2013 GALLARDO LP 560-4 SPYDER FL II - JAPAN

Maintenance Parts:

Brakes

PN	Item
0R1400233	GALLARDO LP560 CARBON-CERAMIC BRAKE KIT BLACK CARBO-CERAMIC BRAKES KIT BLACK (WITH BLACK BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11
0R1400234	GALLARDO LP 560-4 COUPE KIT CARBON-CERAMIC BRAKE CARBO-CERAMIC BRAKES KIT YELLOW (WITH YELLOW BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705) GALLARDO LP 560-4 COUPE EUROPE	Avail to order Our Price: $21,998.11
0R1400235	GALLARDO LP560 CARBO-CERAMIC BRAKES KIT SILVER CARBO-CERAMIC BRAKES KIT SILVER (WITH SILVER BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66

Ignition

PN	Item	Diagram
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion		Current Stock: 48 Our Price: $33.87
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item	Diagram
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 121.09.00 - WATER COOLING SYSTEM

2013 Lamborghini GALLARDO LP 560-4 SPYDER FL II JAPAN WATER COOLING SYSTEM (121.09.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N10005109	HEX. BOLT WITH WASHER € SCREW M8X35	8 req	Current Stock: 4 Our Price: $2.80
2	400121277	SPACER BUSHING	8 req	Avail to order Our Price: $10.48
3	400121268	PUFFER RUBBER BUSHING	8 req	Avail to order Our Price: $11.63
4	WHT001189	RUBBER WASHER MOUNT RUBBER BUSHING 18X30X7	8 req	Avail to order Our Price: $3.95
5	WHT001942	WASHER WASHER	8 req	Current Stock: 13 Our Price: $3.30
6	N10653201	HEXAGON FLANGE SCREW M6X16	8 req	Current Stock: 12 Our Price: $2.01
7	400121241	BRACKET LH BRACKET	1 req	Avail to order Our Price: $87.75
8	400121240	BRACKET RH BRACKET	1 req	Avail to order Our Price: $295.64
9	400121232	BRACKET RH BRACKET	1 req	Avail to order Our Price: $322.18
10	400121233	BRACKET LH BRACKET	1 req	Avail to order Our Price: $102.32
11	400807945	AIR DUCT PART LH CONVEYOR	1 req	Current Stock: 1 Our Price: $149.40
11	400807946	AIR DUCT PART RH CONVEYOR	1 req	Avail to order Our Price: $149.40
12	400809963A	AIR DUCT LH CONVEYOR	1 req	Avail to order Our Price: $454.61
12	400809964A	AIR DUCT RH CONVEYOR	1 req	Current Stock: 1 Our Price: $454.61
13	N90986803	FLANGE TAPPING SCREW ST4.2X13.0	2 req	Avail to order Our Price: $2.00
14	N0454281	SPEED NUT CLIP	2 req	Avail to order Our Price: $2.00
15	N0902324	HEX. BOLT WITH SCREW M6X10	8 req	Current Stock: 18 Our Price: $2.00
16	N10347004	HEXALOBULAR SOCKET SCREW M6X16	8 req	Current Stock: 18 Our Price: $2.00
17	WHT002225A	HEXALOBULAR SOCKET SCREW M8X16	6 req	Avail to order Our Price: $2.00
18	N10653201	HEXAGON FLANGE SCREW M6X16	4 req	Current Stock: 12 Our Price: $2.01
19	N90780903	SOCKET SCREW SCREW M6X16	4 req	Current Stock: 1 Our Price: $2.00
20	400121235	BRACKET LH BRACKET	1 req	Current Stock: 1 Our Price: $227.47
20	400121235A	BRACKET RH BRACKET	1 req	Avail to order Our Price: $205.23
21	400121252D	RADIATOR RH Side RH WATER RADIATOR	1 req	Avail to order Our Price: $2,016.31
21	400121253D	RADIATOR LH WATER RADIATOR	1 req	Avail to order 1 Used Available Our Price: $2,016.31
22	4Z7959455M	ELECTRIC FAN ELECTRIC FAN	2 req	Avail to order Our Price: $1,779.52
23	400122193C	SUPPORT LH SUPPORT	1 req	Avail to order Our Price: $512.34
23	400122194C	Support RH SUPPORT	1 req	Avail to order Our Price: $614.22
24	400807157E	AIR DUCT ELEMENT X RAFFR.MOTORE LH CONVEYOR	1 req	Avail to order Our Price: $974.97
24	400807158E	AIR DUCT ELEMENT X RAFFR.MOTORE RH CONVEYOR	1 req	Avail to order Our Price: $974.97
25	N90881601	BLIND RIVET RIVET	9 req	Current Stock: 4 Our Price: $2.00
26	400260197C	BRACKET BRACKET	3 req	Avail to order Our Price: $74.06
27	N10569501	HEXALOBULAR SOCKET SCREW M5X16	4 req	Avail to order Our Price: $2.23
28	N10082911	HEX. BOLT WITH WASHER SCREW M6X16	2 req	Current Stock: 2 Our Price: $2.00
29	400807265	GASKET GASKET	2 req	Avail to order Our Price: $10.62
30	417103484	gasket GASKET	4 req	Avail to order Our Price: $8.26
31	420121261A	BRACKET SUPPORT	2 req	Current Stock: 3 Our Price: $3.66
32	1J0971830R	BRACKET,PLUG PLUG SUPPORT	2 req	Avail to order Our Price: $5.03
33	N10347004	HEXALOBULAR SOCKET SCREW M6X16	2 req	Current Stock: 18 Our Price: $2.00
34		RUBBER BUSHING (SEE REF. 2 - 3 - 4 - 5)	0 req
35	WHT002961	WASHER WASHER	8 req	Current Stock: 39 Our Price: $2.00
36	N0115484	WASHER WASHER	8 req	Current Stock: 3 Our Price: $4.46
37	400121129	Spacer BUSHING	8 req	Avail to order Our Price: $15.93
38	07L121585	GROMMET FAIRLEAD	8 req	Avail to order Our Price: $19.02
39	N01508213	HEXAGON FLANGE NUT NUT	8 req	Current Stock: 4 Our Price: $2.00
40	400820536B	BRACKET BRACKET	1 req	Avail to order Our Price: $11.13
41	400807681D	GRILLE FRONT AIRDUCT LH LEFT FRONT GRID	1 req	Current Stock: 1 Our Price: $143.67
41	400807682D	GRILLE FRONT AIR DUCT RH RIGHT FRONT GRID	1 req	Avail to order Our Price: $383.13
42		TEMPERATURE SENSOR (SEE TABLE 260.06)	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
