2005 GALLARDO COUPE - AUSTRALIA

Maintenance Parts:

Belts

PN	Item	Diagram
07L903137C	Alternator Belt Alternator Belt		Current Stock: 2 Our Price: $51.00

Brakes

PN	Item
400698151	Brake Pad Kit Front - Gallardo Front Brake Pad Kit	Avail to order Our Price: $1,220.04
400698451	Brake Pad Kit Rear - Murcielago - Gallardo - Sold as 2 pair Rear Brake Pad Kit Set of 2 Pair for both Rear Rotors	Avail to order Our Price: $733.51
400798041	E-Brake Pad Kit - Gallardo Gallardo E-Brake Pad Kit	Avail to order Our Price: $230.62
420698151F	FRONT BRAKE LININGS SET BREMBO FRONT BRAKE LININGS SET BREMBO	Current Stock: 10 Our Price: $399.00

Common repairs and upgrades

PN	Item
400823359B-ALT	Front Hood Gas Cylinder Black - Gallardo Front Hood Gas Cylinder Black All Gallardo years	Current Stock: 10 Our Price: $35.99
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89

Drivetrain

PN	Item
086141671A	GALLARDO THROW OUT BEARING - MANUAL (read description!) CONCENTRIC SLEEVE ASS. Also order PNs n90039604 & n90111301 o-ring''''s 086141671K is compatible with Gallardo according to customers who have used it instead.	Current Stock: 2 Our Price: $6,371.90
07L115561C	OIL FILTER - Gallardo OIL FILTER	Current Stock: 2 Our Price: $79.51
079905381	TRANSDUCER POS. TRANSDUCER POS.	Avail to order Our Price: $463.01
07L105269F	GALLARDO CLUTCH - ALL YEARS (E-GEAR) COMPLETE CLUTCH .(ALSO FOR 04-05 MANUAL see 07L105269C)	Avail to order Our Price: $5,687.07
07L105269G	GALLARDO CLUTCH - MANUAL (NO E-GEAR) only for manual gear box	Current Stock: 2 Our Price: $5,366.99
086325059REBUILD	GALLARDO E-GEAR ACTUATOR REBUILD SERVICE FOR PN 086325059 - Also order Sensors PN 086907811 This is a service to rebuild a damage Actuator - PN 086325059 ** Rebuild service does not include replacing your sensors. We recommend replacing these sensors after your rebuild: Order sensor kit: PN 086907811 TYPICAL REBUILD TURNAROUND 1.5-2 weeks 1 year warranty unlimited miles (nontransferable)	Avail to order Our Price: $10,216.96
086325081REBUILD	Egear unit complete - REBUILD SERVICE for 086325081 This is for the service of rebuilding the complete Egear Assembly. YOU PROVIDE UNIT. Valves are additional	Avail to order Our Price: $4,850.15
0R1400452	KIT E-GEAR PIPES KIT E-GEAR PIPES	Avail to order Our Price: $5,168.13
086141671L	THROW OUT BEARING - EGEAR CONCENTRIC SLAVE CYLINDER IF REPLACING ORIGINAL 04-08 ALLARDO EQUIPMENT ALSO SEE PN: N10124306 X3	Avail to order Our Price: $2,114.04
07L115433	GALLARDO OIL FILTER BOX OIL FILTER BOX	Avail to order Our Price: $174.94
61595014	OIL FILTER WRENCH ENGINE OIL FILTER WRENCH	Current Stock: 1 Our Price: $289.57
N0138495	O-RING DRAIN PLUG WASHER O-RING	Current Stock: 53 Our Price: $3.51

Fuel-Air

PN	Item
07L133843	Air Filter Gallardo sold individually FILTER ELEMENT SEE PN : 07L133843KN for aftermarket sport filter replacement	Current Stock: 2 Our Price: $41.29
07L133843D	Air Filter Sport Gallardo Filter element Gallardo OEM SPORT 100k Miles (2004 - 2008)	Current Stock: 3 Our Price: $90.08
400201511A	Fuel Filter - Diablo - Gallardo - Murcielago FUEL FILTER	Current Stock: 10 Our Price: $293.29
AMGAIR	Hi-Performance BMC Air Filter - Gallardo - SPORT Air Filters for Gallardo Sold Each BMC 523/03 2003-2006 V10- 5L 30-10132	Current Stock: 2 Our Price: $77.63
06A906031BA	FUEL INJECTOR GALLARDO FUEL INJECTOR GALLARDO	Avail to order Our Price: $276.17
0R1400127	GALLARDO 2004-2008 SERVICE KIT - Air-Cabin-Oil Filter Kit STANDARD 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers	Avail to order Our Price: $275.42
0R1400128	GALLARDO 2004-2008 SERVICE KIT - sport Air-Cabin-Oil Filter Kit SPORT 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers,	Avail to order Our Price: $653.57
0R1400129	GALLARDO 2004-2008 SERVICE KIT - Air-Cabin-Oil Filters + Plugs Kit STANDARD 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers, 10 NGK spark plugs	Avail to order Our Price: $620.82
0R1400130	GALLARDO 2004-2008 SERVICE KIT - HP Air-Cabin-Oil Filter + Plugs Kit SPORT 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers, 10 NGK spark plugs	Avail to order Our Price: $686.32
0R1400131	GALLARDO 2004-2008 SERVICE KIT - Engine-Cabin-Oil-Fuel Filters + Plugs Kit STANDARD 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 2 washers, 10 spark plugs, 2 fuel filters	Avail to order Our Price: $893.26
0R1400132	GALLARDO 2004-2008 SERVICE KIT - HP Air-Cabin-Oil-Fuel Filters + Plugs Kit SPORT : 2 engine Air Filters, 2 cabin air filters, 1 oil filter, 10 spark plugs, 2 fuel filters	Avail to order Our Price: $1,054.05
1J0907543A	TEMPERATURE SENSOR TEMPERATURE SENSOR	Current Stock: 1 Our Price: $46.31
4F0898438C	CABIN FILTER ELEMENT SOLD AS PAIR FILTER ELEMENT	Current Stock: 8 Our Price: $120.44
8L0919051H	GALLARDO FUEL PUMP STOCK FEED UNIT - NLA (No longer available) FROM ITALY'S FACTORY BUT WE HAVE ANOTHER SUPPLIER THAT IS EXACT SAME PART.	Current Stock: 4 Our Price: $698.24
4D0906321C	FUEL FILTER FILTER	Avail to order Our Price: $41.62
N10445602	BULB BULB	Avail to order Our Price: $17.64

Fuses-Bulbs-Relays

PN	Item
N01713118	FUSE FUSE	Current Stock: 18 Our Price: $2.00
N10525502	FUSE STRIP FUSE STRIP	Avail to order Our Price: $6.33
N0177326	BULB tail light BULB	Avail to order Our Price: $6.19
N10445703	HEADLIGHT BULB HEADLIGHT BULB	Current Stock: 8 Our Price: $200.99
400945119D	FRONT LEFT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Current Stock: 2 Our Price: $325.84
400945120D	FRONT RIGHT SIDE MARKER (CLEAR/COLORED - read description) SIDE MARKER LIGHT - These are for other markets and models but are popular conversions for other models and makes. We make no warranty if they does not work, fit or break any laws)	Avail to order Our Price: $325.84

Gaskets

PN	Item
0R1400125	GASKETS SET (UP TO VIN 4LA0378) GASKETS SET (UP TO VIN 4LA0378)	Avail to order Our Price: $5,180.89
0R1400126	GASKETS SET (FROM VIN 4LA0379) GASKETS SET (FROM VIN 4LA0379)	Avail to order Our Price: $3,573.03
07L103051A	MAIN SEAL RING FOR ENGINE ALB. SEAL RING FOR ENGINE ALB.	Avail to order Our Price: $70.72

Ignition

PN	Item
400905619	Spark plug Gallardo (2004 - 2008) Spark plug	Avail to order Our Price: $47.94
0R1400355	GALLARDO IGNITION COILS KIT SET OF 10 KIT 10 IGNITION COILS KIT BLACK (FROM THE ENGINE 07L01313 - INCLUDES 10 COIL For Individual Coils See PN 07K905715F OR 07K905715	Current Stock: 5 Our Price: $485.34
400915105C	95AH MOLL BATTERY 9A78DT DEKA NLA (No Longer Available at Factory)	Current Stock: 1 Our Price: $872.41
000915105DK	SEE PN 000915105DK BATTERY	Avail to order Our Price: $607.04
0011015742	IGNITION COIL GASKET IGNITION COIL GASKET	Current Stock: 35 Our Price: $7.15
07K905715G	IGNITION COIL VW OEM BRAND IGNITION COIL VW OEM BRAND	Current Stock: 6 Our Price: $100.95
400919529D	LEFT THERMOCOUPLE LEFT THERMOCOUPLE	Avail to order Our Price: $509.16

Misc

PN	Item
401955425	SEE PN 401955425C WIPER BLADE DRIVER SIDE LHD	Avail to order Our Price: $174.08
LOCREV5G	LOC REV 5 Gallardo Sport Exhaust System 2004 -2008 Excludes SL LOC REV 5 Gallardo Sport Exhaust System 2004 -2008 Excludes SL (Superleggera)	Current Stock: 2 Our Price: $5,999.99
401955425C	WIPER BLADE (GALLARDO / MURCIELAGO) WIPER BLADE	Current Stock: 1 Our Price: $117.47
079903133R	BELT TENSIONER BELT TENSIONER	Avail to order Our Price: $198.75
07L103051C	SEAL SEAL	Avail to order Our Price: $59.55
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78
0R1400009	SPARE PARTS KIT N.3 SPARE PARTS KIT N.3 -New Lamborghini Gallardo Service Spare Parts Kit 0R1400009. VIN 0090 to 0760	Current Stock: 1 Our Price: $1,049.58
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98

Sensors

PN	Item
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
07L919501A	Water Temperature Sensor Water Temperature Sensor	Current Stock: 3 Our Price: $375.18
400919529C	RIGHT THERMOCOUPLE TEMPERATURE SENSOR RIGHT THERMOCOUPLE	Avail to order Our Price: $506.18
036906262J	FRONT OXYGEN SENSOR FRONT OXYGEN SENSOR	Current Stock: 4 Our Price: $439.19
06E905163	PHASE SENSOR PHASE SENSOR	Current Stock: 5 Our Price: $100.50
07L919561B	OIL PRESSURE GAUGE SENDER OIL PRESSURE GAUGE SENDER	Avail to order Our Price: $917.08
086141297	CLUTCH SENSOR CLUTCH SENSOR	Avail to order Our Price: $497.25
086927321	Crank/Flywheel/Timing Sensor ELECTROMAGNETIC PROBE	Avail to order Our Price: $130.42
400698137	Worn Pads Sensor Worn Pads Sensor	Current Stock: 2 Our Price: $127.14
0R1400011	SPARE PARTS KIT N.5 - REFERNCE TSB - L140-07.04 (MY04 GALLARDO) SPARE PARTS KIT N.5 REFERNCE TSB - L140-07.04 (MY04 GALLARDO)	Current Stock: 15 Our Price: $1,239.17
400907475A	PEDAL VALUE (Potentiometer) PEDAL VALUE	Avail to order Our Price: $1,987.50
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $48.16
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72

Tools and Tookits

PN	Item	Diagram
u3x0R1400003	TOOL KIT BAG USED INCLUDES SCREWDRIVER AND WRENCH Incomplete tools kit USED SOLD AS IS - NONREFUNDABLE includes screwdriver and wrench		Current Stock: 1 Our Price: $200.00
62195015	CLUTCH ALIGNING TOOL CLUTCH ALIGNING TOOL		Current Stock: 2 Our Price: $203.22

Open All

Select Group and TAV

< Previous Next >

TAV: 701.09.00 - REAR FRAME ELEMENTS

2005 Lamborghini GALLARDO COUPE AUSTRALIA REAR FRAME ELEMENTS (701.09.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Gallardo Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	400801691	SUPPORT SUPPORT	1 req	Avail to order Our Price: $397.51
2	400801692	SUPPORT SUPPORT	1 req	Avail to order Our Price: $397.51
3	400803087	END PLATE LH LH SHEET	1 req	Avail to order Our Price: $236.72
4	400803088	END PLATE RH RH SHEET	1 req	Avail to order Our Price: $232.25
5		STABILIZING BRACKET (CANNOT BE SOLD SEE REF. 35)	0 req
6	400803501	SIDE MEMBER,WHEEL SIDE MEMBER	1 req	Avail to order Our Price: $672.92
7	400803502	SIDE MEMBER,WHEEL SIDE MEMBER	1 req	Avail to order Our Price: $672.92
8	400803691	SUPPORT BRACKET	1 req	Avail to order Our Price: $340.93
9	400803692	SUPPORT BRACKET	1 req	Avail to order Our Price: $340.93
10	400804087	INTERSECTION PART INTERSECTION PART	1 req	Avail to order Our Price: $346.89
11	400804088	INTERSECTION PART INTERSECTION PART	1 req	Avail to order Our Price: $346.89
12	400809465	BRACKET SUPPORT	2 req	Avail to order Our Price: $121.49
13	400810297	bracket LH BRACKET	1 req	Avail to order Our Price: $344.66
14	400810298	bracket RH BRACKET	1 req	Avail to order Our Price: $344.66
15	400813545	BRACKET SUPPORT	1 req	Avail to order Our Price: $119.55
16	400813546	BRACKET SUPPORT	1 req	Avail to order Our Price: $99.61
17	400813631	CROSS MEMBER MOTOR CROSS MEMBER	1 req	Avail to order Our Price: $250.86
18	400813709	SIDE MEMBER 3,RR SIDE MEMBER	1 req	Avail to order Our Price: $379.64
19	400813710	SIDE MEMBER 3,RR SIDE MEMBER	1 req	Avail to order Our Price: $379.64
20	408809081	INSERT PART PART TO INSERT	1 req	Avail to order Our Price: $686.32
21	408809082	INSERT PART PART TO INSERT	1 req	Avail to order Our Price: $686.32
22	408809967	COVER LID	1 req	Avail to order Our Price: $221.09
23	408809968	COVER LID	1 req	Avail to order Our Price: $221.09
24	400801193E	CONNECTING PIECE CONNECTING PIECE	1 req	Avail to order Our Price: $2,322.47
25	400801194E	CONNECTING PIECE CONNECTING PIECE	1 req	Avail to order Our Price: $2,329.91
26	400804901F	BRACKET SUPPORT	1 req	Avail to order Our Price: $574.67
27	400804902F	BRACKET SUPPORT	1 req	Avail to order Our Price: $227.04
28	400809119F	SUSPENSION STRUT LH SHOCK ABSORBER ASSEMBLY BRACKET	1 req	Avail to order Our Price: $11,135.93
29	400809120F	SUSPENSION STRUT RH SHOCK ABSORBER ASSEMBLY BRACKET	1 req	Avail to order Our Price: $11,135.93
30	400813623F	CROSS MEMBER CROSS MEMBER	1 req	Avail to order Our Price: $681.86
31	400813799F	SIDE MEMBER IV SIDE MEMBER	1 req	Avail to order Our Price: $1,540.87
32	400813800F	SIDE MEMBER IV SIDE MEMBER	1 req	Avail to order Our Price: $2,813.76
33	400813820E	SLEEVE SLEEVE	8 req	Avail to order Our Price: $261.29
34		STABILIZER BAR STIFFENER CONNECTION (CANNOT BE SOLD SEE REF. 35)	0 req
35	400803383A	LH bracket LH STABILIZING BRACKET	1 req	Avail to order Our Price: $115.68
35	400803384A	RH bracket RH STABILIZING BRACKET	1 req	Avail to order Our Price: $3,662.36
36		SUPPORT (VALID FROM A MODEL YEAR 09)	0 req
37		SUPPORT (VALID FROM A MODEL YEAR 09)	0 req
38		SUPPORT (VALID FROM A MODEL YEAR 09)	0 req
39		SUPPORT (VALID FROM A MODEL YEAR 09)	0 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
