2014 AVENTADOR LP700-4 ROADSTER - AUSTRALIA

Maintenance Parts:

Drivetrain

PN	Item	Diagram
07M115561B	SPIN-ON FILTER CARTUCCIS FIL.OLIO SPIN-ON FILTER CARTUCCIS FIL.OLIO		Current Stock: 2 Our Price: $48.56

Fuel-Air

PN	Item	Diagram
4D0906321C	FUEL FILTER FILTER		Avail to order Our Price: $40.12
470133843A	FILTER ELEMENT FILTER ELEMENT		Current Stock: 1 Our Price: $163.31

Ignition

PN	Item	Diagram
470905619	SEE PN 470905619C SPARK PLUG		Avail to order Our Price: $101.44
470905619A	SPARK PLUG SPARK PLUG		Avail to order Our Price: $104.03

Misc

PN	Item
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
N0300574	KEY - Spanner Murcielago-Aventador-Huracan Wrench Spanner Murcielago-Aventador-Huracan	Avail to order Our Price: $9.19
6Q0819653B	ODOR FILTER ODOR FILTER	Avail to order Our Price: $63.53
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22

Sensors

PN	Item
4E0927804	SEE PN 4E0927804F ABS SENSOR RIGHT	Avail to order Our Price: $45.07
4E0927803	ABS SENSOR LEFT ABS SENSOR LEFT	Current Stock: 2 Our Price: $45.07
470998161	COLD JOINT KIT Set of two 470919197C	Avail to order Our Price: $924.67

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 807.02.00 - FRONT BUMPERS

2014 Lamborghini AVENTADOR LP700-4 ROADSTER AUSTRALIA FRONT BUMPERS (807.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Aventador Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1		FRONT BUMPERS (SEE TABLE 8070100)	1 req
2	470807325F	REINFORCEMENT LH REINFORCEMENT (UNTIL THE VIN ZHWUR1ZD2ELA02464 REPLACE ALSO RH P/N AND THE RIF.2 TAV. 701.01.00)	1 req	Avail to order Our Price: $152.84
2	470807326E	REINFORCEMENT RH REINFORCEMENT (UNTIL THE VIN ZHWUR1ZD2ELA02464 REPLACE ALSO LH P/N AND THE RIF.2 TAV. 701.01.00)	1 req	Avail to order Our Price: $99.31
3	470807481C	ANGLE BRACKET BRACKET	2 req	Avail to order Our Price: $28.57
4	470807129A	BRACKET BRACKET	2 req	Avail to order Our Price: $49.73
5	4T0853745A	TYPE SIGN LOGO ANT. LAMBORGHINI ORNAMENT	1 req	Avail to order Our Price: $440.32
6	470807193C	BRACKET,SIDE PER PARAFANGO LH BRACKET	1 req	Avail to order Our Price: $42.92
6	470807194C	See PN 470807194E RH BRACKET	1 req	*See Description
7	470807639A	GRILLE GRID	1 req	Avail to order Our Price: $165.84
8	470807681	GRILLE LEFT FRONT GRID	1 req	Avail to order Our Price: $333.10
8	470807682	GRILLE RIGHT FRONT GRID	1 req	Avail to order Our Price: $348.82
9	470807819	TRIM LH FRAME	1 req	Avail to order Our Price: $2,022.86
9	470807819A	TRIM MOSTR.GRIGLIA SX LH FRAME (EXTERNAL CARBON )	1 req	Avail to order Our Price: $5,518.18
9	470807820	TRIM RH FRAME	1 req	Avail to order Our Price: $2,022.86
9	470807820A	TRIM MOSTR.GRIGLIA DX RH FRAME (EXTERNAL CARBON )	1 req	Avail to order Our Price: $5,518.18
10	N90698605	SCREW SCREW 4.2X16	8 req	Current Stock: 3 Our Price: $2.00
11	N10558102	HEXALOBULAR SOCKET SCREW M6X18	4 req	Current Stock: 11 Our Price: $4.24
12	N10661002	HEXALOBULAR SOCKET SCREW M6X20	6 req	Current Stock: 18 Our Price: $2.00
13	N01167026	WASHER WASHER	6 req	Avail to order Our Price: $2.00
14	N10558102	HEXALOBULAR SOCKET SCREW M6X18	4 req	Current Stock: 11 Our Price: $4.24
15	N0154487	SPEED NUT CLIP	8 req	Current Stock: 6 Our Price: $2.00
16	N90688703	SNAP NUT CLAMP CLIP	2 req	Current Stock: 2 Our Price: $2.00
17	N90780903	SOCKET SCREW SCREW M6X16	2 req	Current Stock: 1 Our Price: $2.00
18	N0110027	HEX.NUT NUT M3	1 req	Current Stock: 1 Our Price: $2.00
19	N10558102	HEXALOBULAR SOCKET SCREW M6X18	10 req	Current Stock: 11 Our Price: $4.24
20	470807287D	LICENSE PLATE ANT.TARGA LICENSE PLATE HOLDER	1 req	Avail to order Our Price: $151.41
21	470807287C	LICENSE PLATE BRAC LICENSE PLATE HOLDER (VALID FOR A MARKET CHINESE)	1 req	Avail to order Our Price: $512.34
22	N10451404	screw SCREW M6X16	3 req	Current Stock: 17 Our Price: $2.00
23	N01166623	WASHER WASHER	3 req	Avail to order Our Price: $2.00
24	400807995	GROMMET RUBBER BUSHING	5 req	Avail to order Our Price: $3.52
25	N10637302	HEXALOBULAR SOCKETFLANGE BOLT SCREW M5X20 (VALID FOR A MARKET CHINESE)	2 req	Current Stock: 8 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
