2020 Lamborghini HURACAN EVO COUPE USA CHASSIS (805.01.00)

Maintenance Parts:

Tools and Tookits

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $317.22

Open All

Select Group and TAV

< Previous Next >

TAV: 805.01.00 - CHASSIS

2020 Lamborghini HURACAN EVO COUPE USA CHASSIS (805.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	4T8813031K	REAR END ASSEMBLY FRAME (CONTACT YOUR AREA MANAGER-REAR ENGINE BAY)	1 req	Avail to order Our Price: $13,597.55
2	4S0813441F	REINFORCEMENT HECKRAHMEN REINFORCEMENT	1 req	Avail to order Our Price: $191.59
3	4T8817361D	ROOF FRAME,SIDE HINTEN SUPPORT (LEFT REAR)	1 req	Avail to order Our Price: $112.09
3	4T8817362D	ROOF FRAME,SIDE HINTEN SUPPORT (RIGHT REAR)	1 req	Avail to order Our Price: $112.09
4	4T8810243F	WAIST RAIL CARRIER SUPPORT (LEFT UPPER)	1 req	Avail to order Our Price: $111.95
4	4T8810244F	DOOR WAIST RAIL SUPPORT (CONTACT YOUR AREA MANAGER-RIGHT UPPER)	1 req	Avail to order Our Price: $156.43
5	4T0813499B	ADAPTER TRAEGERTEIL ADAPTER (LEFT)	1 req	Avail to order Our Price: $22.46
5	4T0813500B	ADAPTER TRAEGERTEIL ADAPTER (RIGHT)	1 req	Avail to order Our Price: $16.79
6	4T8814201E	SUPPORT LTR VORNE UNTEN SUPPORT (CONTACT YOUR AREA MANAGER-LEFT LOWER)	1 req	Avail to order Our Price: $149.98
6	4T8814202D	SUPPORT LTR VORNE UNTEN SUPPORT (CONTACT YOUR AREA MANAGER-RIGHT LOWER)	1 req	Avail to order Our Price: $149.98
7		CROSS MEMBER (CANNOT BE SOLD SEPARATELY)	0 req
8		CROSS MEMBER (CANNOT BE SOLD SEPARATELY)	0 req
9	4S0813253D	REINFORCEMENT SAEULE B DIFF INNE REINFORCEMENT (CONTACT YOUR AREA MANAGER-LEFT)	1 req	Avail to order Our Price: $79.94
9	4S0813254B	REINFORCEMENT SAEULE B DIFF INNE REINFORCEMENT (CONTACT YOUR AREA MANAGER-RIGHT)	1 req	Avail to order Our Price: $79.94
10	4T0810251B	CARRIER CARRIER (LEFT)	1 req	Avail to order Our Price: $68.81
10	4T0810252B	CARRIER CARRIER (RIGHT)	1 req	Avail to order Our Price: $65.95
11	4T0810439B	RH BRACKET BRACKET (LEFT)	1 req	Avail to order Our Price: $22.46
11	4T0810440B	LH BRACKET BRACKET (RIGHT)	1 req	Avail to order Our Price: $22.46
12	N91097301	SCREW HEXAGON SOCKET FLAT HEAD BOLT (M6X45)	8 req	Avail to order Our Price: $2.01
13	4S0813857B	CRASH REINF. HINTERWAGEN REINFORCEMENT (CONTACT YOUR AREA MANAGER)	1 req	Avail to order Our Price: $191.59
14	4T0813483C	ADAPTER QTR GETRIEBE SUPPORT (CONTACT YOUR AREA MANAGER)	1 req	Avail to order Our Price: $154.28
15	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6)	4 req	Current Stock: 17 Our Price: $1.94
16	N91128001	12-POINT SOCKET M8X25 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M8X25)	4 req	Avail to order Our Price: $2.00
17	N10683301	DUO HEXAGON FLANGEAM10X115 HEXAGON COLLARED BOLT WITH MULTI-POINT SOCKET HEAD (DUO) (M10X115)	2 req	Avail to order Our Price: $6.46
18	4S0813239C	STRUT TUNNEL HINTEN BRACE (CONTACT YOUR AREA MANAGER)	1 req	Avail to order Our Price: $74.06
19	4S0813945K	END PLATE MUFFE SLEEVE (TO BE USED FOR REF. 9 - CONTACT YOUR AREA MANAGER-LEFT)	2 req	Avail to order Our Price: $275.54
20		BRACKET (ONLY FOR 2WD VERSION)	1 req
21		BRACKET (ONLY FOR SPYDER VERSION)	1 req
22	4T0813541D	BRACKET STOSSFAENGER FL ARM (LEFT)	1 req	Avail to order Our Price: $217.42
22	4T0813542D	BRACKET STOSSFAENGER FL ARM (RIGHT)	1 req	Avail to order Our Price: $217.42
23	12	OVAL HEXAGON SOCKET HEAD BOLT (M6X16)	0 req
24		BRACKET (ONLY FOR PERFORMANTE MODEL)	1 req
25		ADJUSTING PIN (FOR SPYDER MODEL)	0 req
26		CAP CLOSURE (SEE ILLUSTRATION : 827.02 REF 11)	0 req
27	N10664801	12-POINT SOCKET M8X20 SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD (M8X20)	2 req	Current Stock: 9 Our Price: $2.00
28	8D5827499	ADJUSTING BUFFER STOP	2 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
