2011 GALLARDO LP 550-2 COUPE - CANADA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $86.68

Fuel-Air

PN	Item
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $627.14
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $126.58
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $278.88
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $40.12
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 1 Our Price: $80.66
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 2 Our Price: $115.96

Ignition

PN	Item	Diagram
000915105DK	SEE PN 000915105DK BATTERY		Avail to order Our Price: $408.62

Misc

PN	Item
0R1400308	Tool Kit Gallardo 2009-2014 Tool Kit Gallardo 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $423.36
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,812.27
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT		Current Stock: 2 Our Price: $45.07
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT		Avail to order Our Price: $45.07

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 201.05.00 - FUEL CAP

2011 Lamborghini GALLARDO LP 550-2 COUPE CANADA FUEL CAP (201.05.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
3	400201609	FILLING HOSE FUEL FILLER PIPE	1 req	Avail to order Our Price: $23.54
4	408201137A	FILLING PIPE FUEL FILLER ASSY, UPPER	1 req	Avail to order Our Price: $434.84
5	400201557	SEALING WASHER GASKET	1 req	Avail to order Our Price: $579.79
6	400201587A	Gas Cap - Diablo, Murci, Gallardo FUEL FILLER PLUG	1 req	Current Stock: 1 Our Price: $941.43
7		FUEL FILLER LID CABLE SUPPORT (NOT FOR LP 560-4 MODEL - SEE TABLE 825.06.00)	0 req
7		FUEL FILLER LID CABLE SUPPORT (NOT FOR SUPERLEGGERA LP 570-4 - SEE TABLE 825.06.00)	0 req
8	400809909A	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT FUEL FILLER LID	1 req	*See Description
9	400809933C	INSERT.FUEL FILLER FUEL FILLER TANK	1 req	Avail to order Our Price: $135.05
10	400809977	BOWDEN CABLE FUEL FILLER LID MANUAL OPENING CABLE (AESTHETIC HEAT - STANDARD)	1 req	Current Stock: 1 Our Price: $38.32
10	400809977A	BOWDEN CABLE FUEL FILLER LID MANUAL OPENING CABLE	1 req	Avail to order Our Price: $38.39
11		FUEL TANK SUPPORT BRACKET (VALID UP TO MODEL YEAR 10 )	0 req
12	400959849C	BRACKET ACTUATOR SUPPORT BRACKET	1 req	Avail to order Our Price: $25.98
13	8Z0809937	WATER OUTLET PIPE WATER DRAIN PIPE	1 req	Avail to order Our Price: $2.30
14	8Z0810773A	FUEL FLAP RELEASE MOTOR ACTUATOR	1 req	Avail to order Our Price: $29.71
15	8Z0810901	ACTUATOR SUPPORT ACTUATOR ROD SUPPORT	1 req	Avail to order Our Price: $3.66
16		HORIZONTAL ACTUATOR ROD (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 26)	0 req
17	N90732103	SCREW SCREW 4.0X16	1 req	Current Stock: 12 Our Price: $2.00
18	N10082911	HEX. BOLT WITH WASHER SCREW M6X16.00	2 req	Current Stock: 2 Our Price: $2.00
19	1J0809931	SPRING SPRING	1 req	Current Stock: 3 Our Price: $3.59
20		SCREW M5X12 (NOT FOR LP 560-4 MODEL - SEE TABLE 825.06.00)	0 req
20		SCREW M5X12 (NOT FOR SUPERLEGGERA LP 570-4 - SEE TABLE 825.06.00)	0 req
21	N91115401	HOSE CLAMP CLAMP	2 req	Avail to order Our Price: $4.81
22	N10082911	HEX. BOLT WITH WASHER SCREW M6X16.00	2 req	Current Stock: 2 Our Price: $2.00
23	N90732103	SCREW SCREW 4.0X16	1 req	Current Stock: 12 Our Price: $2.00
24	N90944603	HEXALOBULAR SOCKET SCREW M5X12	4 req	Avail to order Our Price: $2.00
25		SCREW (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 14)	0 req
26	408959776	LOCKING MOTOR ACTUATOR ASSEMBLY	1 req	Current Stock: 2 Our Price: $66.81
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
