2013 AVENTADOR LP700-4 ROADSTER - ARABIA

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.85
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.44
4T0803615	Towing Eye TOWING EYE previous part number 400803615	Avail to order Our Price: $47.87

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Avail to order Our Price: $104.15

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $41.62
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.08

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item	Diagram
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER		Current Stock: 2 Our Price: $65.70
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $999.38
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 12 Our Price: $154.84
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $356.21
69195290	Tool kit for removing the grille Tool kit for removing the grille LP700 Bumper Net Tool	Avail to order Our Price: $389.40
61195080	TOOL FOR TOP DEAD CENTER LP700 SUPER DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $258.12

Open All

Select Group and TAV

< Previous Next >

TAV: 260.01.00 - AIR CONDITIONING SYSTEM

2013 Lamborghini AVENTADOR LP700-4 ROADSTER ARABIA AIR CONDITIONING SYSTEM (260.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470260401A	CONDENSER A/C CONDENSER	1 req	Avail to order Our Price: $1,055.54
2	N90942301	HOLDING CLIP CLAMP	1 req	Avail to order Our Price: $10.94
3	N10347204	HEXALOBULAR SOCKET SCREW M6X25	3 req	Avail to order Our Price: $2.53
4	N01508213	HEXAGON FLANGE NUT NUT M6	1 req	Current Stock: 4 Our Price: $2.00
5	N10569501	HEXALOBULAR SOCKET SCREW M5X16	4 req	Avail to order Our Price: $2.39
6	N10451408	HEXALOBULAR SOCKET SCREW M6X16	4 req	Avail to order Our Price: $2.00
7	N91096701	HEXALOBULAR SOCKET SCREW M6X16	2 req	Current Stock: 8 Our Price: $2.00
8	4E0260749B	seal ring SEAL RING 13,7X2,5	2 req	Current Stock: 2 Our Price: $6.03
9	7H0820896	O-RING SEAL RING 7,6X1,82	1 req	Avail to order Our Price: $5.81
10	470260702D	REFRIGERANT LINE PIPE	1 req	Avail to order Our Price: $345.39
11	470260701B	REFRIGERANT LINE PIPE	1 req	Avail to order Our Price: $424.30
12	4E0260749A	seal ring SEAL RING 11X2,5	1 req	Current Stock: 7 Our Price: $6.55
13	8E0260749C	seal ring SEAL RING 23,8X2,4	1 req	Current Stock: 4 Our Price: $5.52
14	470260709C	REFRIGERANT LINE PIPE	1 req	Avail to order Our Price: $1,950.28
15	470201809	BRACKET BRACKET	1 req	Avail to order Our Price: $36.11
16	4H0959126A	AC PRESSURE SENSOR PRESSURE SENSOR	1 req	Avail to order Our Price: $80.25
17	N0206405	HOLDING CLIP CLAMP	1 req	Avail to order Our Price: $2.17
18	N10414402	HEXALOBULAR SOCKET SCREW M8X28	2 req	Avail to order Our Price: $3.28
19		SEAL RING 14X2 (CANNOT BE SOLD SEPARATELY - SEE REF. 14)	0 req
20		FUEL COOLER (CANNOT BE SOLD SEPARATELY - SEE REF. 14)	0 req
21	470260427A	BRACKET LH BRACKET	1 req	Avail to order Our Price: $42.81
22	470260428A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $42.81
23		COMPRESSOR (SEE TABLE 145.02.00)	0 req
24		PIPE (SEE TABLE 260.02.00)	0 req
25		PIPE (SEE TABLE 260.02.00)	0 req
26	470260761	BRACKET BRACKET	1 req	Avail to order Our Price: $41.09
27	N91032702	HEXALOBULAR SOCKET FLANGE BOLT SCREW M6X20	1 req	Current Stock: 6 Our Price: $2.00
28	3W0971838	CABLE TIE CLAMP	1 req	Avail to order Our Price: $2.00
29	N10562301	CLAMP CLAMP	2 req	Avail to order Our Price: $2.00
30	470260423	SEAL FOAM SEALING	2 req	Avail to order Our Price: $54.79
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
