCKETFLANGE BOLT SCREW M5X20	2 req	Current Stock: 8 Our Price: $1.10
21	470825613B	HEAT SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $2,953.39
22	N90775001	FLANGE TAPPING SCREW ST4,8X16	12 req	Current Stock: 3 Our Price: $2.12
23		CROSS MEMBER (SEE TABLE 701.03.00)	0 req
24		REAR BUMPER (SEE TABLE 701.04.00)	0 req
25	470825497	DIFFUSER HEAT SHIELD	1 req	Avail to order Our Price: $265.15
26	470825981	SPACER SPACER	2 req	Avail to order Our Price: $23.20
27	WHT001942	WASHER WASHER	4 req	Current Stock: 13 Our Price: $3.45
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
