2017 Lamborghini AVENTADOR S JAPAN SUSPENSION (505.03.00)

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 505.03.00 - SUSPENSION

2017 Lamborghini AVENTADOR S JAPAN SUSPENSION (505.03.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		SHOCK ABSORBERS (SEE ILLUSTRATION :-REAR 512-010)	0 req
2	WHT005396	TAP END STUD THREADED PIN (M10X1,25- M10X45)	8 req	Avail to order Our Price: $29.92
3	N10272302	HEX.NUT W/ FLANGE HEXAGON COLLAR NUT SELF-LOCKING (M10)	8 req	Avail to order Our Price: $2.37
4	WHT004898	HEXAGON FLANGE NUT W.WASHER HEXAGON COLLAR NUT SELF-LOCKING (M14X1,5)	2 req	Current Stock: 14 Our Price: $6.24
5		HEXAGON FLANGE SCREW	2 req
6	N10106402	HEX.NUT W/FLANGE LOCKING ELEM. HEXAGON COLLAR NUT SELF-LOCKING (M12X1,5)	8 req	Avail to order Our Price: $2.52
7		WHEEL BEARING HOUSING (SEE ILLUSTRATION :-REAR 505-040)	0 req
8	N91055501	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M5X12)	10 req	Avail to order Our Price: $2.00
9	N10689301	12-POINT SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M8X25)	8 req	Current Stock: 4 Our Price: $3.16
10	N10640301	HEXAGON FLANGE HEX COLLARED BOLT (M12X1,5X100)	8 req	Avail to order Our Price: $7.39
11	WHT005397	TAP END STUD THREADED PIN (M10X1,25- M10X39)	8 req	Avail to order Our Price: $40.33
12	WHT004856	ECCENTRIC BOLT ECCENTRIC BOLT (M12X1,5X75)	2 req	Avail to order Our Price: $65.74
13	WHT001676	ECCENTRIC WASHER ECCENTRIC WASHER (12,2X30X5X4)	4 req	Current Stock: 6 Our Price: $1.87
14	470505311G	TRACK CONTROL ARM POST. INF. SX WISHBONE (LEFT LOWER)	1 req	Avail to order Our Price: $1,432.23
14	470505312G	TRACK CONTROL ARM POST. INF. DX WISHBONE (RIGHT LOWER)	1 req	Avail to order Our Price: $1,432.23
15	470971005A	CABLE HOLDER MOUNTING BAR	1 req	Avail to order Our Price: $10.84
16	470407203C	BACKING PLATE SPESS.CAMBER 1,0 BALANCING PLATE (1 MM)	4 req	Avail to order Our Price: $28.42
16	470407203D	BACKING PLATE SPESS.CAMBER 0,5 BALANCING PLATE (0,5 MM)	4 req	Avail to order Our Price: $27.99
16	470407203E	BACKING PLATE SPESS.CAMBER 3,0 BALANCING PLATE (3 MM)	4 req	Avail to order Our Price: $20.96
17	470501397B	ACTUATOR STEERING GEAR (LEFT)	1 req	Avail to order Our Price: $7,512.74
17	470501398B	ACTUATOR STEERING GEAR (RIGHT)	1 req	Avail to order Our Price: $7,512.74
18	470505323J	TRACK CONTROL ARM SUP.POST SX WISHBONE (LEFT UPPER)	1 req	Avail to order Our Price: $830.92
18	470505324J	TRACK CONTROL ARM SUP.POST DX WISHBONE (RIGHT UPPER)	1 req	Avail to order Our Price: $830.92
19	470513387B	PUSH ROD INSULATION STRIP (REAR)	2 req	Avail to order Our Price: $296.36
20	470501429D	MOUNTING BRACKET	2 req	Avail to order Our Price: $322.90
21	WHT004995	PREV.TORQUE HEX. HEXAGON FLANGE NUT, SELF-LOCKING (M12X1,5)	4 req	Avail to order Our Price: $4.89
22	N10434301	PAN HEAD BOLT SOCKET HEAD BOLT (M5X10)	2 req	Avail to order Our Price: $2.00
23	N01118312	HEX.HEAD CLAMPING NUT HEXAGON NUT, SELF-LOCKING (M6)	2 req	Current Stock: 4 Our Price: $2.01
24	470941287F	RETAINING PART SENSORE LIFTING ARM (LEFT)	1 req	Avail to order Our Price: $17.16
24	470941288H	RETAINING PART SENSORE LIFTING ARM (RIGHT)	1 req	Avail to order Our Price: $17.16
25	470941287G	RETAINING PART SENSORE LIFTING ARM (LEFT)	1 req	Avail to order Our Price: $29.28
25	470941288G	RETAINING PART SENSORE LIFTING ARM (RIGHT)	1 req	Avail to order Our Price: $29.28
26	470941307	SENSOR ASS.POTENZIOMETRO POTENTIOMETER	2 req	Avail to order Our Price: $115.39
27	N10714801	HEXALOBULAR SOCKET FILLISTER HEAD BOLT WITH MULTI-POINT SOCKET HEAD (M6X18)	10 req	Avail to order Our Price: $2.00
28	470501470B	SUPPORT BRACKET (RIGHT)	1 req	Avail to order Our Price: $40.98
28	470501473B	SUPPORT BRACKET (LEFT)	1 req	Avail to order Our Price: $40.98
29	WHT003841	HEXALOBULAR SOCKETM6GFX14 FLAT ROUND HEAD BOLT (M6GFX14)	4 req	Avail to order Our Price: $2.00
30	470599503	BRACKET ARM (LEFT)	1 req	Avail to order Our Price: $470.71
30	470599504	BRACKET ARM (RIGHT)	1 req	Avail to order Our Price: $470.71
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
