2015 AVENTADOR SV LP750-4 COUPE - ENGLAND

Maintenance Parts:

Common repairs and upgrades

PN	Item
900000170	Tutela CS Speed Fluid -Oil Lifting System 1 liter Tutela CS Speed Fluid -Oil Lifting System 1 liter	Avail to order Our Price: $67.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO	Current Stock: 2 Our Price: $22.58
4T0803615	TOWING EYE TOWING EYE OLD PN 400803615	Current Stock: 2 Our Price: $48.32

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $104.15

Fuel-Air

PN	Item	Diagram
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $174.19

Ignition

PN	Item	Diagram
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $110.70
470905619C	Spark Plug Spark Plug		Avail to order Our Price: $106.98

Misc

PN	Item
6Q0819653B	CABIN FILTER AVENTADOR CABIN FILTER	Current Stock: 2 Our Price: $65.74
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $373.98
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
7PP907275F	WHEEL ELECTRONICS WHEEL ELECTRONICS	Avail to order Our Price: $169.72
4H0959126A	AC PRESSURE SENSOR A/C PRESSURE SENSOR,	Avail to order Our Price: $80.25
06A906262AT	OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE OXYGEN SENSOR O2 SENSOR - LAMBDA PROBE	Current Stock: 24 Our Price: $154.84
4E0927803F	RH ABS SENSOR SPEED SENSOR	Avail to order Our Price: $145.31
4E0927804F	LH ABS SENSOR SPEED SENSOR	Current Stock: 1 Our Price: $145.31

Tools and Tookits

PN	Item
470012257	DEMOUNTING HOOK DEMOUNTING HOOK	Current Stock: 1 Our Price: $253.70
69795000805	V12 VALVE SEALING FITTING TOOL V12 VALVE SEALING FITTING TOOL	Avail to order Our Price: $359.54
69195290	TOOL KIT FOR REMOVING THE GRILLE TOOL KIT FOR REMOVING THE GRILLE BUMPER NET TOOL	Avail to order Our Price: $393.04
61195080	TOOL FOR TOP DEAD CENTER LP700 TOP DEAD CENTER GAUGE. TOOL FOR TOP DEAD CENTER LP700	Avail to order Our Price: $260.54

Open All

Select Group and TAV

< Previous Next >

TAV: 907.08.00 - RETAINER FOR CONTROL UNITS

2015 Lamborghini AVENTADOR SV LP750-4 COUPE ENGLAND RETAINER FOR CONTROL UNITS (907.08.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	470907354C	RETAINER RETAINER FOR CONTROL UNITS (RIGHT)	1 req	Avail to order Our Price: $180.15
2	470907372D	BRACKET RETAINER FOR CONTROL UNITS (LEFT)	1 req	Avail to order Our Price: $113.74
3	470907376C	CONTROL UNIT- DIAG-ADR: 014 CONTROL UNIT FOR FRONT AXLE INCREASE	1 req	Avail to order Our Price: $902.19
4	470907713	HOLDER,ELECTR. ARM (LIFTING SYSTEM)	1 req	Avail to order Our Price: $5.58
5	893201365A	BACKING UNDERLAY (LIFTING SYSTEM)	2 req	Avail to order Our Price: $2.00
6	8K0907637C	SENSOR YAW RATE SENSOR	1 req	Current Stock: 8 Our Price: $1,010.87
7		CONTROL UNIT FOR PARK STEERING ASSIST (NOT FOR SV MODEL)	1 req
8	8F0907441A	CONTROL UNIT, DIAG-ADR: 06C CONTROL UNIT FOR REVERSING CAMERA SYSTEM	1 req	Avail to order Our Price: $1,353.29
9	470907392C	HOLDER,ELECTR. ARM (RVC)	1 req	Avail to order Our Price: $83.08
10		WARNING BUZZER (NOT FOR SV MODEL)	1 req
12	470907273A	TIRE PRESSURE CONTROL UNIT FOR TYRE PRESSURE CONTROL (315 MHZ - 433 MHZ - TIRE PRESSURE MONITORING SYSTEM)	1 req	Avail to order Our Price: $1,260.99
13	470868923A	BRACKET RR TRAY LOWER EXT ARM	2 req	Avail to order Our Price: $31.87
14	470868924A	BRACKET ARM	2 req	Avail to order Our Price: $30.67
15	470868891A	BRACKET ARM	2 req	Avail to order Our Price: $34.39
16	470909554A	CONTROL UNIT, MAGNERIDE CONTROL UNIT FOR ELECTRONIC REGULATED DAMPING (ONLY FOR SV VERSION)	1 req	Avail to order Our Price: $1,049.58
17	470907371	HOLDER,ELECTR. RETAINER FOR CONTROL UNIT, ELECTRONICALLY CONTROLLED DAMPING	1 req	Avail to order Our Price: $43.70
18	N10586401	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M5X10-M5X10)	3 req	Current Stock: 13 Our Price: $2.00
19	N01508210	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M6-M6)	16 req	Current Stock: 17 Our Price: $2.09
20	N01100412	HEX.NUT HEXAGON NUT (M4-M4)	4 req	Current Stock: 6 Our Price: $2.00
21	N10017304	HEXAGON FLANGE NUT HEXAGON COLLAR NUT (M5-M5)	2 req	Current Stock: 16 Our Price: $2.01
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
