2010 GALLARDO LP 550-2 SPYDER - EUROPE

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
7H0906271A-ALT	Fuel Pump Module Assembly Fuel Pump Module Assembly 7H0906271A Fuel Vapor Leak Detection Pump The Factory is no longer providing the original item. This is a compatible replacement	Avail to order Our Price: $300.00

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $352.09
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 837.06.00 - DOORS

2010 Lamborghini GALLARDO LP 550-2 SPYDER EUROPE DOORS (837.06.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	1H0837947	END CUP SCREW COVER	2 req	Current Stock: 16 Our Price: $2.00
2	407831021	DOOR,FR DOOR, LH	1 req	Avail to order Our Price: $13,912.47
2	407831022	DOOR,FR DOOR, RH	1 req	Avail to order Our Price: $13,912.47
3	407837477	WINDOW SLOT SEAL GLASS WEATHERSTRIP, LH	1 req	Avail to order Our Price: $196.52
3	407837478	WINDOW SLOT SEAL GLASS WEATHERSTRIP, RH	1 req	Avail to order Our Price: $196.52
4	400837497	clip COUPLING RING, LH	1 req	Avail to order Our Price: $5.96
4	400837498	clip COUPLING RING, RH	1 req	Avail to order Our Price: $5.96
5	407837911D	DOOR SEALING DOOR WEATHERSTRIP, OUTER LH	1 req	Avail to order Our Price: $471.94
5	407837912D	DOOR SEALING DOOR WEATHERSTRIP, OUTER RH	1 req	Avail to order Our Price: $471.94
6	4E0831401A	DOOR HINGE HINGE, UPPER LH	1 req	Avail to order Our Price: $78.47
6	4E0831402A	DOOR HINGE HINGE, UPPER RH	1 req	Avail to order Our Price: $78.47
7	4E0831411C	DOOR HINGE HINGE, LOWER LH	1 req	Avail to order Our Price: $116.13
7	4E0831412C	DOOR HINGE HINGE, LOWER RH	1 req	Avail to order Our Price: $116.13
8	8E0837033	STRIKER LH CLOSING BRACKET	2 req	Current Stock: 2 Our Price: $20.55
9	8E0971841E	GROMMET BUSHING	2 req	Avail to order Our Price: $12.73
10	420837805	ANTI-DRUM LAYER INSULATING COVERING	4 req	Avail to order Our Price: $22.11
11	8L3837199B	FASTENER WINDOW REV. FIXING CLIP. WINDOW COVERING FASTENER	16 req	Current Stock: 34 Our Price: $2.00
12	8L3837947	END CUP SCREW COVER	2 req	Current Stock: 60 Our Price: $2.00
13	N0902941	COMBI TAPPING SCREW 4,2x19 SCREW	6 req	Current Stock: 35 Our Price: $2.00
14	407831707A	DOOR SEAL LH DOOR WEATHERSTRIP, INNER	1 req	Current Stock: 2 Our Price: $434.73
14	407831708A	DOOR SEAL RH DOOR WEATHERSTRIP, INNER	1 req	Current Stock: 1 Our Price: $434.73
15		LEFT SIDE COVER ASSEMBLY (SEE TABLE 701.12.00)	0 req
16	WHT001237	HEXALOBULAR SOCKET SCREW M8X40	4 req	Current Stock: 16 Our Price: $2.00
17	WHT001230	HEXALOBULAR SOCKET SCREW M8X27	4 req	Avail to order Our Price: $4.40
18	N91060501	HEXALOBULAR SOCKET FLANGE BOLT SCREW M8X130X80	4 req	Avail to order Our Price: $58.29
19	8H0831701	SCREW SCREW M10X34	2 req	Current Stock: 3 Our Price: $2.01
20	400863979	SOUND ABSORBER LH INSULATION	1 req	Avail to order Our Price: $22.19
20	400863980	SOUND ABSORBER RH INSULATION	1 req	Avail to order Our Price: $22.19
21	8P3959845A	BELLOWS SHEATH	2 req	Avail to order Our Price: $10.05
22	400863051	LH Cover LH COVER	1 req	Current Stock: 2 Our Price: $6.03
22	400863052	RH COVER RH COVER	1 req	Avail to order Our Price: $6.03
23	407837173A	CLAMP SCREW	6 req	Avail to order Our Price: $69.01
24	407868382	SEAL PART GASKET	2 req	Avail to order Our Price: $41.25
25	N90107607	WASHER WASHER	4 req	Current Stock: 18 Our Price: $2.00
26	N90900401	HEXALOBULAR SOCKET M6x20 SCREW M6X20	4 req	Current Stock: 2 Our Price: $2.00
27	N90807405	HEXALOBULAR SOCKET FLANGE BOLT SCREW M5X18	2 req	Current Stock: 2 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
