2021 Lamborghini HURACAN EVO COUPE USA CERAMIC BRAKE DISC (615.01.00)

Maintenance Parts:

Tools and Tookits

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Open All

Select Group and TAV

< Previous Next >

TAV: 615.01.00 - CERAMIC BRAKE DISC

2021 Lamborghini HURACAN EVO COUPE USA CERAMIC BRAKE DISC (615.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4S0615301A	BRAKE DISK KERAMIK CERAMIC BRAKE DISC (VENTED) (380X38MM 5/112 LEFT FRONT)	1 req	Avail to order Our Price: $7,519.92
1	4S0615302A	BRAKE DISK KERAMIK CERAMIC BRAKE DISC (VENTED) (RIGHT FRONT)	1 req	Avail to order Our Price: $7,519.92
1	4T0615301	BRAKE DISK ANT. CERAMIC BRAKE DISC (VENTED) (MONOLOCK WHEELS-LEFT FRONT)	1 req	Avail to order Our Price: $9,536.23
1	4T0615302	BRAKE DISK ANT. CERAMIC BRAKE DISC (VENTED) (MONOLOCK WHEELS-RIGHT FRONT)	1 req	Avail to order Our Price: $9,536.23
2	N10648301	HEXALOBULAR SOCKET HEX SOCKET COUNTERSUNK BOLT (M6X16)	2 req	Avail to order Our Price: $2.00
3	4T0615105DH	PCCB FRONT BRAKE CALIPER GREEN ADP BRAKE CALIPER HOUSING (AD PERSONAM-LEFT VERDE SCANDAL)	1 req	Avail to order Our Price: $6,271.38
3	4T0615105DJ	Pccb Front Brake Caliper Blu Adp BRAKE CALIPER HOUSING (AD PERSONAM-LEFT BLUE)	1 req	Avail to order Our Price: $5,209.41
3	4T0615105DN	BRAKE CALIPER CSIC SCHW.CU FREI BRAKE CALIPER HOUSING (LEFT BLACK)	1 req	Avail to order Our Price: $3,451.42
3	4T0615105DP	BRAKE CALIPER CSIC GELB CU FREI BRAKE CALIPER HOUSING (LEFT YELLOW)	1 req	Avail to order Our Price: $3,609.27
3	4T0615105DQ	BRAKE CALIPER CSIC SILB.CU FREI BRAKE CALIPER HOUSING (LEFT GREY)	1 req	Avail to order Our Price: $3,630.80
3	4T0615105DR	BRAKE CALIPER CSIC ORAN.CU FREI BRAKE CALIPER HOUSING (LEFT ORANGE)	1 req	Avail to order Our Price: $3,623.62
3	4T0615105DS	BRAKE CALIPER CSIC ROT CU FREI BRAKE CALIPER HOUSING (LEFT RED)	1 req	Avail to order Our Price: $3,623.62
3	4T0615105DT	BRAKE CALIPER CSIC GRUEN CU FREI BRAKE CALIPER HOUSING (LEFT VERDE MANTIS)	1 req	Avail to order Our Price: $3,688.21
3	4T0615105EA	BRAKE CALIPER HOUSING (LEFT WHITE)	1 req
3	4T0615106DH	PCCB FRONT BRAKE CALIPER GREEN ADP BRAKE CALIPER HOUSING (AD PERSONAM-RIGHT VERDE SCANDAL)	1 req	Avail to order Our Price: $6,271.38
3	4T0615106DJ	Pccb Front Brake Caliper Blu Adp BRAKE CALIPER HOUSING (AD PERSONAM-RIGHT BLUE)	1 req	Avail to order Our Price: $5,209.41
3	4T0615106DN	BRAKE CALIPER CSIC SCHW.CU FREI BRAKE CALIPER HOUSING (RIGHT BLACK)	1 req	Avail to order Our Price: $3,444.24
3	4T0615106DP	BRAKE CALIPER CSIC GELB CU FREI BRAKE CALIPER HOUSING (RIGHT YELLOW)	1 req	Avail to order Our Price: $3,602.10
3	4T0615106DQ	BRAKE CALIPER CSIC SILB.CU FREI BRAKE CALIPER HOUSING (RIGHT SILVER)	1 req	Avail to order Our Price: $3,623.62
3	4T0615106DR	BRAKE CALIPER CSIC ORAN.CU FREI BRAKE CALIPER HOUSING (RIGHT ORANGE)	1 req	Avail to order Our Price: $3,609.27
3	4T0615106DS	BRAKE CALIPER CSIC ROT CU FREI BRAKE CALIPER HOUSING (RIGHT RED)	1 req	Avail to order Our Price: $3,609.27
3	4T0615106DT	BRAKE CALIPER CSIC GRUEN CU FREI BRAKE CALIPER HOUSING (RIGHT VERDE MANTIS)	1 req	Avail to order Our Price: $3,673.86
3	4T0615106EA	BRAKE CALIPER HOUSING (RIGHT WHITE)	1 req
4	4S0615437B	WIRING HARNESS SENSOR CONTACTS (FRONT)	1 req	Avail to order Our Price: $86.97
5	4S0611845H	BRACKET,BRAKE HOSEMSS BRACKET (LEFT)	1 req	Avail to order Our Price: $12.21
5	4S0611846H	BRACKET,BRAKE HOSEMSS BRACKET (RIGHT)	1 req	Avail to order Our Price: $12.21
6	4S0611707F	BRAKE HOSE MSS BRAKE HOSE (FRONT)	2 req	Avail to order Our Price: $108.21
7	4S0611841H	BRACKET BRACKET (LEFT FRONT)	1 req	Avail to order Our Price: $12.21
7	4S0611842H	BRACKET BRACKET (RIGHT FRONT)	1 req	Avail to order Our Price: $12.21
8	4S0611847K	BRACKET,BRAKE HOSELI.SEITE MSS RETAINER FOR BRAKE HOSE (LEFT FRONT)	1 req	Avail to order Our Price: $7.47
8	4S0611848K	BRACKET,BRAKE HOSERE.SEITE MSS RETAINER FOR BRAKE HOSE (RIGHT FRONT)	1 req	Avail to order Our Price: $7.47
9	4S0698151M	1 SET OF BRAKE PADS FOR DISC 1 SET OF BRAKE PADS FOR DISK BRAKE (380X38MM FRONT)	1 req	Avail to order Our Price: $889.76
10	N10572403	TRIPLE SQUARE BOLTM8X16 SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK. (M8X16)	4 req	Avail to order Our Price: $2.95
11	N0902619	HEX. BOLT WITH HEXAGON HEAD BOLT (COMBI) (M6X20)	1 req	Avail to order Our Price: $1.94
12	N90692402	BLIND RIVET 4.8X11.3 POP RIVET (4,8X10)	1 req	Current Stock: 8 Our Price: $2.00
13	4E0927803F	SPEED SENSOR SPEED SENSOR (RIGHT)	1 req	Avail to order Our Price: $140.07
13	4E0927804F	SPEED SENSOR SPEED SENSOR (LEFT)	1 req	Current Stock: 1 Our Price: $140.07
14	WHT001330A	HEXAGON SOCKET SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M12X1,5X77X30)	4 req	Current Stock: 3 Our Price: $13.93
15	N10406504	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X12)	2 req	Avail to order Our Price: $2.00
16	4S0615311	COVER MSS COVER PLATE FOR BRAKE DISC (LEFT)	1 req	Avail to order Our Price: $50.09
16	4S0615312	COVER MSS COVER PLATE FOR BRAKE DISC (RIGHT)	1 req	Avail to order Our Price: $50.09
17	N01474011	PAN HEAD BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M6X16)	2 req	Avail to order Our Price: $2.30
18	0R1400210	Caliper spring set 1 SET SPRINGS (4 SPRINGS FOR KIT)	1 req	Current Stock: 5 Our Price: $43.97
19	4T0698010	Ceramic Brake Pad Kit 1 SET DOUBLE-SIDED ADHESIVE TAPE	1 req	Avail to order Our Price: $116.39
20	211611483	DUST CAP DUST CAP	2 req	Avail to order Our Price: $5.89
21	8A0615273	BLEEDER SCREW BREATHER VALVE	2 req	Avail to order Our Price: $16.79
22	4S0698269A	1 SET OF SECURING PARTS 1 SET ATTACHMENT PARTS	2 req	Avail to order Our Price: $109.36
23		AXLE SHAFT (SEE ILLUSTRATION : 407.01)	0 req
24	4E0698507	REPAIR KIT SET OF GASKETS FOR BRAKE CALIPER HOUSING	2 req	Avail to order Our Price: $81.67
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
