2007 Lamborghini GALLARDO SPYDER CANADA TIMING CHAIN COVER

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137C	Alternator Belt Alternator Belt		Avail to order Our Price: $51.00
079903133D	SEE PN 079903133R BELT TENSIONER		Avail to order Our Price: $112.33

Brakes

PN	Item
4E0698151G	See PN 4S0698151K Front Brake pads Set carbon ceramic brakes	Avail to order Our Price: $870.93
400698151	Brake Pad Kit Front - Gallardo Front Brake Pad Kit	Avail to order Our Price: $1,184.32
400698451	Brake Pad Kit Rear - Murcielago - Gallardo - Sold as 2 pair Rear Brake Pad Kit Set of 2 Pair for both Rear Rotors	Avail to order Our Price: $712.68
400798041	E-Brake Pad Kit - Gallardo Gallardo E-Brake Pad Kit	Avail to order Our Price: $223.93

Drivetrain

PN	Item
086141671A	GALLARDO THROW OUT BEARING - MANUAL (read description!) CONCENTRIC SLEEVE ASS. Also order PNs n90039604 & n90111301 o-ring''''s	Current Stock: 2 Our Price: $6,185.80
07L115561C	OIL FILTER - Gallardo OIL FILTER	Avail to order Our Price: $77.08
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $448.13
07L105269F	GALLARDO CLUTCH - ALL YEARS (E-GEAR) (ALSO FOR 04-05 MANUAL) COMPL.	Avail to order Our Price: $5,515.86
07L105269G	GALLARDO CLUTCH - MANUAL (NO E-GEAR) only for manual gear box	Current Stock: 2 Our Price: $5,210.67
086325059REBUILD	GALLARDO E-GEAR ACTUATOR REBUILD SERVICE FOR PN 086325059 - Also order Sensors PN 086907811 This is a service to rebuild a damage Actuator - PN 086325059 ** Rebuild service does not include replacing your sensors. We recommend replacing these sensors after your rebuild: Order sensor kit: PN 086907811 TYPICAL REBUILD TURNAROUND 1.5-2 weeks 1 year warranty unlimited miles (nontransferable)	Avail to order Our Price: $10,216.96
086325081REBUILD	Egear unit complete - REBUILD SERVICE for 086325081 This is for the service of rebuilding the complete Egear Assembly. YOU PROVIDE UNIT. Valves are additional	Avail to order Our Price: $4,850.15
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,114.04
0R1400452	KIT E-GEAR PIPES KIT E-GEAR PIPES	Avail to order Our Price: $5,011.74
61595014	Oil filter wrench ENGINE OIL FILTER	Avail to order Our Price: $286.89
07L115433	GALLARDO OIL FILTER BOX OIL FILTER BOX	Avail to order Our Price: $170.47

Fuel-Air

PN	Item
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $284.18
AMGAIR	Hi-Performance BMC Air Filter - Gallardo - SPORT Air Filters for Gallardo Sold Each BMC 523/03	Avail to order Our Price: $77.63
07L133843D	Air Filter Sport Gallardo Filter element Gallardo OEM SPORT 100k Miles (2004 - 2008)	Current Stock: 3 Our Price: $87.35
06A906031BA	GALLARDO FUEL INJECTOR INJECTOR	Avail to order Our Price: $276.17
0R1400128	GALLARDO 2004-2008 SERVICE KIT - HP Air-Cabin-Oil Filter Kit SPORT 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers,	Avail to order Our Price: $634.22
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $46.31
0R1400132	GALLARDO 2004-2008 SERVICE KIT - HP Air-Cabin-Oil-Fuel Filters + Plugs Kit SPORT : 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 10 spark plugs, 2 fuel filters, 2 washers	Avail to order Our Price: $1,022.78
0R1400130	GALLARDO 2004-2008 SERVICE KIT - HP Air-Cabin-Oil Filter + Plugs Kit SPORT 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers, 10 NGK spark plugs	Avail to order Our Price: $665.48
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 1 Our Price: $120.44
8L0919051H	NLA (No Longer Available) FEED UNIT	Avail to order Our Price: $677.39
400201511AZ	OE Spec Aftermarket Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Avail to order Our Price: $91.69
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
07L133843KN	K&N Air Filter - 04-08 Gallardo K&N's replacement air filters are designed to increase horsepower and acceleration while providing excellent filtration. These filters are washable and reusable and are custom designed to fit into your existing factory air box. Their drop-in design means adding performance is simple.	Avail to order Our Price: $83.43

Fuses-Bulbs-Relays

PN	Item
N10445601	SEE PN N10445602 Headlight BULB H21W-12V21W	Avail to order Our Price: $27.92
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.11
N01713118	FUSE Please Check your Part Manual for a Description	Current Stock: 18 Our Price: $2.00
N10445703	HEADLIGHT BULB D2SLL-12V35W Please Check your Part Manual for a Description	Current Stock: 8 Our Price: $194.91
N0177326	BULB tail light BULB	Avail to order Our Price: $5.96
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $316.18
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $316.18

Gaskets

PN	Item	Diagram
0R1400126	GASKETS SET (FROM VIN 4LA0379) GASKETS SET (FROM VIN 4LA0379)		Avail to order Our Price: $3,468.82

Ignition

PN	Item
400905619	Spark plug Gallardo (2004 - 2008) Spark plug NGK R PFR76	Avail to order Our Price: $46.50
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F	Avail to order Our Price: $470.45
400915105C	NLA (No Longer Available) 9A78DT DEKA	Current Stock: 1 Our Price: $846.59
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $422.55

Misc

PN	Item
401955425	SEE PN 401955425C WIPER BLADE DRIVER SIDE LHD	Avail to order Our Price: $168.88
LOCREV5G	LOC REV 5 Gallardo Sport Exhaust System 2004 -2008 TEMPORARILY UNAVAILABLE EXHAUST IS TEMPORARILY UNAVAILABLE. CHECK BACK LATER FOR UPDATES	Avail to order Our Price: $9,709.03
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $113.97
07L103051C	SEAL SEAL	Avail to order Our Price: $59.55
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
06A906262AT	O2 SENSOR-LAMBDA PROBE LAMBDA PROBE	Avail to order Our Price: $149.62
400919529C	SEE PN 0R1400030 TEMPERATURE SENSOR	Avail to order Our Price: $492.78
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $364.01
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $497.25
3B0945511C	SEE PN 1K2945511 SWITCH,BRAKE PEDAL	Avail to order Our Price: $11.17
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $123.42
06E905163	PHASE SENSOR PHASE SENSOR	Current Stock: 5 Our Price: $100.50
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $126.55
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $890.28
036906262J	LAMBDA PROBE Please Check your Part Manual for a Description	Avail to order Our Price: $439.19
400907475A	PEDAL VALUE (Potentiometer) PEDAL VALUE	Avail to order Our Price: $1,927.95
4F0907275D	See PN 7PP907275F WHEEL ELECTRONICS	Avail to order Our Price: $203.22
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $46.75
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $46.75

Open All

Select Group and TAV

< Previous Next >

TAV: 103.04.00 - TIMING CHAIN COVER - PROPELLER SHAFT

2007 Lamborghini GALLARDO SPYDER CANADA TIMING CHAIN COVER - PROPELLER SHAFT (103.04.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L103173F	TIMING CHAIN COVER COVER	1 req	Avail to order Our Price: $1,249.08
2	N10124303	SEE PN N10124308 SCREW M6X20.0	6 req	Avail to order Our Price: $2.00
3	WHT000198	STUD STUD BOLT M10XM12X84	3 req	Avail to order Our Price: $52.18
5	N10261306	FLANGED NUT M10 NUT M10	9 req	Avail to order Our Price: $2.00
6	07L103051A	Main Seal SEAL RING	1 req	Avail to order Our Price: $70.72
7	N10156203	No Description - Please Check your book SCREW M6X30.0	9 req	Avail to order Our Price: $2.00
8	N90462502	SCREW M8X32 SCREW M8X32.0	10 req	Avail to order Our Price: $2.00
9	WHT002302	TAP END STUD STUD BOLT M10 2MX59	2 req	Avail to order Our Price: $6.48
10	086311101A	TANSMISSION SHAFT INPUT SHAFT PROPELLER SHAFT	1 req	Avail to order Our Price: $1,511.10
10		INPUT SHAFT PROPELLER SHAFT (NOT FOR 2WD MODEL)	0 req
11	086311435A	ROLLER BEARING RACE BEARING	1 req	Avail to order Our Price: $84.42
11		BEARING (NOT FOR 2WD MODEL)	0 req
12	086311430	ROLLER BEARING RACE BEARING	1 req	Avail to order Our Price: $37.07
12		BEARING (NOT FOR 2WD MODEL)	0 req
13	N0123191	RETAINER RING 62X2 SEEGER 62X2.00	1 req	Current Stock: 3 Our Price: $6.11
13		SEEGER 62X2.00 (NOT FOR 2WD MODEL)	0 req
14	N0122902	SEGER SEEGER 52X2.00	1 req	Current Stock: 9 Our Price: $4.85
14		SEEGER 52X2.00 (NOT FOR 2WD MODEL)	0 req
15	086311807	TRANSMISSION SHAFT FLANGE	1 req	Avail to order 1 Used Available Our Price: $227.04
15		FLANGE (NOT FOR 2WD MODEL)	0 req
16	086311495	RING NUT M20x1.5 RING NUT	1 req	Avail to order Our Price: $34.02
16		RING NUT (NOT FOR 2WD MODEL)	0 req
17	WHT002302	TAP END STUD STUD BOLT M10 2MX59	2 req	Avail to order Our Price: $6.48
18	WHT000197	STUD STUD BOLT M10XM12X90	1 req	Avail to order Our Price: $26.13
19	WHT002301	TAP END STUD STUD BOLT M10 2MX167	1 req	Avail to order Our Price: $30.08
20		COVER (CANNOT BE SOLD SEPARATELY)	0 req
21		PLUG M10X1.00X10.0 (CANNOT BE SOLD SEPARATELY)	0 req
22		WASHER A10X14 (CANNOT BE SOLD SEPARATELY)	0 req
23		ENGINE BLOCK (SEE TABLE 1030100)	0 req
24		PLUG (VALID FOR A MODEL 2WD)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
