2009 GALLARDO LP 560-4 COUPE - JAPAN

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137T	RIBBED V-BELT RIBBED V-BELT		Current Stock: 4 Our Price: $206.26

Brakes

PN	Item
400698151A	SEE PN 420698151F SET BRAKE	Avail to order Our Price: $1,122.15
420698451D	E-BRAKE PAD SET GALLARDO LP560 SET BRAKE LININGS	Current Stock: 1 Our Price: $299.78
420698451B	REAR PAD SET GALLARDO LP560 SET BRAKE	Current Stock: 12 Our Price: $506.69
400698151E	SET BRAKE LININGS SET BRAKE LININGS	Avail to order Our Price: $1,122.15
0R1400233	GALLARDO LP560 CARBON-CERAMIC BRAKE KIT BLACK CARBO-CERAMIC BRAKES KIT BLACK (WITH BLACK BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $26,091.93
0R1400234	GALLARDO LP 560-4 COUPE KIT CARBON-CERAMIC BRAKE CARBO-CERAMIC BRAKES KIT YELLOW (WITH YELLOW BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705) GALLARDO LP 560-4 COUPE EUROPE	Avail to order Our Price: $26,091.93
0R1400235	GALLARDO LP560 CARBO-CERAMIC BRAKES KIT SILVER CARBO-CERAMIC BRAKES KIT SILVER (WITH SILVER BRAKE CALIPERS - SUPPLY VIN - SEE THE WORKSHOP MANUAL CHAPTER 760705)	Avail to order Our Price: $26,091.93
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO	Current Stock: 10 Our Price: $1,031.98
4S0698151K	SET OF BRAKE PADS FOR CARBOCERAMIC DISC SET OF BRAKE PADS FOR DISC CARBOCERAMIC BRAKES OLD PN 4E0698151G	Current Stock: 1 Our Price: $938.30

Common repairs and upgrades

PN	Item
079115561J	SPIN-ON FILTER SPIN-ON FILTER	Avail to order Our Price: $75.82
0R1400313	LP560 AND LP570 SERVICE KIT 1 - AIR-CABIN-OIL FILTERS KIT SERVICE KIT 1 - 2 CABIN, 2 AIR AND 1 OIL FILTER INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTER 1X 4F0898438C POLLEN FILTER 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $399.23
0R1400314	GALLARDO 2009-2014 SERVICE KIT - AIR-CABIN-OIL FILTER +PLUGS+BELT KIT AIR-CABIN-OIL FILTER +PLUGS+BELT KIT KIT SERVICE 2 INCLUDES: 1X 079198405E OIL FILTER 2X 420133844D AIR FILTERS 1X 4F0898438C POLLEN FILTER 10X 06H905601A SPARK PLUGS 1X07L903137T ALTERNATOR BELT 1X N0138322 COPPER WASHER 1X N0138486 COPPER WASHER	Avail to order Our Price: $664.29
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $27.66
900000170	TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER TUTELA CS SPEED FLUID -OIL LIFTING SYSTEM 1 LITER	Current Stock: 6 Our Price: $61.26

Drivetrain

PN	Item
086141671K	SEE PN 086141671M CONCENTRIC SLAVE C WHEN A PART IS SUPERCEDED THE PRICE IS NO LONGER UPDATED FOR THE OLD PART NUMBER	Avail to order Our Price: $858.77
07L105269J	GALLARDO LP560 CLUTCH (MANUAL) CLUTCH FLYWHEEL (MANUAL GEARBOX) GALLARDO LP560 CLUTCH (MANUAL)	Current Stock: 1 Our Price: $4,249.56
07L105269M	SEE PN 07L105269K COMPLETE CLUTCH ASSEMBLY LP560	Avail to order Our Price: $4,249.56
079198405E	OIL FILTER GALLARDO/HURACAN LP SERIES OIL FILTER GALLARDO LP SERIES	Current Stock: 6 Our Price: $89.00
07L105269K	BALANCED CLUTCH ASSEMBLY EGEAR 560 BALANCED CLUTCH ASSEMBLY EGEAR 560	Current Stock: 5 Our Price: $5,427.94
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER FOR A LOWER COST ALTERNATIVE SEE OE SPEC BUT NON-OEM PN 086141671L-ALT IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,091.61
07L105269L	CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL CLUTCH FLYWHEEL (MANUAL GEARBOX) FLYWHEEL	Avail to order Our Price: $6,252.88
086301517	OIL FILTER GEARBOX OIL FILTER FOR GEARBOX	Avail to order Our Price: $141.07
N0138495	O-RING / WASHER O-RING	Current Stock: 47 Our Price: $3.45

Fuel-Air

PN	Item
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $48.35
420133844D	AIR FILTER GALLARDO LP 560-4 FILTER ELEMENT PERFORMANCE FILTER AVAILABLE, SEE PN: 420133844DZ	Current Stock: 1 Our Price: $135.23
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $42.69
4F0201511E	FUEL FILTER - GALLARDO LP 560-4 FUEL FILTER - GALLARDO LP 560-4	Current Stock: 8 Our Price: $87.67
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $122.39
06E906051K	FUEL PRESSURE SENSOR FUEL PRESSURE SENSOR	Current Stock: 1 Our Price: $133.02
420133844DZ	PAIR HIGH FLOW K&N AIR FILTER GALLARDO LP 550,560-4,570 FILTER ELEMENT	Current Stock: 2 Our Price: $227.32

Fuses-Bulbs-Relays

PN	Item
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.29
N01713118	FUSE FUSE	Current Stock: 18 Our Price: $1.40
N10566103	DISCHARGE LAMP DISCHARGE LAMP	Avail to order Our Price: $298.27
400941107	LIGHT LIGHT	Avail to order Our Price: $24.44
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - READ DESCRIPTION) SIDE MARKER LIGHT - THESE ARE FOR OTHER MARKETS AND MODELS BUT ARE POPULAR CONVERSIONS FOR OTHER MODELS AND MAKES. WE MAKE NO WARRANTY IF THEY DOES NOT WORK, FIT OR BREAK ANY LAWS)	Current Stock: 2 Our Price: $294.35
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - READ DESCRIPTION) SIDE MARKER LIGHT - THESE ARE FOR OTHER MARKETS AND MODELS BUT ARE POPULAR CONVERSIONS FOR OTHER MODELS AND MAKES. WE MAKE NO WARRANTY IF THEY DOES NOT WORK, FIT OR BREAK ANY LAWS)	Avail to order Our Price: $294.35

Gaskets

PN	Item	Diagram
N0138493	WASHER WASHER		Current Stock: 47 Our Price: $4.16

Ignition

PN	Item
101905631G	SPARK PLUG SPARK PLUG	Current Stock: 48 Our Price: $35.16
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $493.18
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $102.38
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL FOR INDIVIDUAL COILS SEE PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $480.17

Misc

PN	Item
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $106.01
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
0R1400308	TOOL KIT GALLARDO 2009-2014 TOOL KIT GALLARDO 2009-2014 KIT TROUSSE GALLARDO DA MY'09	Avail to order Our Price: $447.76
0R1400466	VIDEORECORDING AND TELEMETRY VIDEORECORDING AND TELEMETRY	Avail to order Our Price: $10,988.32
400093050D	CTEK US-CD BATTERY CHARGER INPUT 110-120VAC OUTPUT MAX 4.3A, 12V BACK DRAIN LESS THAN 1.5AM/MONTH	Avail to order Our Price: $417.39
7H0906271A-ALT	FUEL PUMP MODULE ASSEMBLY FUEL PUMP MODULE ASSEMBLY 7H0906271A FUEL VAPOR LEAK DETECTION PUMP THE FACTORY IS NO LONGER PROVIDING THE ORIGINAL ITEM. THIS IS A COMPATIBLE REPLACEMENT	Avail to order Our Price: $7,629.44

Sensors

PN	Item
07L919501A	WATER TEMPERATURE SENSOR WATER TEMPERATURE SENSOR	Current Stock: 3 Our Price: $371.24
1K2945511	BRAKE PEDAL SWITCH SWITCH BRAKE PEDAL	Avail to order Our Price: $29.05
086141297	CLUTCH SENSOR CLUTCH SENSOR	Current Stock: 1 Our Price: $512.59
400698137	WORN PADS SENSOR WORN PADS SENSOR	Current Stock: 2 Our Price: $125.76
07L905163A	SEE PN 07L905163C PHASE SENSOR	Avail to order Our Price: $38.61
059919523A	TEMPERATURE SENDER TEMPERATURE SENDER	Current Stock: 6 Our Price: $69.79
086927321	CRANK / FLYWHEEL / TIMING SENSOR ELECTROMAGNETIC PROBE	Avail to order Our Price: $129.03
1K0998262L	LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $361.59
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $47.65
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $143.73
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $143.73
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $185.62

Tools and Tookits

PN	Item
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL	Current Stock: 2 Our Price: $245.40
V03839111CJ	CRANKSHAFT V10 LOCKING PIN T40237 CRANKSHAFT V10 LOCKING PIN T40237	Avail to order Our Price: $38.70
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.	Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 615.05.00 - FRONT BRAKES DISCS STD

2009 Lamborghini GALLARDO LP 560-4 COUPE JAPAN FRONT BRAKES DISCS STD (615.05.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	420615301B	BRAKE DISK FRONT BRAKE DISK	2 req	Current Stock: 17 Our Price: $849.91
1	420615301D	FRONT BRAKE DISK - LP560/570/STS/ FRONT BRAKE DISK (REPLACE FOR AXLE)	2 req	Avail to order Our Price: $907.39
2	400615105BD	BRAKE CALIPER LH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS - FROM VIN ALA09366 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,203.75
2	400615105BD	BRAKE CALIPER LH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS - UNTIL THE VIN ALA09365 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,203.75
2	400615105BE	BRAKE CALIPER LH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS - FROM VIN ALA09366 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,837.14
2	400615105BE	BRAKE CALIPER LH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS - UNTIL THE VIN ALA09365 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,837.14
2	400615105BF	BRAKE CALIPER LH FRONT BRAKE CALIPER (GREY FRONT CALIPERS - FROM VIN BLA10052 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $4,249.56
2	400615105AM	BRAKE CALIPER LH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	1 req	Avail to order Our Price: $2,342.06
2	400615105AN	BRAKE CALIPER LH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	1 req	Avail to order Our Price: $2,481.99
2	400615105AP	BRAKE CALIPER LH FRONT BRAKE CALIPER (GREY FRONT CALIPERS)	1 req	Avail to order Our Price: $2,474.64
2	400615106AM	BRAKE CALIPER RH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	1 req	Avail to order Our Price: $2,342.06
2	400615106AN	NLA SEE 400615105BE AND 400615106BE RH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	1 req	*See Description
2	400615106AP	BRAKE CALIPER RH FRONT BRAKE CALIPER (GREY FRONT CALIPERS)	1 req	Avail to order Our Price: $2,474.64
2	400615105BF	BRAKE CALIPER LH FRONT BRAKE CALIPER (GREY FRONT CALIPERS - UNTIL THE VIN BLA10051 REPLACE PER AXLE)	1 req	Avail to order Our Price: $4,249.56
2	400615105BG	BRAKE CALIPER LH FRONT BRAKE CALIPER (ORANGE FRONT CALIPERS - FROM VIN ALA09374 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,203.75
2	400615105BG	BRAKE CALIPER LH FRONT BRAKE CALIPER (ORANGE FRONT CALIPERS - UNTIL THE VIN ALA09373 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,203.75
2	400615106BD	BRAKE CALIPER RH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS - FROM VIN ALA09366 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,203.75
2	400615106BD	BRAKE CALIPER RH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS - UNTIL THE VIN ALA09365 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,203.75
2	400615106BE	BRAKE CALIPER RH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS - FROM VIN ALA09366 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,837.14
2	400615106BE	BRAKE CALIPER RH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS - UNTIL THE VIN ALA09365 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,837.14
2	400615106BF	BRAKE CALIPER RH FRONT BRAKE CALIPER (GREY FRONT CALIPERS - FROM VIN BLA10052 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $4,249.56
2	400615106BF	BRAKE CALIPER RH FRONT BRAKE CALIPER (GREY FRONT CALIPERS - UNTIL THE VIN BLA10051 REPLACE PER AXLE)	1 req	Avail to order Our Price: $4,249.56
2	400615106BG	BRAKE CALIPER RH FRONT BRAKE CALIPER (ORANGE FRONT CALIPERS - FROM VIN ALA09374 INTERCHANGEABLE 1 TO 1)	1 req	Avail to order Our Price: $3,203.75
2	400615106BG	BRAKE CALIPER RH FRONT BRAKE CALIPER (ORANGE FRONT CALIPERS - UNTIL THE VIN ALA09373 REPLACE PER AXLE)	1 req	Avail to order Our Price: $3,203.75
3	420611707B	BRAKE HOSE HOSE	2 req	Avail to order Our Price: $114.77
3	420611707B	BRAKE HOSE HOSE	2 req	Avail to order Our Price: $114.77
5	420611846A	BRACKET,BRAKE HOSE RH BRACKET	1 req	Avail to order Our Price: $24.26
5	420611846A	BRACKET,BRAKE HOSE RH BRACKET	1 req	Avail to order Our Price: $24.26
6	420611845B	BRACKET,BRAKE HOSE LH BRACKET	1 req	Avail to order Our Price: $25.86
6	420611845B	BRACKET,BRAKE HOSE LH BRACKET	1 req	Avail to order Our Price: $25.86
7	N01029316	HEXAGON HEAD BOLT SCREW M8X16	2 req	Avail to order Our Price: $1.20
7	N01029316	HEXAGON HEAD BOLT SCREW M8X16	2 req	Avail to order Our Price: $1.20
8	WHT001330A	HEXAGON SOCKET SCREW M12X1,5X77X30	2 req	Current Stock: 3 Our Price: $14.88
8	WHT001330A	HEXAGON SOCKET SCREW M12X1,5X77X30	2 req	Current Stock: 3 Our Price: $14.88
9	420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE PAD SET	1 req	Current Stock: 10 Our Price: $1,031.98
9	420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE PAD SET	1 req	Current Stock: 10 Our Price: $1,031.98
10	8A0615273	BLEEDER SCREW BLEEDER/BOOT	2 req	Avail to order Our Price: $26.39
10	8A0615273	BLEEDER SCREW BLEEDER/BOOT	2 req	Avail to order Our Price: $26.39
11	7D0611483	DUST CAP BOOT	2 req	Avail to order Our Price: $16.38
11	7D0611483	DUST CAP BOOT	2 req	Avail to order Our Price: $16.38
12	3D0698269	RETAINING SPRING JOURNAL AND CLIP	2 req	Avail to order Our Price: $61.02
12	3D0698269	RETAINING SPRING JOURNAL AND CLIP	2 req	Avail to order Our Price: $61.02
13	3D0698472	GASKET SET SEAL RING	2 req	Avail to order Our Price: $67.48
13	3D0698472	GASKET SET SEAL RING	2 req	Avail to order Our Price: $67.48
15	400698137A	WORN PADS SENSOR ELECTRIC CABLE	2 req	Avail to order Our Price: $71.11
15	400698137A	WORN PADS SENSOR ELECTRIC CABLE	2 req	Avail to order Our Price: $71.11
16	N10648301	HEXALOBULAR SOCKET SCREW M6X16	2 req	Avail to order Our Price: $1.50
16	N10648301	HEXALOBULAR SOCKET SCREW M6X16	2 req	Avail to order Our Price: $1.50
19		FRONT HUB CARRIER (SEE TABLE 407.02.00)	1 req
19		FRONT HUB CARRIER (SEE TABLE 407.02.00)	1 req
21		BRACKET (SEE TABLE 407.05.00)	2 req
21		BRACKET (SEE TABLE 407.05.00)	2 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
