TAV: 971.01.00 - ELETTRICAL SYSTEM

2006 Lamborghini GALLARDO SPYDER USA ELETTRICAL SYSTEM (971.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	407971135B	HARNESS,PASSENGER CENTRAL WIRING HARNESS (NAVIGATOR / REAR VIEW CAMERA)	1 req	Avail to order Our Price: $11,500.68
1	407971135E	HARNESS,PASSENGER CENTRAL WIRING HARNESS (NAVIGATOR / REAR VIEW CAMERA / TV)	1 req	Avail to order Our Price: $5,545.63
2		RELAY BOX WIRING HARNESS (VALID FOR A DIFFERENT MODEL)	0 req
3	400971036B	HARNESS,DOOR DOOR WIRING HARNESS (PASSENGER SIDE)	1 req	Avail to order Our Price: $242.67
4	07L905532F	IGNITION CABLE INJECTION WIRING HARNESS 1-5 (AUTOMATIC GEARBOX / REAR VIEW CAMERA)	1 req	Avail to order Our Price: $7,399.15
4	07L905532B	IGNITION CABLE INJECTION WIRING HARNESS 1-5 (MANUAL GEARBOX VERSIONS / REAR VIEW CAMERA)	1 req	Avail to order Our Price: $5,880.61
5	407971258	relais engine box ENGINE RELAY BOX WIRING HARNESS	1 req	Avail to order Our Price: $1,689.74
6	407971771	HARNESS WIRING HARNESS (E-GEAR)	1 req	Avail to order Our Price: $228.52
8	400971194A	HARNESS WIRING HARNESS	1 req	Avail to order Our Price: $234.49
10	07L905534C	IGNITION CABLE INJECTION WIRING HARNESS 6-10	1 req	Avail to order Our Price: $1,652.53
11	400970264	tunnel harness TUNNEL WIRING HARNESS	1 req	Avail to order Our Price: $67.67
12	401971035B	HARNESS,DOOR DOOR WIRING HARNESS (DRIVER SIDE)	1 req	Avail to order Our Price: $250.12
13	400971235A	CABLE- BATTERY/ DISCONNECT CABLE	1 req	Avail to order Our Price: $586.58
14		CABLE (SEE TABLE 971.05.00 - SEE REF. 2)	1 req
15	400971793B	HARNESS,STARTER CABLE (CABLE STARTER MOTOR EXCITATION)	1 req	Avail to order Our Price: $166.00
16		AIRBAG WIRING HARNESS (VALID FOR A DIFFERENT MODEL)	0 req
17	407971315E	HARNESS,DASHBOARD WIRING HARNESS DASHBOARD (WITH GPS)	1 req	Avail to order Our Price: $1,734.41
17	407971315D	HARNESS,DASHBOARD WIRING HARNESS DASHBOARD	1 req	Avail to order Our Price: $1,360.73
18	400971679A	HARNESS,GLOVE WIRING HARNESS (PASSENGER SIDE DRAWER)	1 req	Avail to order 1 Used Available Our Price: $125.80
19	400971899	CABLE HOLDER CLAMP (Ø 23 MM)	3 req	Avail to order Our Price: $8.26
19	400971930	CABLE HOLDER CLAMP (Ø 31 MM)	1 req	Avail to order Our Price: $2.90
20	3D0971838A	CABLE TIE CLAMP	5 req	Avail to order Our Price: $2.84
21	3D0971838D	CABLE TIE BASE CLAMP	3 req	Avail to order Our Price: $2.84
22	5M0971838	CABLE TIE BASE CLAMP	2 req	Current Stock: 4 Our Price: $2.84
23	400971503	BRACKET, CABLE SUPPORT LH BRACKET	1 req	Avail to order Our Price: $30.97
24	400971504	BRACKET, CABLE SUPPORT RH BRACKET	1 req	Avail to order Our Price: $30.97
25	N10082911	HEX. BOLT WITH WASHER SCREW M6X15 (M6X15)	4 req	Current Stock: 2 Our Price: $2.00
26	N10003703	HEX.HEAD SCREW W. SCREW M6X17.00 (M6X17)	4 req	Avail to order Our Price: $2.00
27	1J0973803	FLAT CONNECTOR HOUSING CONNECTOR FOR LICENSE PLATES LIGHTS WIRING	1 req	Avail to order Our Price: $6.92
28	3D0973703	FLAT CONTACT HOUSING CONNECTOR FOR LICENSE PLATES LIGHTS WIRING	1 req	Current Stock: 1 Our Price: $9.46
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
