2012 GALLARDO LP 560-4 COUPE - EUROPE

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 2 Our Price: $86.97

Brakes

PN	Item
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $839.54
400698151A	See PN 420698151F SET BRAKE	Avail to order Our Price: $1,166.85
420698451D	E-BRAKE PAD SET GALLARDO LP560 SET BRAKE LININGS	Current Stock: 1 Our Price: $292.05
420698451B	REAR PAD SET GALLARDO LP560 SET BRAKE	Current Stock: 12 Our Price: $526.59
0R1400233	GALLARDO LP560 CARBON-CERAMIC BRAKE KIT BLACK CARBO-CERAMIC BRAKES KIT BLACK (WITH BLACK BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11
0R1400234	GALLARDO LP 560-4 COUPE KIT CARBON-CERAMIC BRAKE CARBO-CERAMIC BRAKES KIT YELLOW (WITH YELLOW BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705) GALLARDO LP 560-4 COUPE EUROPE	Avail to order Our Price: $21,998.11
0R1400235	GALLARDO LP560 CARBO-CERAMIC BRAKES KIT SILVER CARBO-CERAMIC BRAKES KIT SILVER (WITH SILVER BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11
400698151E	SET BRAKE LININGS SET BRAKE LININGS	Avail to order Our Price: $1,166.85
420698151F	SET BRAKE LININGS SET BRAKE LININGS	Current Stock: 8 Our Price: $856.76

Drivetrain

PN	Item
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C	Avail to order Our Price: $812.27
07L105269J	Gallardo LP560 Clutch (Manual) CLUTCH FLYWHEEL (MANUAL GEARBOX) Gallardo LP560 Clutch (Manual)	Current Stock: 1 Our Price: $4,018.28
07L105269M	See PN 07L105269K Complete Clutch Assembly LP560	Avail to order Our Price: $4,018.28
07L105269K	Balanced Clutch Assembly Egear 560 Balanced Clutch Assembly Egear 560	Current Stock: 6 Our Price: $5,130.48
07L105269L	CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL	Avail to order Our Price: $5,912.61
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,037.84
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Avail to order Our Price: $86.68

Fuel-Air

PN	Item
0R1400313	LP560 and LP570 SERVICE KIT - Air-Cabin-OIL Filters Kit SERVICE KIT - 2 cabin, 2 air and 1 oil filter	Avail to order Our Price: $377.43
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $44.64
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88

Fuses-Bulbs-Relays

PN	Item
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $5.89
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N10566103	DISCHARGE LAMP DISCHARGE LAMP	Avail to order Our Price: $282.00
400941107	LIGHT LIGHT	Avail to order Our Price: $23.11
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $305.75
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $305.75

Ignition

PN	Item
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion	Current Stock: 48 Our Price: $33.87
07K905715F	PENCIL COIL PENCIL COIL	Avail to order Our Price: $81.95
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $408.62

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $184.17
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $350.89
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $479.33
1K2945511	SWITCH,BRAKE PEDAL SWITCH,BRAKE PEDAL	Avail to order Our Price: $27.42
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $118.98
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $66.02
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $36.53
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $195.90
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $121.99
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 827.03.00 - SPOILER

2012 Lamborghini GALLARDO LP 560-4 COUPE EUROPE SPOILER (827.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		FASTENER (VALID FOR A DIFFERENT MODEL)	0 req
1	400827603A	BRACKET FASTENER	10 req	Current Stock: 10 Our Price: $9.84
1		FASTENER (NOT FOR SUPERLEGGERA LP 570-4)	0 req
1	400827603A	BRACKET FASTENER	10 req	Current Stock: 10 Our Price: $9.84
2		GASKET (VALID UP TO MODEL YEAR 08)	0 req
2	400862379B	GASKET GASKET	0 req	Current Stock: 2 Our Price: $97.59
2		GASKET (VALID FOR A DIFFERENT MODEL)	0 req
2		GASKET (VALID UP TO MODEL YEAR 08)	0 req
3	400861981A	COVER SPOILER LEG COVER BRACKET	1 req	Current Stock: 1 Our Price: $269.08
3	400861981B	COVER SPOILER LEG COVER BRACKET	1 req	Avail to order Our Price: $1,801.28
3	400861981A	COVER SPOILER LEG COVER BRACKET	1 req	Current Stock: 1 Our Price: $269.08
4	400861982A	COVER SPOILER LEG COVER BRACKET	1 req	Current Stock: 1 Our Price: $269.08
4	400861982A	COVER SPOILER LEG COVER BRACKET	1 req	Current Stock: 1 Our Price: $269.08
4	400861982B	COVER SPOILER LEG COVER BRACKET	1 req	Avail to order Our Price: $1,801.28
5	400862379B	GASKET SPOILER GASKET	2 req	Current Stock: 2 Our Price: $97.59
5	400863197	SEALING STRIP LEFT LH GASKET	1 req	Avail to order Our Price: $25.12
5	400863198	SEALING STRIP RIGHT RH GASKET	1 req	Avail to order Our Price: $5.46
5	400863197	SEALING STRIP LEFT LH GASKET	1 req	Avail to order Our Price: $25.12
5	400863198	SEALING STRIP RIGHT RH GASKET	1 req	Avail to order Our Price: $5.46
6	400862603B	SPOILER SPOILER DRIVE KIT	1 req	Avail to order Our Price: $2,647.76
6		SPOILER DRIVE KIT (NOT FOR SUPERLEGGERA LP 570-4)	0 req
6	400862603B	SPOILER SPOILER DRIVE KIT	1 req	Avail to order Our Price: $2,647.76
6		SPOILER DRIVE KIT (VALID FOR A DIFFERENT MODEL)	0 req
7	400862611F	SPOILER SPOILER (BRAKE LIGHTS)	1 req	Avail to order Our Price: $5,246.56
7	400862613F	SPOILER SPOILER (BRAKE LIGHTS - REAR VIEW CAMERA)	1 req	Avail to order Our Price: $2,863.03
7		SPOILER (BRAKE LIGHTS - CANNOT BE SOLD SEPARATELY - SEE REF. 40)	0 req
7	400862613F	SPOILER SPOILER (BRAKE LIGHTS - REAR VIEW CAMERA)	1 req	Avail to order Our Price: $2,863.03
8	N10596301	SCREW M5x25.0 SCREW M5X25.0	2 req	Avail to order Our Price: $2.00
8	N10596301	SCREW M5x25.0 SCREW M5X25.0	2 req	Avail to order Our Price: $2.00
8		SCREW (NOT FOR SUPERLEGGERA LP 570-4)	0 req
8		SCREW (VALID FOR A DIFFERENT MODEL)	0 req
9	N10565502	screw SCREW M5X12 (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	4 req	Current Stock: 4 Our Price: $2.00
9		SCREW M5X12 (NOT FOR SUPERLEGGERA LP 570-4)	0 req
9		SCREW M5X12 (VALID FOR A DIFFERENT MODEL)	0 req
9	N10565502	screw SCREW M5X12 (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	4 req	Current Stock: 4 Our Price: $2.00
10	400862267	COVER COVER (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order 1 Used Available Our Price: $211.69
10	400862267	COVER COVER (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order 1 Used Available Our Price: $211.69
10		COVER (NOT FOR SUPERLEGGERA LP 570-4)	0 req
10		COVER (VALID FOR A DIFFERENT MODEL)	0 req
11	400860151	GASKET COVER GASKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $54.25
11		COVER GASKET (NOT FOR SUPERLEGGERA LP 570-4)	0 req
11		COVER GASKET (VALID FOR A DIFFERENT MODEL)	0 req
11	400860151	GASKET COVER GASKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $54.25
12	N90455204	SCREW SCREW (M4X10 - ONLY FOR VEHICLES WITH STANDARD)	2 req	Current Stock: 16 Our Price: $2.00
12	N90455204	SCREW SCREW (M4X10 - ONLY FOR VEHICLES WITH STANDARD)	2 req	Current Stock: 16 Our Price: $2.00
12		SCREW (NOT FOR SUPERLEGGERA LP 570-4)	0 req
12		SCREW (VALID FOR A DIFFERENT MODEL)	0 req
13	N10613301	SCREW SCREW M3X8.0 (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	2 req	Avail to order Our Price: $2.00
13	N10613301	SCREW SCREW M3X8.0 (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	2 req	Avail to order Our Price: $2.00
14	400862172	BRACKET CAMERA BRACKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Current Stock: 1 Our Price: $266.43
14	400862172	BRACKET CAMERA BRACKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Current Stock: 1 Our Price: $266.43
14	403862172B	BRACKET CAMERA BRACKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $170.78
15	7L6980551	CAMERA CAMERA (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $621.40
15	7L6980551	CAMERA CAMERA (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $621.40
16	400862231	GASKET ADHESIVE GASKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Current Stock: 18 Our Price: $2.00
16	400862231	GASKET ADHESIVE GASKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Current Stock: 18 Our Price: $2.00
17	400862591A	TRIM FRAME (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $191.57
17		FRAME (NOT FOR SUPERLEGGERA LP 570-4)	0 req
17		FRAME (VALID FOR A DIFFERENT MODEL)	0 req
17	400862591A	TRIM FRAME (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $191.57
18		THIRD STOP LAMP (SEE TABLE 945.01.00 - SEE REF. 9)	0 req
18		THIRD STOP LAMP (SEE TABLE 945.01.00 - SEE REF. 9)	0 req
19	400862263	SOUND ABSORBER ADHESIVE SPONGE RUBBER (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $1.94
19	400862263	SOUND ABSORBER ADHESIVE SPONGE RUBBER (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $1.94
20		SPOILER DRIVE KIT (VALID FOR A DIFFERENT MODEL)	0 req
20		SPOILER DRIVE KIT (NOT FOR SUPERLEGGERA LP 570-4)	0 req
20		SPOILER DRIVE KIT (VALID FOR A DIFFERENT MODEL)	0 req
21		COVER (NOT FOR SUPERLEGGERA LP 570-4)	0 req
21		COVER (VALID FOR A DIFFERENT MODEL)	0 req
21		COVER (VALID FOR A DIFFERENT MODEL)	0 req
22		SCREW M5X18.0 (VALID FOR A DIFFERENT MODEL)	0 req
22		SCREW M5X18.0 (NOT FOR SUPERLEGGERA LP 570-4)	0 req
22		SCREW M5X18.0 (VALID FOR A DIFFERENT MODEL)	0 req
23		SPOILER (VALID FOR A DIFFERENT MODEL)	0 req
23		SPOILER (VALID FOR A DIFFERENT MODEL)	0 req
24		COVER GASKET (VALID FOR A DIFFERENT MODEL)	0 req
24	403860151	GASKET COVER GASKET (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $67.52
24		COVER GASKET (VALID FOR A DIFFERENT MODEL)	0 req
25	403827651A	PROFILE SEAL GASKET	2 req	Current Stock: 1 Our Price: $82.96
25		GASKET (VALID FOR A DIFFERENT MODEL)	0 req
25		GASKET (VALID FOR A DIFFERENT MODEL)	0 req
26		COVER (VALID FOR A DIFFERENT MODEL)	0 req
26	403827598A	COVER COVER (WITH PREDISPOSITION FOR REAR VIEW CAMERA)	1 req	Avail to order Our Price: $2,444.59
26	403827598B	COVER COVER (WITHAUT PREDISPOSITION FOR REAR VIEW CAMERA)	1 req	Avail to order Our Price: $2,444.59
26		COVER (VALID FOR A DIFFERENT MODEL)	0 req
27	N10565502	screw SCREW M5X12	4 req	Current Stock: 4 Our Price: $2.00
27		SCREW M5X12 (VALID FOR A DIFFERENT MODEL)	0 req
27		SCREW M5X12 (VALID FOR A DIFFERENT MODEL)	0 req
28		SCREW M6X12 (VALID FOR A DIFFERENT MODEL)	0 req
28	N10621601	HEXALOBULAR SOCKET SCREW M4X12	6 req	Current Stock: 4 Our Price: $2.37
28		SCREW M6X12 (VALID FOR A DIFFERENT MODEL)	0 req
29	N90626204	HEXALOBULAR SOCKET SCREW M5X13.6	6 req	Current Stock: 4 Our Price: $2.15
29		SCREW M5X13.6 (VALID FOR A DIFFERENT MODEL)	0 req
29		SCREW M5X13.6 (VALID FOR A DIFFERENT MODEL)	0 req
30	N10621601	HEXALOBULAR SOCKET SCREW M6X12	10 req	Current Stock: 4 Our Price: $2.37
30	N10621601	HEXALOBULAR SOCKET SCREW M6X12	10 req	Current Stock: 4 Our Price: $2.37
31	403827757	SUPPORTING PLATE LEFT SPOILER BRACKET	1 req	Current Stock: 1 Our Price: $1,779.52
31		LEFT SPOILER BRACKET (VALID FOR A DIFFERENT MODEL)	0 req
31		LEFT SPOILER BRACKET (VALID FOR A DIFFERENT MODEL)	0 req
32		RIGHT SPOILER BRACKET (VALID FOR A DIFFERENT MODEL)	0 req
32	403827758	SUPPORTING PLATE RIGHT SPOILER BRACKET	1 req	Current Stock: 1 Our Price: $1,779.52
32		RIGHT SPOILER BRACKET (VALID FOR A DIFFERENT MODEL)	0 req
33	N10621601	HEXALOBULAR SOCKET SCREW M4X12	10 req	Current Stock: 4 Our Price: $2.37
33		SCREW M4X12 (VALID FOR A DIFFERENT MODEL)	0 req
33	N10621601	HEXALOBULAR SOCKET SCREW M4X12	10 req	Current Stock: 4 Our Price: $2.37
34		WIRING HARNESS (VALID FOR A DIFFERENT MODEL)	0 req
34	403971157	ADAPTER HARNESS WIRING HARNESS (ONLY FOR VEHICLES WITH REAR VIEW CAMERA)	1 req	Avail to order Our Price: $11.19
34		WIRING HARNESS (VALID FOR A DIFFERENT MODEL)	0 req
35	N90533005	HEX. BOLT WITH SCREW M6X20	2 req	Current Stock: 8 Our Price: $1.94
35	N91051101	DUO 6-POINT FLANGE SCREW M6X30	4 req	Avail to order Our Price: $2.00
35	WHT003681	HEXALOBULAR SOCKET SCREW M6X30	4 req	Avail to order Our Price: $6.18
35		SCREW M6X20 (VALID FOR A DIFFERENT MODEL)	0 req
35	N90533005	HEX. BOLT WITH SCREW M6X20	2 req	Current Stock: 8 Our Price: $1.94
35	WHT003681	HEXALOBULAR SOCKET SCREW M6X30	4 req	Avail to order Our Price: $6.18
36	408827027	TRUNK LID COVER	1 req	Avail to order Our Price: $167.20
36	408827027A	TRUNK LID COVER (FOR TRASPARENT ENGINE BONNET)	1 req	Avail to order Our Price: $1,387.74
36	408827027	TRUNK LID COVER	1 req	Avail to order Our Price: $167.20
36	408827027A	TRUNK LID COVER (FOR TRASPARENT ENGINE BONNET)	1 req	Avail to order Our Price: $1,387.74
36		COVER (VALID FOR A DIFFERENT MODEL)	0 req
37	408827207A	END PLATE COVER	1 req	Avail to order Our Price: $200.92
37		COVER (VALID FOR A DIFFERENT MODEL)	0 req
37	408827207A	END PLATE COVER	1 req	Avail to order Our Price: $200.92
38	408827208A	END PLATE COVER	1 req	Avail to order Our Price: $200.92
38	408827208A	END PLATE COVER	1 req	Avail to order Our Price: $200.92
38		COVER (VALID FOR A DIFFERENT MODEL)	0 req
39	N90807405	HEXALOBULAR SOCKET FLANGE BOLT SCREW M5X18	10 req	Current Stock: 2 Our Price: $2.00
39		SCREW M5X18 (VALID FOR A DIFFERENT MODEL)	0 req
39	N90807405	HEXALOBULAR SOCKET FLANGE BOLT SCREW M5X18	10 req	Current Stock: 2 Our Price: $2.00
40	400862611H	SPOILER SPOILER (BRAKE LIGHTS)	1 req	Avail to order Our Price: $2,776.92
40	400862611H	SPOILER SPOILER (BRAKE LIGHTS)	1 req	Avail to order Our Price: $2,776.92
40		SPOILER (VALID FOR A DIFFERENT MODEL)	0 req
41	WHT001197A	WASHER WASHER	4 req	Current Stock: 2 Our Price: $2.00
41		WASHER (VALID FOR A DIFFERENT MODEL)	0 req
41	WHT001197A	WASHER WASHER	4 req	Current Stock: 2 Our Price: $2.00
42	N10156306	HEXAGON FLANGE BOLT SCREW M6X12	3 req	Avail to order Our Price: $2.00
42	N10156306	HEXAGON FLANGE BOLT SCREW M6X12	3 req	Avail to order Our Price: $2.00
42		SCREW M6X12 (VALID FOR A DIFFERENT MODEL )	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
