2014 GALLARDO STS II SQUADRA CORSE - EUROPE

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item	Diagram
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter		Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 115.01.00 - OIL FILTER

2014 Lamborghini GALLARDO STS II SQUADRA CORSE EUROPE OIL FILTER (115.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		FILTERING CARTRIDGE (VALID UP TO MODEL YEAR 08)	0 req
2		SCREW M6X20 (VALID UP TO MODEL YEAR 08)	0 req
3		GASKET (VALID UP TO MODEL YEAR 08)	0 req
4		CHECK VALVE (VALID UP TO MODEL YEAR 08)	0 req
5		VALVE (VALID UP TO MODEL YEAR 08)	0 req
6		O-RING (VALID UP TO MODEL YEAR 08)	0 req
7		PIPE (VALID UP TO MODEL YEAR 08)	0 req
8		GASKET (VALID UP TO MODEL YEAR 08)	0 req
9		SUPPORT (VALID UP TO MODEL YEAR 08)	0 req
10		OIL FILTER (VALID UP TO MODEL YEAR 08)	0 req
11		OIL SENSOR (VALID UP TO MODEL YEAR 08)	0 req
12	07L115401F	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT OIL FILTER ASSEMBLY	1 req	*See Description
13	079198405E	Oil Filter Gallardo/Huracan LP Series OIL FILTER	1 req	Current Stock: 7 Our Price: $89.92
14	079115540A	NOZZLE VALVE	1 req	Current Stock: 4 Our Price: $32.16
15	079103121BE	GASKET GASKET	1 req	Avail to order Our Price: $18.31
16	N10622101	HEXALOBULAR SOCKET SCREW M6X65	2 req	Avail to order Our Price: $2.00
17	N91124501	12-POINT SOCKET SCREW M8X40	2 req	Avail to order Our Price: $6.70
18	07L103161H	GASKET GASKET	1 req	Avail to order Our Price: $34.99
19		CHECK VALVE (VALID UP TO MODEL YEAR 10)	0 req
20	WHT002287C	O-RING O-RING 5,6X2	1 req	Current Stock: 4 Our Price: $5.29
21	07L103704H	COVER COVER	1 req	Avail to order Our Price: $1,503.65
22	079117409F	VALVE VALVE	1 req	Avail to order Our Price: $30.90
23	077103175B	CHECK VALVE CHECK VALVE	1 req	Avail to order Our Price: $41.92
24		ENGINE BLOCK (SEE TABLE 103.01.00)	0 req
25	N10156206	SCREW SCREW M6X30	25 req	Current Stock: 130 Our Price: $2.00
26	079115433D	OIL FILTER COVER COVER	1 req	Avail to order Our Price: $102.73
27	N0138063	O-RING O-RING 10X14	1 req	Avail to order Our Price: $3.51
28	N10538201	O-RING O-RING 19X3,55	1 req	Avail to order Our Price: $6.41
29	079919081	OIL PRESSURE OIL SENSOR	1 req	Avail to order Our Price: $27.40
30	WHT002287B	O-RING O-RING 5,6X2	1 req	Avail to order Our Price: $4.85
31	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	1 req	Current Stock: 6 Our Price: $70.57
32	059919523A	TEMPERATURE SENDER TEMPERATURE SENSOR	1 req	Current Stock: 6 Our Price: $70.57
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
