2012 GALLARDO LP 550-2 SPYDER - JAPAN

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
7H0906271A-ALT	Fuel Pump Module Assembly Fuel Pump Module Assembly 7H0906271A Fuel Vapor Leak Detection Pump The Factory is no longer providing the original item. This is a compatible replacement	Avail to order Our Price: $300.00

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $352.09
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 907.04.00 - ELECTRICAL SYSTEM

2012 Lamborghini GALLARDO LP 550-2 SPYDER JAPAN ELECTRICAL SYSTEM (907.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	400907552E	CONTROL UNIT LIE CONTROL UNIT - 2WD (NOT FOR A MARKET SCANDINAVIA - ORDER ALSO REF. 4 - 7)	2 req	Avail to order Our Price: $6,096.48
2	N91096601	HEXALOBULAR SOCKET SCREW M6X12	8 req	Current Stock: 6 Our Price: $2.00
3	407907324D	BRACKET RH BRACKET	1 req	Avail to order Our Price: $218.85
3	407907348D	BRACKET LH BRACKET	1 req	Avail to order Our Price: $218.85
4	N91023802	SHEAR BOLT SCREW M5X14	4 req	Current Stock: 10 Our Price: $2.00
5	8E0907411J	PROTECTION HOUSING BRACKET	2 req	Avail to order Our Price: $61.56
6	420907637	SENSOR YAWRATE SENSOR (ESP)	1 req	Avail to order Our Price: $1,161.24
7	N90980304	SHEAR BOLT SCREW M6X12	4 req	Current Stock: 9 Our Price: $2.00
8	400927156B	CONTROL UNIT E-GEAR CONTROL UNIT (2WD)	1 req	Avail to order Our Price: $1,771.63
8	400927156D	CONTROL UNIT E-GEAR CONTROL UNIT	1 req	Avail to order Our Price: $8,076.53
9	8E0907500J	CATCH BRACKET	2 req	Current Stock: 1 Our Price: $39.68
10	407907354	BRACKET LH BRACKET	1 req	Avail to order Our Price: $15.57
10	407907649	BRACKET RH BRACKET	1 req	Avail to order Our Price: $72.88
11		BRACKET (VALID UP TO MODEL YEAR 10)	0 req
12	N01508213	HEXAGON FLANGE NUT NUT M6	3 req	Current Stock: 4 Our Price: $2.00
13	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
14	8P0035503M	ANTENNA ANTENNA BLUETOOTH	1 req	Avail to order Our Price: $31.79
16	N01508213	HEXAGON FLANGE NUT NUT M6	4 req	Current Stock: 4 Our Price: $2.00
17	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
18		CD CHANGER (SEE TABLE 857.07.00)	0 req
18		USB INTERFACE (SEE TABLE 857.07.00)	0 req
19	8E0959643E	sensor AIR BAG SENSOR	2 req	Avail to order Our Price: $225.55
20		BRACKET (VALID UP TO MODEL YEAR 09)	0 req
21		SCREW M6X14 (VALID UP TO MODEL YEAR 09)	0 req
22	407959255A	CONTROL UNIT TOP CAPOTE CONTROL UNIT	1 req	Avail to order Our Price: $430.26
23		SUPPORT (VALID UP TO MODEL YEAR 10)	0 req
24	N91096601	HEXALOBULAR SOCKET SCREW M6X12	5 req	Current Stock: 6 Our Price: $2.00
25	N90338204	PAN HEAD BOLT WITH WASHER SCREW M6X45	4 req	Avail to order Our Price: $3.43
26	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
27	407035643	BRACKET BRACKET (CAPOTE-CD-ESP)	1 req	Avail to order Our Price: $133.10
28	8P1862335A	CELLULAR PHONE BLUETOOTH CONTROL UNIT	1 req	Avail to order Our Price: $803.94
29	N91053801	6-POINT FLANGE SCREW M6X20	3 req	Current Stock: 12 Our Price: $2.00
30	N91096601	HEXALOBULAR SOCKET SCREW M6X12	5 req	Current Stock: 6 Our Price: $2.00
31	4F0937503	RELAY PLATE SUPPORT (ENGINE RELAY BOX WIRING HARNESS)	1 req	Avail to order Our Price: $11.99
32	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
33	4F1971845A	BRACKET SUPPORT	1 req	Avail to order Our Price: $14.90
34	4F1937545	CLUTCH CARRIER SUPPORT (CENTRAL WIRING HARNESS)	1 req	Avail to order Our Price: $7.22
35	N10595002	HEXALOBULAR SOCKET SCREW M5X18	2 req	Avail to order Our Price: $2.00
36		SUPPORT (VALID UP TO MODEL YEAR 10)	0 req
37	407971856	BRACKET BRACKET (CAPOTE-CD-ESP)	1 req	Avail to order Our Price: $16.91
38	4B0937545B	support SUPPORT (CENTRAL WIRING HARNESS)	1 req	Avail to order Our Price: $7.37
39	407971806	BRACKET SUPPORT	1 req	Avail to order Our Price: $59.93
40		COVER (VALID UP TO MODEL YEAR 09)	0 req
41	407861669	BRACKET BRACKET (BLUETOOTH)	1 req	Avail to order Our Price: $195.04
42	407861826	BRACKET RH BRACKET (BLUETOOTH)	1 req	Avail to order Our Price: $27.47
43	407861825	BRACKET LH BRACKET (BLUETOOTH)	1 req	Avail to order Our Price: $33.21
44	N10017304	HEXAGON FLANGE NUT NUT M5	4 req	Current Stock: 16 Our Price: $2.01
45	6N0906356A	MOUNTING BRACKET (E-GEAR)	1 req	Avail to order Our Price: $2.61
46	6N0906356	MOUNTING BRACKET (E-GEAR)	2 req	Avail to order Our Price: $2.61
47	407907347A	BRACKET SUPPORT (E-GEAR)	1 req	Avail to order Our Price: $291.80
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
