![HURACAN EVO SPYDER 2WD](/content/ls/huracan.png?r=t&w=274&h=96")
| PN | Item | Diagram | ||
|---|---|---|---|---|
| 400093050D |
CTEK US-CD BATTERY CHARGER
Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month |
Avail to order
Our Price: $317.22
|
|
Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.
| Item # | PN | Item | Qty Req * | ||
|---|---|---|---|---|---|
| 1 | 4T0853533 |
SILL
SIDE MEMBER (PRIMER - SUPPLY VIN-LEFT) |
1 req |
Avail to order
Our Price: $2,167.00
|
|
| 2 | 4T0853534 |
SILL
SIDE MEMBER (PRIMER - SUPPLY VIN-RIGHT) |
1 req |
Avail to order
Our Price: $2,167.00
|
|
| 3 | 4T0807715B3FZ |
GRILLE
GRILLE (MATT BLACK - INCLUDED LEFT AND RIGHT-MATT BLACK) |
1 req |
Avail to order
Our Price: $1,276.61
|
|
| 3 | 4T0807715BY9B |
GRILLE
GRILLE (SHINY BLACK - INCLUDED LEFT AND RIGHT-BRILLIANT BLACK) |
1 req |
Avail to order
Our Price: $1,508.21
|
|
| 4 | 4T0853231A |
BRACKET
ARM (LEFT) |
1 req |
Avail to order
Our Price: $35.60
|
|
| 4 | 4T0853232A |
BRACKET
ARM (RIGHT) |
1 req |
Avail to order
Our Price: $35.60
|
|
| 5 | SEAL (SEE ILLUSTRATION : 853.05) | 1 req | |||
| 6 | COVER (SEE ILLUSTRATION : 853.05) | 1 req | |||
| 7 | 4T0853921A |
BRACKET,SILL PANEL
ARM (LEFT) |
1 req |
Avail to order
Our Price: $15.87
|
|
| 7 | 4T0853922A |
BRACKET,SILL PANEL
ARM (RIGHT) |
1 req |
Avail to order
Our Price: $15.87
|
|
| 8 | WING (SEE ILLUSTRATION : 821.01) | 1 req | |||
| 9 | SIDE PART (SEE ILLUSTRATION : 853.03) | 1 req | |||
| 10 | 420819181 |
ONE-WAY FLAP-TYPE INNEN
VENT TRIM |
2 req |
Avail to order
Our Price: $30.14
|
|
| 11 | 4T0853997B |
BRACKET CENTRAL SUPPORT
ARM (LEFT) |
1 req |
Avail to order
Our Price: $89.99
|
|
| 12 | 4T0853373C |
SCUFF PLATE
SILL TRIM STRIP (LEFT) |
1 req |
Avail to order
Our Price: $200.86
|
|
| 12 | 4T0853373E |
SCUFF PLATE
SILL TRIM STRIP (MATT CARBON LOOK-LEFT) |
1 req |
Avail to order
Our Price: $894.92
|
|
| 12 | 4T0853374C |
Scuff Plate RH (STD)
SILL TRIM STRIP (RIGHT) |
1 req |
Avail to order
Our Price: $200.86
|
|
| 12 | 4T0853374E |
SCUFF PLATE
SILL TRIM STRIP (MATT CARBON LOOK-RIGHT) |
1 req |
Avail to order
Our Price: $894.92
|
|
| 13 | 40 | OVAL HEXAGON SOCKET HEAD BOLT (M6X16) | 0 req | ||
| 14 | N01508210 |
HEXAGON FLANGE NUT
HEXAGON COLLAR NUT (M6) |
2 req |
Current Stock: 17
Our Price: $1.94
|
|
| 15 | 420853139 |
CLIP
CLIP |
1 req |
Avail to order
Our Price: $1.87
|
|
| 16 | N91137102 |
SNAP NUT CLAMP
SPEED NUT (M5X16.6X17.3 1-4MM) |
6 req |
Avail to order
Our Price: $2.00
|
|
| 17 | N10752901 |
HEXALOBULAR SOCKETM5X18
FILLISTER HD. BOLT (M5X18) |
6 req |
Avail to order
Our Price: $2.00
|
|
| 18 | WHT001197A |
WASHER
WASHER (12X6,4X0,5) |
2 req |
Current Stock: 2
Our Price: $2.00
|
|
| 19 | N90276701 |
SPEED NUT
SPEED NUT (4,8X14,25) |
2 req |
Avail to order
Our Price: $2.00
|
|
| 20 | N90688703 |
SNAP NUT CLAMP
SPEED NUT (M6X24X16) |
1 req |
Current Stock: 2
Our Price: $2.00
|
|
| 21 | 7M0867299K |
CLIP
CLIP |
2 req |
Avail to order
Our Price: $2.00
|
|
| 22 | N90276701 |
SPEED NUT
SPEED NUT (4,8X14,25) |
4 req |
Avail to order
Our Price: $2.00
|
|
| 23 | N10017304 |
HEXAGON FLANGE NUT
HEXAGON COLLAR NUT (M5) |
2 req |
Current Stock: 16
Our Price: $1.87
|
|
| 24 | 14 | SPEED NUT (4,2X16,3X11) | 0 req | ||
| 25 | 14 | HEXAGON SOCKET HEAD PANEL BOLT (ST4,2X16) | 0 req | ||
| 26 | CLIP (N 90495903) | 8 req | |||
| 27 | N90953004 |
HEXALOBULAR SOCKETM5X14
OVAL HEXAGON SOCKET HEAD BOLT |
8 req |
Avail to order
Our Price: $2.00
|
|
| 28 | 1 SET ATTACHMENT PARTS (4T0898054A) | 2 req | |||
| 29 | 4T0853998B |
BRACKET CENTRAL SUPP RH
ARM (RIGHT) |
1 req |
Avail to order
Our Price: $89.99
|
|
| 30 | 4T0853023 |
CONNECTING PART
BRACKET (LEFT) |
1 req |
Avail to order
Our Price: $31.72
|
|
| 30 | 4T0853024 |
CONNECTING PART
BRACKET (RIGHT) |
1 req |
Avail to order
Our Price: $33.66
|
|
| 31 | RADIATOR GRILLE (MATT BLACK - INCLUDED IN REF.36-LEFT) | 1 req | |||
| 31 | RADIATOR GRILLE (MATT BLACK - INCLUDED IN REF.36-RIGHT) | 1 req | |||
| 31 | RADIATOR GRILLE (PRIMER - INCLUDED IN REF.36-LEFT) | 1 req | |||
| 31 | RADIATOR GRILLE (PRIMER - INCLUDED IN REF.36-RIGHT) | 1 req | |||
| 32 | SEAL (SEE ILLUSTRATION : 804.02) | 0 req | |||
| 33 | GRILLE ( INCLUDED IN REF.36-LOWER) | 1 req | |||
| 34 | 1 SET OF FOAM STRIPS (TEMPORARY NOT AVAILABLE) | 1 req | |||
| 35 | 4T0898054E |
1 Set Of Securing Parts
1 SET ATTACHMENT PARTS |
1 req |
Avail to order
Our Price: $307.83
|
|
| 36 | 4T0807715AGRU |
GRILLE
GRILLE (PRIMER-PRIMER) |
1 req |
Avail to order
Our Price: $2,723.35
|
|
|
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts. |
|||||
