2010 GALLARDO LP 550-2 COUPE - AUSTRALIA

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G		Current Stock: 1 Our Price: $948.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO		Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING		Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
7H0906271A-ALT	Fuel Pump Module Assembly Fuel Pump Module Assembly 7H0906271A Fuel Vapor Leak Detection Pump The Factory is no longer providing the original item. This is a compatible replacement	Avail to order Our Price: $300.00

Sensors

PN	Item
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $352.09
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 857.07.00 - HI-FI SYSTEM

2010 Lamborghini GALLARDO LP 550-2 COUPE AUSTRALIA HI-FI SYSTEM (857.07.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		CAR HI-FI SYSTEM (VALID UP TO MODEL YEAR 06)	0 req
2	400035311D	BRACKET,RADIO SUPPORT	1 req	Avail to order Our Price: $181.64
3	400035419A	NLA (No Longer Available) LH LOUDSPEAKER GRID	1 req	*See Description
3	400035420A	LOUDSPEAKER GRILLE RH LOUDSPEAKER GRID	1 req	Avail to order Our Price: $267.99
3		LOUDSPEAKER GRID (NOT FOR SUPERLEGGERA MODEL)	0 req
4	8E0035399	TWEETER TWEETER	2 req	Current Stock: 12 Our Price: $46.98
5	8E0035411	SPEAKER LOUDSPEAKER	2 req	Avail to order Our Price: $81.15
6	8E0858075	SUPPORT RADIO SUPPORT (RNSE)	1 req	Avail to order Our Price: $42.51
7	N0902941	COMBI TAPPING SCREW 4,2x19 SCREW ST4.2X19	6 req	Current Stock: 35 Our Price: $2.00
8	N90729003	SCREW W.WASHER SCREW M5X16	6 req	Current Stock: 16 Our Price: $2.00
9	N90777702	SNAP NUT CLAMP CLIP M5X13.6X11.5	4 req	Current Stock: 3 Our Price: $2.00
10	N90821401	nut CLIP	6 req	Current Stock: 25 Our Price: $2.00
11	400035192N	RADIO NAVIGATION RADIO AND NAVIGATOR SYSTEM (STANDARD)	1 req	Avail to order Our Price: $5,664.74
12		CD CHANGER (VALID UP TO MODEL YEAR 09)	0 req
14	N90659901	PAN HEAD SCREW SCREW M4X16	2 req	Current Stock: 4 Our Price: $3.43
14		SCREW (NOT FOR SUPERLEGGERA MODEL)	0 req
15		WIRING HARNESS (VALID UP TO MODEL YEAR 08)	0 req
16	8Z0919889	antenna AERIAL GPS	1 req	Current Stock: 2 Our Price: $364.75
17	400919909A	bracket GPS ANTENNA BRACKET	1 req	Current Stock: 1 Our Price: $26.13
18		BRACKET (FOR SPYDER MODEL)	0 req
19		SCREW M6X15 (FOR SPYDER MODEL)	0 req
20		ANTENNA AMPLIFIER (SEE TABLE 858.01.00)	0 req
21		NUT M4 (FOR SPYDER MODEL)	0 req
23	400035536	BRACKET BRACKET (ANTENNA AMPLIFIER AM/FM)	1 req	Current Stock: 1 Our Price: $14.90
24	N90693702	6-POINT FLANGE M5X20.0 SCREW M5X20	2 req	Avail to order Our Price: $2.00
25	N90693702	6-POINT FLANGE M5X20.0 SCREW M5X20	2 req	Avail to order Our Price: $2.00
26		KIT FOR I-POD (NOT FOR SUPERLEGGERA MODEL)	0 req
26		KIT FOR I-POD (VALID UP TO MODEL YEAR 09)	0 req
27		KIT FM CONVERTER WIRING (VALID UP TO MODEL YEAR 08)	0 req
28	N01508213	HEXAGON FLANGE NUT NUT M6	2 req	Current Stock: 4 Our Price: $2.00
29		SHELF MOUNTING IPOD (NOT FOR SUPERLEGGERA MODEL)	0 req
29		SHELF MOUNTING IPOD (VALID UP TO MODEL YEAR 09)	0 req
30		SCREW M5X12 (VALID UP TO MODEL YEAR 08)	0 req
31		BRACKET (VALID FOR A MARKET JAPANESE)	0 req
32		FAIRLEAD (VALID FOR A MARKET JAPANESE)	0 req
34		IPOD INTERFACE (VALID FOR A MARKET JAPANESE FROM MY12)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
