2009 GALLARDO LP 560-4 SPYDER - USA

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 4 Our Price: $208.43

Brakes

PN	Item
400698151A	See PN 420698151F SET BRAKE	Avail to order Our Price: $1,242.35
420698451B	REAR PAD SET GALLARDO LP560 SET BRAKE	Current Stock: 12 Our Price: $560.92
420698451D	E-BRAKE PAD SET GALLARDO LP560 SET BRAKE LININGS	Current Stock: 1 Our Price: $302.97
0R1400233	GALLARDO LP560 CARBON-CERAMIC BRAKE KIT BLACK CARBO-CERAMIC BRAKES KIT BLACK (WITH BLACK BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11
0R1400234	GALLARDO LP 560-4 COUPE KIT CARBON-CERAMIC BRAKE CARBO-CERAMIC BRAKES KIT YELLOW (WITH YELLOW BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705) GALLARDO LP 560-4 COUPE EUROPE	Avail to order Our Price: $21,998.11
0R1400235	GALLARDO LP560 CARBO-CERAMIC BRAKES KIT SILVER CARBO-CERAMIC BRAKES KIT SILVER (WITH SILVER BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $21,998.11
400698151E	SET BRAKE LININGS SET BRAKE LININGS	Avail to order Our Price: $1,242.35
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO	Current Stock: 10 Our Price: $399.00
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G	Current Stock: 1 Our Price: $948.35

Common repairs and upgrades

PN	Item
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $83.92
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89

Drivetrain

PN	Item
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C	Avail to order Our Price: $867.95
07L105269J	Gallardo LP560 Clutch (Manual) CLUTCH FLYWHEEL (MANUAL GEARBOX) Gallardo LP560 Clutch (Manual)	Current Stock: 1 Our Price: $4,295.08
07L105269M	See PN 07L105269K Complete Clutch Assembly LP560	Avail to order Our Price: $4,295.08
07L105269K	Balanced Clutch Assembly Egear 560 Balanced Clutch Assembly Egear 560	Current Stock: 6 Our Price: $5,486.08
07L105269L	CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL	Avail to order Our Price: $6,319.79
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,114.04
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series	Current Stock: 7 Our Price: $89.92
N0138495	O-RING DRAIN PLUG WASHER O-RING	Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
0R1400313	LP560 and LP570 SERVICE KIT - Air-Cabin-OIL Filters Kit SERVICE KIT - 2 cabin, 2 air and 1 oil filter	Avail to order Our Price: $403.46
0R1400314	GALLARDO 2009-2014 SERVICE KIT - Air-Cabin-OIL Filter +Plugs+Belt Kit SERVICE KIT Air-Cabin-OIL Filter +Plugs+Belt Kit	Avail to order Our Price: $671.44
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $46.31
420133844D	Air filter Gallardo LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Avail to order Our Price: $131.32
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
4F0201511E	Fuel Filter - Gallardo LP 560-4 FUEL FILTER - Gallardo LP 560-4	Current Stock: 8 Our Price: $85.46
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $123.28
420133844DZ	Pair High Flow K&N Air filter Gallardo LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $289.31

Fuses-Bulbs-Relays

PN	Item
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.33
N01713118	FUSE FUSE	Current Stock: 18 Our Price: $2.00
N10566103	DISCHARGE LAMP DISCHARGE LAMP	Avail to order Our Price: $301.48
400941107	LIGHT LIGHT	Avail to order Our Price: $24.72
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $325.84
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $325.84

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.18

Ignition

PN	Item
101905631G	Spark Plug - Gallardo/Huracan LP Series Spark Plug Champion	Current Stock: 48 Our Price: $35.14
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $117.47
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $452.59
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $8,901.04
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
7H0906271A-ALT	Fuel Pump Module Assembly Fuel Pump Module Assembly 7H0906271A Fuel Vapor Leak Detection Pump The Factory is no longer providing the original item. This is a compatible replacement	Avail to order Our Price: $300.00

Sensors

PN	Item
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $375.18
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $497.25
1K2945511	BRAKE PEDAL SWITCH SWITCH BRAKE PEDAL	Avail to order Our Price: $29.33
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $127.14
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $70.57
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $39.01
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $130.42
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $352.09
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237		Avail to order Our Price: $31.79

Open All

Select Group and TAV

< Previous Next >

TAV: 129.04.00 - INTAKE MANIFOLD

2009 Lamborghini GALLARDO LP 560-4 SPYDER USA INTAKE MANIFOLD (129.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L133920B	COVER COVER	1 req	Avail to order Our Price: $415.36
2	07L133185H	INTAKE MANIFOLD, FUEL MANIFOLD	1 req	Avail to order Our Price: $1,533.43
3	07L133062F	THROTTLE VALVE MOTOR-DRIVEN THROTTLE BODY	2 req	Avail to order Our Price: $969.18
4	N10405702	screw SCREW M6X45	8 req	Current Stock: 7 Our Price: $2.00
5	420131541	VACUUM TANK VACUUM TANK ASSEMBLY	1 req	Avail to order Our Price: $66.47
6	420133750	VACUUM BOOSTER PIPE ASSEMBLY	1 req	Avail to order Our Price: $169.72
7	WHT003265	SCREW SCREW 6X15	5 req	Avail to order Our Price: $7.82
8	07L133073F	SEAL,ADAPTER GASKET	2 req	Avail to order Our Price: $28.59
9	07L133588	DECOUPLING ELEMENT SCREW	12 req	Avail to order Our Price: $34.02
10	07L133109AB	FLANGE MANIFOLD (FROM ENGINE CEH002327)	1 req	Avail to order Our Price: $820.31
10	07L133109J	FLANGE MANIFOLD (UP TO ENGINE CEH002326)	1 req	Avail to order Our Price: $1,585.54
11	07L129717E	GASKET GASKET	5 req	Avail to order Our Price: $29.78
12	07L198717A	SET GASKET RINGS 5 GASKET PER KIT	1 req	Avail to order Our Price: $48.54
13	07L907386	POTENTIOMETER POTENTIOMETER	1 req	Avail to order Our Price: $91.41
14	N10535603	SCREW SCREW 3X16	2 req	Avail to order Our Price: $2.00
15	07L133110AB	FLANGE MANIFOLD (FROM ENGINE CEH002327)	1 req	Avail to order Our Price: $820.31
15	07L133110J	FLANGE MANIFOLD (UP TO ENGINE CEH002326)	1 req	Avail to order Our Price: $1,615.31
16	07L907386	POTENTIOMETER POTENTIOMETER	1 req	Avail to order Our Price: $91.41
17	N10535603	SCREW SCREW 3X16	2 req	Avail to order Our Price: $2.00
18	07L129717E	GASKET GASKET	5 req	Avail to order Our Price: $29.78
19	07L198717A	SET GASKET RINGS 5 GASKET PER KIT	1 req	Avail to order Our Price: $48.54
20	079906036D	HYDRAULIC INJECTOR INJECTOR (ALSO USE KIT 06E998907 REF. 32)	10 req	Avail to order Our Price: $267.24
21	N91063801	TAP END STUD STUD BOLT M6X62	10 req	Current Stock: 3 Our Price: $3.06
22	N01508213	HEXAGON FLANGE NUT NUT M6	10 req	Current Stock: 4 Our Price: $2.00
23	N10470703	HEXALOBULAR SOCKET SCREW M6X50	12 req	Current Stock: 11 Our Price: $2.31
24	N90925202	SCREW SCREW 6X16	2 req	Avail to order Our Price: $2.00
25	07L133240H	HOSE PIPE ASSEMBLY	1 req	Avail to order Our Price: $206.94
26	07L133240F	HOSE PIPE ASSEMBLY	1 req	Avail to order Our Price: $22.86
27	06H906517B	ACC VALVE VALVE AKF	1 req	Avail to order Our Price: $54.64
28	N90686701	SPRING CLAMP CLAMP	4 req	Avail to order Our Price: $2.09
29	07L133847	CLAMP CLAMP	1 req	Current Stock: 9 Our Price: $2.00
30	07L103320H	BRACKET BRACKET	1 req	Avail to order Our Price: $16.30
31	06H906517B	ACC VALVE VALVE AKF	1 req	Avail to order Our Price: $54.64
32	06E998907	REPAIR KIT REPAIR KIT FOR INJECTOR	10 req	Avail to order Our Price: $36.56
33	07L133588A	DECOUPLING ELEMENT THREADED BUSH	12 req	Avail to order Our Price: $18.25
34	07L133394AC	HOSE PIPE ASSEMBLY	1 req	Avail to order Our Price: $41.99
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
