2014 GALLARDO STS II SQUADRA CORSE - ARABIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 301.21.00 - REAR DIFFERENTIAL

2014 Lamborghini GALLARDO STS II SQUADRA CORSE ARABIA REAR DIFFERENTIAL (301.21.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	086525127A	FLANGE FLANGE	1 req	Avail to order Our Price: $904.12
2	086525126	SPACER RING S=6.8 RING 6.8 MM	1 req	Avail to order Our Price: $123.71
2	086525126A	SPACER RING RING 6.6 MM	1 req	Avail to order Our Price: $123.71
2	086525126B	SPACER RING RING 6.4 MM	1 req	Avail to order Our Price: $123.71
2	086525126C	SPACER RING RING 6.2 MM	1 req	Avail to order Our Price: $123.71
2	086525126D	SPACER RING RING 6.0 MM	1 req	Avail to order Our Price: $123.71
2	086525126E	SPACER RING RING 5.8 MM	1 req	Avail to order Our Price: $123.71
2	086525126F	SPACER RING RING 5.5 MM	1 req	Avail to order Our Price: $123.71
3	086311357	SPACER BUSH BUSHING	1 req	Avail to order Our Price: $47.72
4	086525356D	FLANGE SHAFT MAIN SHAFT	1 req	Avail to order Our Price: $711.81
5	086525596	SEAL RING 55X70X8 SEAL RING	2 req	Avail to order Our Price: $53.75
6		SCREW (CANNOT BE SOLD SEPARATELY)	0 req
7	N91029101	O RING SEAL RING 215,49X3,53	0 req	Avail to order Our Price: $39.26
8	086525021F	DIFFERENTIAL + BEVEL GEAR PAIR (4WD - 25/45) DIFFERENTIAL + BEVEL GEAR PAIR (4WD - 25/45)	1 req	Avail to order Our Price: $7,024.80
9	086311347A	GEAR GEAR	1 req	Avail to order Our Price: $522.38
10	086525251	BEARING 50,800X92.075X24.608 BEARING	1 req	Avail to order Our Price: $331.51
11	086307291	PINION RING NUT RING NUT M36X1,5	2 req	Avail to order Our Price: $81.24
12	086525231	DISCONTINUED - NLA - CONTACT US 4.00 mm ADJUSTMENT SHIM	1 req	*See Description
12		3.25 mm ADJUSTMENT SHIM	0 req
12		4.50 mm ADJUSTMENT SHIM	0 req
12		4.75 mm ADJUSTMENT SHIM	0 req
13	086311211	TAPER ROLLER BEARING RACE BEARING	1 req	Avail to order Our Price: $269.08
14	086525241	ADJUSTING WASHER 2.00 mm ADJUSTMENT SHIM	1 req	Avail to order Our Price: $144.23
14		1.75 mm ADJUSTMENT SHIM	0 req
14		2.25 mm ADJUSTMENT SHIM	0 req
15		SCREW (CANNOT BE SOLD SEPARATELY)	0 req
16		BEVEL GEAR PAIR (CANNOT BE SOLD SEPARATELY)	0 req
17		DIFFERENTIAL (CANNOT BE SOLD SEPARATELY)	0 req
18	086301184A	COVER FLANGE	1 req	Avail to order Our Price: $195.90
19		SEAL RING (CANNOT BE SOLD SEPARATELY)	0 req
20	086525597	SEAL RING 55X72X8 SEAL RING	1 req	Avail to order Our Price: $50.67
21	086525357D	FLANGE SHAFT MAIN SHAFT	1 req	Avail to order Our Price: $711.81
22		SCREW (CANNOT BE SOLD SEPARATELY)	0 req
23	086525777A	BALL BEARING BEARING	1 req	Avail to order Our Price: $110.22
24	086525125	SEGER RING RETAINING RING	1 req	Avail to order Our Price: $8.12
25	086525271	SPACER RING S=3,3 3.30 mm ADJUSTMENT SHIM	1 req	Avail to order Our Price: $89.84
25		2.60 mm ADJUSTMENT SHIM	0 req
25		2.80 mm ADJUSTMENT SHIM	0 req
25		2.95 mm ADJUSTMENT SHIM	0 req
26	086311124	TAPER ROLLER BEARING RACE BEARING	1 req	Avail to order Our Price: $238.23
27		GEAR (SEE TABLE 301.18.00)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
