2020 AVENTADOR SVJ ROADSTER - USA

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 4 Our Price: $48.32
G052529A2	TRANSMISSION FLUID TRANSMISSION FLUID	Avail to order Our Price: $39.00

Ignition

PN	Item	Diagram
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item	Diagram
0R0000149	CLEANER FLUID 250ml CLEANER FLUID		Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31

Tools and Tookits

PN	Item	Diagram
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month		Avail to order Our Price: $373.98
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL		Avail to order Our Price: $359.54

Open All

Select Group and TAV

< Previous Next >

TAV: 253.03.00 - SILENCER WITH CATALYST

2020 Lamborghini AVENTADOR SVJ ROADSTER USA SILENCER WITH CATALYST (253.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		SILENCER (ONLY FOR CHINA AND JAPAN - SEE REF 2-POST. 6 CATALYST)	0 req
2	470251051R	MUFFLER SILENCER (NOT FOR CHINA - SEE REF 1-POST. 4 CATALYST)	1 req	Avail to order Our Price: $14,917.39
3	470825497	DIFFUSER HEAT SHIELD	1 req	Avail to order Our Price: $267.99
4	420251143	CLAMP CLIP	2 req	Avail to order Our Price: $94.69
5	7L0253144B	SUSPENSION BRACKET	2 req	Avail to order Our Price: $58.51
6	420251305	BRACKET SDH RETAINER FOR EXHAUST SYSTEM	2 req	Avail to order Our Price: $26.65
7	470253047	SUPPORT BRACKET (LEFT)	1 req	Avail to order Our Price: $67.45
7	470253048	SUPPORT BRACKET (RIGHT)	1 req	Avail to order Our Price: $67.45
8	470825709J	HEAT SHIELD,REAR HEAT SHIELD	1 req	Avail to order Our Price: $10,875.39
9	470131849	HOSE VACUUM HOSE	1 req	Avail to order Our Price: $123.87
10	470131850	HOSE VACUUM HOSE	1 req	Avail to order Our Price: $124.32
11	470971796	BRACKET BRACKET (LEFT)	1 req	Avail to order Our Price: $29.63
11	470971806A	BRACKET BRACKET (RIGHT)	1 req	Avail to order Our Price: $68.12
12	059906051A	PRESSURE SENSOR PRESSURE DIFFERENCE SENDER	2 req	Current Stock: 4 Our Price: $137.72
13	WHT001942	WASHER WASHER	4 req	Current Stock: 13 Our Price: $3.51
14	N0195307	HEXAGON FLANGE HEX COLLARED BOLT (M8X25)	4 req	Avail to order Our Price: $3.28
15	N91021502	TRIPLE SQUARE BOLTM8X25 ROUND HD. SCREW (M8X25)	8 req	Avail to order Our Price: $2.31
16	N01152721	WASHER WASHER	2 req	Avail to order Our Price: $2.00
17	N10711101	HEXAGON FLANGE BOLT, HEX. HD. WITH SHAFT (M10X125X90)	2 req	Avail to order Our Price: $6.63
18	3C0131483A	CLIP SPRING BAND CLAMP (13,5X12)	2 req	Avail to order Our Price: $3.95
19	3C0131483	CLIP SPRING BAND CLAMP (11,5X8,4)	2 req	Avail to order Our Price: $3.51
20		CABLE CLIP (INCLUDED IN REF 8)	0 req
21	470825613E	HEAT SHIELD HEAT SHIELD	1 req	Avail to order Our Price: $4,957.58
22	N10637302	HEXALOBULAR SOCKETFLANGE BOLT OVAL HEXAGON SOCKET HEAD BOLT (M5X20)	2 req	Current Stock: 8 Our Price: $2.00
23	N10569501	HEXALOBULAR SOCKET ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD (M5X16)	2 req	Avail to order Our Price: $2.39
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
