2010 MURCIELAGO SV LP 670-4 - USA

Maintenance Parts:

Belts

PN	Item	Diagram
07M903137A	RIBBED V-BELT RIBBED V-BELT		Avail to order Our Price: $103.88

Brakes

PN	Item	Diagram
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes		Avail to order Our Price: $839.54
410798041A	Brake Pad Set Rear Carboceramic - Murcielago Brake Pad Set Rear Carboceramic - Murcielago Sold as 2 pair for both rear rotors.		Avail to order Our Price: $1,254.62

Drivetrain

PN	Item
07M105269	MURCIELAGO LP640/670 CLUTCH (MANUAL AND EGEAR) BALANCED MECHANISM CLUTCH MURCIELAGO LP640 CLUTCH (MANUAL AND EGEAR)	Avail to order Our Price: $7,620.37
07M115561	see PN 07M115561B Oil Filter Cartridge	Avail to order Our Price: $48.56
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C	Avail to order Our Price: $812.27
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,037.84
410721401A	MASTER CYLINDER 2008 and Up MASTER CYLINDER	Avail to order Our Price: $379.37
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO	Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item
07M133843A	Air Filter - SPORT PERFORMANCE FILTER Performance filter replacement for 07M133843 Air Filter - Murcielago SV LP 670-4	Avail to order Our Price: $733.78
07M906031A	INJECTOR INJECTOR	Avail to order Our Price: $228.19
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $274.81
410805396	FILTER BOX Please Check your Part Manual for a Description	Current Stock: 1 Our Price: $141.50
410820367A	PARTICULATE FILTER PARTICULATE FILTER	Current Stock: 2 Our Price: $67.20

Fuses-Bulbs-Relays

PN	Item
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
410953227B	RELAY RELAY	Avail to order Our Price: $361.65
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
N10445601	SEE PN N10445602 Headlight BULB H21W-12V21W	Avail to order Our Price: $26.91
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $5.89
N0177532	LAMP BULB LAMP BULB	Avail to order Our Price: $2.00
N10445703	HEADLIGHT BULB D2SLL-12V35W Please Check your Part Manual for a Description	Current Stock: 8 Our Price: $188.49

Gaskets

PN	Item	Diagram
0R1470106	GEAR BOX SUPPORT-GASKET SET GEAR BOX SUPPORT		Avail to order Our Price: $4,032.63
600940141L	latch Gasket Left latch Gasket Set Left This is the rubber/plastic gasket that is located on the Left side between the outer door latch and the door frame		Current Stock: 5 Our Price: $23.40

Ignition

PN	Item
410905619	Spark Plug All Murcielgos Spark Plug - Murcielago, Murcielago LP640 - LP 670-4 - Reventon Sold Each	Current Stock: 2 Our Price: $51.23
7L0915105	See pn 000915105CC Battery Varta 12V 68 Ah 38A DIN	Avail to order Our Price: $820.11
07M905115B	IGNITION COIL IGNITION COIL	Current Stock: 1 Our Price: $174.37

Misc

PN	Item
0R1470029	TRANSPARENT ENGINE BONNET KIT 2002-2010 Murcielago Coupe TRANSPARENT ENGINE BONNET KIT FOR 2002-2010 Murcielago Coupe INCLUDES 418827023A TRUNK LID x 1 418827401 gas spring x 2 418827631A Glass bonnet x 1 418827632A Glass bonnet x 1 418827651 PROFILE SEAL x 2 418827652 PROFILE SEAL x 2 895827439B BALL PINN x 2 410827602 SHOCK ABSORBER FASTENING BRACKET x 1 410827601 SHOCK ABSORBER FASTENING BRACKET x 1 418827322A HOOK x 1 N90319404 HEXAGON FLANGE x 7 WHT003407 WASHER x 7	Avail to order Our Price: $10,291.83
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19

Sensors

PN	Item
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $144.23
410919529	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 3 Our Price: $383.18
410919529A	TEMPERATURE SENSOR - MURCIELAGO TEMPERATURE SENSOR	Avail to order Our Price: $368.82
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $350.89
036906262J	LAMBDA PROBE Please Check your Part Manual for a Description	Avail to order Our Price: $423.36
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $36.53
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $858.19
07M905381	Phase Sensor Phase Sensor	Avail to order Our Price: $658.83
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $479.33
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $121.99
1K2945511	SWITCH,BRAKE PEDAL SWITCH,BRAKE PEDAL	Avail to order Our Price: $27.42
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $118.98
400907475A	PEDAL VALUE (Potentiometer) PEDAL VALUE	Avail to order Our Price: $1,858.46

Open All

Select Group and TAV

< Previous Next >

TAV: 141.02.00 - CLUTCH (E-GEAR)

2010 Lamborghini MURCIELAGO SV LP 670-4 USA CLUTCH (E-GEAR) (141.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Murcielago Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		WASHER (VALID UP TO MODEL YEAR 09)	0 req
2		SEAL RING (VALID UP TO MODEL YEAR 09)	0 req
3		HELI-COIL (VALID UP TO MODEL YEAR 09)	0 req
4	N01100845	HEX.NUT NUT	10 req	Current Stock: 16 Our Price: $1.94
5	WHT000771	SPRING LOCK WASHER WASHER	16 req	Current Stock: 10 Our Price: $2.00
6	1J0615273	BREATHER SCREW BLEEDER SCREW	1 req	Avail to order Our Price: $23.54
7	086301147	BOOT BOOT	1 req	Current Stock: 23 Our Price: $2.00
8	086323173C	CONNECTING PART CONNECTOR	1 req	Avail to order Our Price: $132.03
9	WHT002219	o-ring SEAL RING	1 req	Avail to order Our Price: $4.89
10	086323209K	CLUTCH HOUSING CLUTCH HOUSING	1 req	Avail to order Our Price: $3,257.67
11	WHT003027	TAP END STUD STUD BOLT M8X35	11 req	Avail to order Our Price: $9.26
12	WHT002942	TAP END STUD STUD BOLT M6X18	3 req	Avail to order Our Price: $10.98
13	WHT003213	SPRING LOCK WASHER WASHER	3 req	Avail to order Our Price: $2.00
14	N01100637	HEX.NUT NUT	2 req	Current Stock: 18 Our Price: $2.00
15		WASHER (VALID UP TO MODEL YEAR 09)	0 req
16		ANTIROTATION BAR HOLD (VALID UP TO MODEL YEAR 09)	0 req
17	07M105269	MURCIELAGO LP640/670 CLUTCH (MANUAL AND EGEAR) BALANCED MECHANISM CLUTCH	1 req	Avail to order Our Price: $7,620.37
18	WHT003078	Reference Pin 8h7x16C40 DOWEL	1 req	Avail to order Our Price: $17.16
19	410141179	RETAINING PART PLATE	4 req	Avail to order Our Price: $63.72
20	WHT002951	HEXAGON HEAD BOLT SCREW M8X1,25X23	8 req	Avail to order Our Price: $18.94
21	WHT002944	TAP END STUD STUD BOLT M8X50	2 req	Avail to order Our Price: $16.73
22	WHT003166	TAP END STUD STUD BOLT M8X40	1 req	Avail to order Our Price: $50.59
23	086141671L	THROW OUT BEARING - EGEAR THRUST BEARING	1 req	Avail to order Our Price: $2,037.84
24	WHT002218	o-ring SEAL RING	1 req	Current Stock: 42 Our Price: $4.31
25	N90111302	o ring SEAL RING	1 req	Current Stock: 18 Our Price: $2.00
26	086311819	Oil Seal 36x52x7 mm SEAL RING	1 req	Current Stock: 8 Our Price: $54.97
27	WHT003580	Check Part Manual RETAINING RING	1 req	Avail to order Our Price: $15.22
28	410911085A	BRACKET BRACKET	1 req	Avail to order Our Price: $27.06
29	086323179A	CONNECTION TUBE HOSE	1 req	Avail to order Our Price: $228.19
30	191611715	HOSE SUPPORT PLATE	1 req	Current Stock: 5 Our Price: $2.01
31		BLOCK (VALID UP TO MODEL YEAR 09)	0 req
32		SCREW (VALID UP TO MODEL YEAR 09)	0 req
33	086325274A	QUICK COUPLING CONNECTOR	1 req	Avail to order Our Price: $1,829.76
34	086141305	clutch sensor support SUPPORT	1 req	Avail to order Our Price: $58.34
35	086141297	CLUTCH SENSOR CLUTCH SENSOR	1 req	Avail to order Our Price: $479.33
36	N10421101	CYLINDRIC PIN M6X20 PIN	2 req	Current Stock: 16 Our Price: $2.00
37	N10295402	PAN HEAD BOLT WITH SCREW	2 req	Current Stock: 7 Our Price: $2.66
38	N90659905	HEXALOBULAR SOCKET SCREW	2 req	Avail to order Our Price: $9.69
39	410972846	CLIP SUPPORT	2 req	Avail to order Our Price: $2.00
40	086323131A	SUPPORT BRACKET	1 req	Avail to order Our Price: $57.99
41	N91065401	12-POINT SOCKETFLANGE BOLT SCREW	2 req	Avail to order Our Price: $2.00
43	N10124306	HEXALOBULAR SOCKET SCREW M6X20	3 req	Current Stock: 4 Our Price: $2.00
44	086323961	SEALING PLUG PLUG	1 req	Avail to order Our Price: $49.22
45	N0160276	SCREW M14X1.5 DIN908 PLUG	1 req	Avail to order Our Price: $6.96
46	N0138302	washer WASHER	1 req	Current Stock: 17 Our Price: $3.23
47	N0138494	SEE PN N0138495 WASHER	1 req	Current Stock: 1 Our Price: $5.96
48	086323179	PIPE PIPE	1 req	Current Stock: 2 Our Price: $162.89
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
