2020 HURACAN EVO SPYDER 2WD - EUROPE

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35

Common repairs and upgrades

PN	Item
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0823359	GAS SPRING GAS SPRING	Current Stock: 2 Our Price: $82.49
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Current Stock: 7 Our Price: $89.92
1K0906283A	EGR VALVE ELECTR.CHANGEOVER EGR VALVE	Current Stock: 3 Our Price: $72.36

Fuel-Air

PN	Item
4T0133843	FILTER ELEMENT FILTER ELEMENT FILTER ELEMENT	Avail to order Our Price: $477.90
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28
4s0819439	Filter Element Filter Element	Current Stock: 6 Our Price: $104.52
07L127025S	FUEL PUMP FUEL PUMP	Avail to order Our Price: $695.26

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item	Diagram
0BZ911024D	STARTER STARTER		Current Stock: 1 Our Price: $1,307.14

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ml CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
4S0906262F	LAMBDA PROBE BACK RIGHT O2 SENSOR LAMBDA PROBE LSU 4.9	Current Stock: 1 Our Price: $571.69
4S0906262G	LAMBDA PROBE BACK LEFT O2 SENSOR LAMBDA PROBE LSU 4.9	Current Stock: 1 Our Price: $343.91
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $373.98

Open All

Select Group and TAV

< Previous Next >

TAV: 121.05.00 - COOLER FOR COOLANT

2020 Lamborghini HURACAN EVO SPYDER 2WD EUROPE COOLER FOR COOLANT (121.05.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4S0121403B	EXPANSION TANK RESERVOIR	1 req	Avail to order Our Price: $256.82
2	4S7121321	COVER AGB SPYDER END CAP	1 req	Avail to order Our Price: $138.90
3	4S0121212B	AUXILIARY RADIATORIM SIDEBLADE RE. ADDITIONAL COOLER FOR COOLANT (RIGHT)	1 req	Avail to order Our Price: $378.15
4	4S0121256B	BRACKET ZWK IM SIDEBLADE BRACKET FOR ADDITIONAL COOLANT RADIATOR	1 req	Avail to order Our Price: $16.46
5	4S0121106A	COOLANT HOSE AGB BEFUELLSCHL. COOLANT HOSE	1 req	Avail to order Our Price: $45.27
6	4S0121275B	BEARING KUEHLER RUBBER BUSH	4 req	Avail to order Our Price: $41.25
7	4S0121081L	COOLANT HOSE HWK BREATHER LINE	1 req	Avail to order Our Price: $41.99
8		RETAINING BASE (CANNOT BE SOLD SEPARATELY - INCLUDED IN REAR PANEL)	0 req
9	4S0121214C	BRACKET AGB ADAPTER RETAINER FOR RESERVOIR	1 req	Avail to order Our Price: $118.36
10	4S0121081N	COOLANT HOSE ZWK SB RE BREATHER LINE (RIGHT)	1 req	Avail to order Our Price: $38.41
11		COOLANT PIPE (SEE ILLUSTRATION : 121.03)	0 req
12		COOLANT PIPE (SEE ILLUSTRATION : 121.04)	0 req
13	4T0121694C	AIR DUCT ELEMENT TEIL WATER RH FL AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $73.50
14	4T0121694	AIR DUCT ELEMENT AIR GUIDE (RIGHT)	1 req	Avail to order Our Price: $89.76
15	N90731503	SCREW HEXAGON SOCKET HEAD PANEL BOLT (6X25)	1 req	Avail to order Our Price: $2.00
16	N91184901	NLA (No Longer Available) SPRING BAND CLAMP (14X12)	2 req	*See Description
17	N91096801	HEXALOBULAR SOCKET HEXAGON SOCKET FLAT HEAD BOLT (M6X20)	1 req	Current Stock: 6 Our Price: $2.00
18	N91069601	HEXALOBULAR SOCKETM6X22 HEXAGON SOCKET FLAT HEAD BOLT (M6X22)	1 req	Current Stock: 14 Our Price: $2.00
19	N91096701	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	2 req	Current Stock: 8 Our Price: $2.00
20	14	WASHER (6,2X24X2)	0 req
21		COOLANT PIPE (INCLUDED IN REF. 7)	1 req
22	4H0121585	GROMMET RUBBER BUSH	1 req	Avail to order Our Price: $2.39
23	N90687001	SPRING CLAMP SPRING BAND CLAMP (27X12)	2 req	Avail to order Our Price: $8.12
24		HOSE CONNECTOR (NO PART - VALID FOR COUPÈ MODEL)	0 req
25	7L6121099	PLUG BUNGS	1 req	Avail to order Our Price: $16.75
26	N90686701	SPRING CLAMP SPRING BAND CLAMP (14X12)	3 req	Avail to order Our Price: $2.09
27	4S0122449B	COOLANT HOSE Y-ENTLUEFT. AM AGB VENT HOSE	1 req	Avail to order Our Price: $31.20
28		COOLANT HOSE (NO PART - VALID FOR COUPE MODEL)	0 req
29	07L121086G	COOLANT HOSE VENT HOSE	1 req	Avail to order Our Price: $72.21
30	07L133847	CLAMP HOSE BRACKET	1 req	Current Stock: 9 Our Price: $2.00
31	N10743901	SECURING PIN SWIVEL PIN	1 req	Avail to order Our Price: $3.51
32	N0206208	CLAMP CLAMP	1 req	Avail to order Our Price: $4.18
33	N10451408	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	1 req	Avail to order Our Price: $2.00
34	N10661002	HEXALOBULAR SOCKET HEX SOCKET OVAL HEAD COLLARED (M6X20)	2 req	Current Stock: 18 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
