1981-1988 Lamborghini Jalpa 3.5 USA Engine And Luggage Comp. Hoods (46.78)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $335.91
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $76.70

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $509.81
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $96.01

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $83.98
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $341.11
002111112	Flywheel Flywheel	Avail to order Our Price: $1,232.98
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,804.01
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $66.50
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,389.53

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $305.02
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09
006311154	Relay Relay	Avail to order Our Price: $54.49
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $19.64
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.48
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $82.73

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,066.00
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $338.14
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,361.46

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $64.49
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $646.55

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $39.22
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $132.69
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $145.52

Open All

Select Group and TAV

< Previous Next >

TAV: 46.78 - Engine And Luggage Comp. Hoods

1981-1988 Lamborghini Jalpa 3.5 USA Engine And Luggage Comp. Hoods (46.78)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	007058002	Rearv.Mirror	1 req	Avail to order Our Price: $1,061.23
2	006119375	NLA - SEE PN 006119375M for Manual Mirrors	1 req	*See Description
3	006119118	NLA (No Longer Available)	1 req	*See Description
4	006119374	NLA - 1 in used stock SEE PN 006119375M for Manual Mirrors	1 req	*See Description
5	WHT002961	WASHER	8 req	Current Stock: 39 Our Price: $2.00
6	N10430103	HEXALOBULAR SOCKET	2 req	Current Stock: 21 Our Price: $2.00
7	007829004	Hood Lock Hook Unit	1 req	Avail to order Our Price: $78.73
8	007829006	Rear Hood Int.Washer	1 req	Avail to order Our Price: $15.81
9	007829002	This item is no longer available	1 req
10	008100607	Screw M6x18 Uni 5739/5s/Z	2 req	Avail to order Our Price: $6.56
11	WHT002961	WASHER	6 req	Current Stock: 39 Our Price: $2.00
12	006959110	Fiat Original BonnetLock 423	2 req	Current Stock: 1 Our Price: $135.82
13	006929115	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	007858026	This item is no longer available	1 req
15	007858024	This item is no longer available	1 req
16	007858035	Side Panel	1 req	Avail to order Our Price: $212.55
17	007858063	This item is no longer available	1 req
18	007858059	Rh Bonn.Side Panel	1 req	Avail to order Our Price: $299.67
19	007858031	This item is no longer available	2 req
20	007858027	This item is no longer available	1 req
21	007858036	Light Cover Bon.Comp.Side Pane	1 req	Avail to order Our Price: $212.55
22	007858064	This item is no longer available	1 req
23	007858060	This item is no longer available	1 req
24	007858065	This item is no longer available	1 req
25	007858027	This item is no longer available	1 req
26	008611602	Grommet 16x25x1.5 mm	1 req	Avail to order Our Price: $15.88
27	007858025	This item is no longer available	1 req
28	007858023	This item is no longer available	1 req
29	007029005	Bonnet Lifter	1 req	Avail to order Our Price: $111.67
30	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
31	008820101	Split Pin 1.8x12 Uni 1336a	3 req	Avail to order Our Price: $2.76
32	008700630	Screw M6x20 Din 966 4s/Z	1 req	Avail to order Our Price: $2.76
33	006921965	Door Hole Plug	1 req	Avail to order Our Price: $6.79
34	006960116	Engine Compartment Handle	1 req	Avail to order Our Price: $339.93
35	007860032	This item is no longer available	1 req
36	007860024	Lateral Rh Locking Plate	1 req	Avail to order Our Price: $212.55
37	008100616	Screw M6x16 Uni 5739/5s/Z	2 req	Avail to order Our Price: $2.00
38	WHT002961	WASHER	4 req	Current Stock: 39 Our Price: $2.00
39	007860026	Hood Lock Striker	1 req	Avail to order Our Price: $118.09
40	007860023	Engine Cover	1 req	Avail to order Our Price: $10,227.63
41	007860025	Lateral Lh Locking Plate	1 req	Avail to order Our Price: $212.55
42	007860005	Engine Bonnet Back Shield	1 req	Avail to order Our Price: $236.31
43	007060018	Engine Bonn.Lifter	1 req	Current Stock: 1 Our Price: $168.24
44	006959119	mm 760 Front Bon Sec. Cable	1 req	Avail to order Our Price: $101.83
45	007860033	This item is no longer available	1 req
46	008580502	Circlip 6 8 Din 6799	1 req	Avail to order Our Price: $2.76
47	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
48	008410601	Washer 12x6.1x0.6 C72	1 req	Avail to order Our Price: $2.00
49	007059012	Bonnet Cable Fix.Washer	1 req	Avail to order Our Price: $23.64
50	006959298	Bonnet Lock Cable Fix.Pin	1 req	Avail to order Our Price: $34.00
51	N01152427	WASHER	1 req	Avail to order Our Price: $2.00
52	008580402	Circlip 4 5 Din 6799	1 req	Avail to order Our Price: $2.76
53	007855054	Engine Cover Sheet	2 req	Avail to order Our Price: $78.73
54	007855032	This item is no longer available	1 req
55	007855052	Isol.Support Frame On Pressure	1 req	Avail to order Our Price: $393.61
56	007855053	Upper Engine Bracket	2 req	Avail to order Our Price: $102.28
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
