2012 GALLARDO LP 550-2 SPYDER - AUSTRALIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27

Sensors

PN	Item	Diagram
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 301.18.00 - DRIVEN SHAFT - PTO

2012 Lamborghini GALLARDO LP 550-2 SPYDER AUSTRALIA DRIVEN SHAFT - PTO (301.18.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	086311257A	INDEXING GEAR,1ST FIRST GEAR (E-GEAR)	1 req	Avail to order Our Price: $1,092.12
1	086311257G	INDEXING GEAR,1ST FIRST GEAR (MANUAL GEARBOX)	1 req	Avail to order Our Price: $1,092.12
2	086311231	1ST GEAR SHOULDER SHIMRING SPACER	1 req	Avail to order Our Price: $89.99
3	086311372E	ROLLER BEARING BEARING 35X72X17	1 req	Avail to order Our Price: $238.23
4	086311423	REVERSE DRIVEN GEARB BUSHING BUSHING	1 req	Avail to order Our Price: $254.02
5	086311770	RETAINER REVERSE DRIVEN ROLLER CAGE	1 req	Avail to order Our Price: $87.40
6	086311532A	INTERMEDIATE WHEEL REVERSE IDLE GEAR	1 req	Avail to order Our Price: $1,109.34
7	086307303	RINGNUT M27X15 RING NUT M27X1,5	2 req	Avail to order Our Price: $98.17
8	086311762A	SYNCHRONIZER HUB SYNCHRONIZING GEAR (MANUAL GEARBOX)	1 req	Avail to order Our Price: $619.97
8	086311762D	SYNCHRONIZER HUB SYNCHRONIZING GEAR (E-GEAR)	1 req	Avail to order Our Price: $513.77
9	086311195M	OUTPUT SHAFT MAIN SHAFT	1 req	Avail to order Our Price: $2,611.88
10	086311235C	BALL BEARING BEARING 35X80X21	1 req	Avail to order Our Price: $135.62
11	086311352D	GEAR GEAR	1 req	Avail to order Our Price: $4,032.63
12	086311348E	GEAR GEAR	1 req	Avail to order Our Price: $562.56
13	086311372F	ROLLER BEARING BEARING 30X62X16	1 req	Avail to order Our Price: $269.08
14	086307293	THRUST WASHER WASHER	1 req	Avail to order Our Price: $28.57
15	086307304	RINGNUT M22X15 RING NUT M22	1 req	Avail to order Our Price: $98.17
16	086311243B	SYNCHRONIZER HUB SYNCHRONIZING GEAR (MANUAL GEARBOX)	1 req	Avail to order Our Price: $2,260.28
16	086311243C	SYNCHRONIZER HUB SYNCHRONIZING GEAR (E-GEAR)	1 req	Avail to order Our Price: $2,260.28
17	086311163F	INDEXING GEAR,2ND SECOND GEAR	1 req	Avail to order Our Price: $476.46
18	086311150	RETAINER 4TH DRIVEGEAR ROLLER CAGE	1 req	Avail to order Our Price: $78.36
19	086311132	RETAINER 1ST DRIVEN GEAR ROLLER CAGE	1 req	Avail to order Our Price: $60.28
20	086311187A	SECURITY RING FOR SHAFTS RETAINING RING	1 req	Avail to order Our Price: $40.84
21		SCREW (CANNOT BE SOLD SEPARATELY)	0 req
22	086311345A	GEAR GEAR (4WD)	1 req	Avail to order Our Price: $401.83
23	086311372G	ROLLER BEARING BEARING 30X62X20 (4WD)	1 req	Avail to order Our Price: $348.73
24	086311113A	RADIAL SHAFT SEAL RETAINING RING	1 req	Avail to order Our Price: $52.31
25	086311106B	DRIVE SHAFT PTO SHAFT (4WD)	1 req	Avail to order Our Price: $1,043.32
26	086311133A	RIGID BEARING EGINE SIDE BEARING 30X62X16 (4WD)	1 req	Current Stock: 1 Our Price: $86.68
27	086311317	ELASTIC SECURITY RING RETAINING RING (4WD)	1 req	Avail to order Our Price: $5.81
28	086525283B	FLANGE COVER (4WD)	1 req	Avail to order Our Price: $174.37
29		WASHER (CANNOT BE SOLD SEPARATELY)	0 req
30	086311276	TOOTHED WASHER WASHER (4WD)	1 req	Avail to order Our Price: $2.00
31		SCREW (CANNOT BE SOLD SEPARATELY)	0 req
32	086311713	PROTECTIVE CAP PROTECTION (4WD)	1 req	Avail to order Our Price: $44.21
33	086311137	CAP PLUG (FOR 2WD MODEL)	1 req	Avail to order Our Price: $155.71
33		PLUG (VALID FOR A MODEL 2WD)	0 req
34	086311120	CAP PLUG (FOR 2WD MODEL)	1 req	Avail to order Our Price: $155.71
34		PLUG (VALID FOR A MODEL 2WD)	0 req
35		RETAINING RING (CANNOT BE SOLD SEPARATELY)	0 req
35		RETAINING RING (VALID FOR A MODEL 2WD)	0 req
36		RETAINING RING (CANNOT BE SOLD SEPARATELY)	0 req
36		RETAINING RING (VALID FOR A MODEL 2WD)	0 req
37		SEAL RING (CANNOT BE SOLD SEPARATELY)	0 req
37		SEAL RING (VALID FOR A MODEL 2WD)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
