2013 AVENTADOR LP700-4 ROADSTER - USA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $40.12

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19

Sensors

PN	Item
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $924.67
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 915.01.00 - BATTERY - BATTERY MOUNTING

2013 Lamborghini AVENTADOR LP700-4 ROADSTER USA BATTERY - BATTERY MOUNTING (915.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	6R0915105A	SEE PN 5GM915105AE BATTERY 58AH/340A	1 req	Avail to order Our Price: $735.22
2	8D0803123A	CLAMPING STRIP BRACKET	2 req	Avail to order Our Price: $4.38
3	N10347804	HEXALOBULAR SOCKET SCREW M8X20	2 req	Current Stock: 8 Our Price: $2.00
4	8K0915429C	POLE COVER COVER CAP	1 req	Avail to order Our Price: $11.48
5	4F0915531	TUBE CORRUGATED PIPE	1 req	Avail to order Our Price: $9.26
6	1K0971813F	COVER COVER CAP NEGATIVE CONTACT	1 req	Avail to order Our Price: $3.23
7	8X0915181	BATTERY MANAGEMENT CONTROL UNIT FOR BATTERY MONITORING	1 req	Avail to order Our Price: $278.41
8	N91048802	12-POINT SOCKET SCREW M8X20	1 req	Current Stock: 9 Our Price: $3.09
9	470971417	CABLE BOX SUPERCAP ULTRACAPACITOR POWER BOX (START - STOP)	1 req	Avail to order Our Price: $4,026.77
10	470803123	CLAMPING STRIP BRACKET	1 req	Avail to order Our Price: $44.49
11	N10664901	12-POINT SOCKET SCREW M8X20	2 req	Current Stock: 18 Our Price: $3.01
12	470971013	HARNESS SUPERCAP WIRING HARNESS	1 req	Avail to order Our Price: $107.21
13	470971008	HARNESS SUPERCAP WIRING HARNESS	1 req	Avail to order Our Price: $464.98
14		WIRING HARNESS (SEE TABLE 971.03.00)	0 req
15	N10609201	HEXAGON FLANGE NUT NUT M8	3 req	Current Stock: 11 Our Price: $2.15
16	470971250	GROUND STRAP WIRING HARNESS	1 req	Avail to order Our Price: $284.87
17	470972899A	PROTECTIVE CAP ULTRACAPACITOR COVER	1 req	Avail to order Our Price: $51.74
18	N10653201	HEXAGON FLANGE SCREW M6x16	1 req	Current Stock: 12 Our Price: $2.01
19	410905131	BRACKET BRACKET	1 req	Avail to order Our Price: $27.92
20	8J0915459	FUSE FUSE HOLDER BOX	1 req	Avail to order Our Price: $239.66
21	N90295502	HEXAGON FLANGE NUTM8 NUT M8	1 req	Avail to order Our Price: $2.15
22	N10424905	FUSE STRIP 110A FUSE	3 req	Avail to order Our Price: $6.03
23	N90488005	HEXAGON NUT W. M6 NUT M6	3 req	Avail to order Our Price: $2.06
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
