2015 AVENTADOR SV LP750-4 COUPE - EUROPE

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $104.15

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.19

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $65.74
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $359.54
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $393.04
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $260.54

Open All

Select Group and TAV

< Previous Next >

TAV: 505.02.00 - AXLE SHAFT

2015 Lamborghini AVENTADOR SV LP750-4 COUPE EUROPE AXLE SHAFT (505.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0		601-040)	0 req
1	N90737804	HEXALOBULAR SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M6X14.0)	6 req	Avail to order Our Price: $2.00
2	N01474011	PAN HEAD BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M6X16)	2 req	Avail to order Our Price: $2.46
3	N10667901	12-POINT SOCKET SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M10X55)	12 req	Avail to order Our Price: $3.28
4	470501203F	DRIVE SHAFT CRASH PART DRIVE SHAFT WITH CONSTANT VELOCITY JOINTS (CONTACT YOUR AREA MANAGER-LEFT REAR)	1 req	Avail to order Our Price: $2,434.13
4	470501203H	DRIVE SHAFT POST.SX CRASH PART DRIVE SHAFT WITH CONSTANT VELOCITY JOINTS (CENTER LOCK WHEEL - CONTACT YOUR AREA MANAGER-LEFT REAR)	1 req	Avail to order Our Price: $2,441.57
4	470501204F	DRIVE SHAFT CRASH PART DRIVE SHAFT WITH CONSTANT VELOCITY JOINTS (CONTACT YOUR AREA MANAGER-RIGHT REAR)	1 req	Avail to order Our Price: $2,434.13
4	470501204H	DRIVE SHAFT POST.DX CRASH PART DRIVE SHAFT WITH CONSTANT VELOCITY JOINTS (CENTER LOCK WHEEL - CONTACT YOUR AREA MANAGER-RIGHT REAR)	1 req	Avail to order Our Price: $2,441.57
5	470505433D	WHEEL BRACKET WHEEL BEARING HOUSING (FROM VIN CLA01032 TO VIN GLA04209 - CONTACT YOUR AREA MANAGER-LEFT REAR)	1 req	Avail to order Our Price: $1,436.66
5	470505434D	WHEEL BRACKET WHEEL BEARING HOUSING (FROM VIN CLA01032 TO VIN GLA04209 - CONTACT YOUR AREA MANAGER-RIGHT REAR)	1 req	Avail to order Our Price: $937.93
6	4E0927803F	RH ABS SENSOR SPEED SENSOR (LEFT)	1 req	Avail to order Our Price: $145.31
6	4E0927803F	RH ABS SENSOR SPEED SENSOR (LEFT)	1 req	Avail to order Our Price: $145.31
6	4E0927804F	LH ABS SENSOR SPEED SENSOR (RIGHT)	1 req	Current Stock: 1 Our Price: $145.31
6	4E0927804F	LH ABS SENSOR SPEED SENSOR (RIGHT)	1 req	Current Stock: 1 Our Price: $145.31
7	7L0407357B	BACKING PLATE SPACER	6 req	Current Stock: 14 Our Price: $2.01
8	470615611C	COVER COVER PLATE FOR BRAKE DISC (LEFT)	1 req	Avail to order Our Price: $78.31
8	470615612C	COVER COVER PLATE FOR BRAKE DISC (RIGHT)	1 req	Avail to order Our Price: $78.31
9	WHT006779	PREV.TORQUE TYPE 12 POINT SOCKET SHOULDERED NUT SELF-LOCKING (M24X1,5)	2 req	Avail to order Our Price: $16.60
10	400501226	SPACER RING SPACER RING	2 req	Avail to order Our Price: $51.73
11	WHT000237A	12-POINT SOCKET BALL SCREW (M12X1,5X45)	8 req	Current Stock: 23 Our Price: $6.78
12	N91055501	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M5X12)	2 req	Current Stock: 20 Our Price: $2.00
13	470501652B	WHEEL HUB WHEEL HUB	2 req	Avail to order Our Price: $745.87
14	4E0407625F	ANGULAR CONTACT DOUBLE (ANGLED) BALL BEARING WITH FLANGE (BALL:92MM)	1 req	Avail to order Our Price: $213.64
15	470971930	CABLE HOLDER CABLE TERMINAL	2 req	Avail to order Our Price: $16.46
16	470501652E	WHEEL HUB WHEEL HUB (CENTRAL LOCK WHEEL ONLY FOR SV VERSION)	2 req	Avail to order Our Price: $1,205.90
17	WHT007467	WHEEL BOLT M16X1.5X72.0 SHOULDERED BOLT (CENTRAL LOCK WHEEL ONLY FOR SV VERSION-M16X1,5X72)	8 req	Avail to order Our Price: $151.85
18		SUSPENSION BLOCKS (CENTRAL LOCK WHEEL ONLY FOR SV VERSION-	0 req
19		TENSIONING NUT - (CENTRAL LOCK WHEEL ONLY FOR SV VERSION- 601-040)	0 req
20	470615315	TANG FOLLOWER	10 req	Avail to order Our Price: $42.14
21	N10620901	HEXALOBULAR SOCKET PAN HEAD BOLT SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M6X30)	10 req	Avail to order Our Price: $2.01
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
