2018 HURACAN LP580-2 SPYDER - JAPAN

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $699.29
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $120.74

Common repairs and upgrades

PN	Item
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $89.92

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $148.14

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $36.40

Misc

PN	Item
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $41.92
4T0072192B	Aero Kit RWD Huracan LP580-2 Coupes and Spyders includes: front splitter, side skirts, rear diffuser, rear wing, and fixing parts. Fender louvers not included	Avail to order Our Price: $13,392.99
4T0864537	TRIM COVER PLATE TRIM COVER PLATE	Avail to order Our Price: $75.90
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 109.02.00 - CAMSHAFT, VALVES

2018 Lamborghini HURACAN LP580-2 SPYDER JAPAN CAMSHAFT, VALVES (109.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L109101BQ	CAMSHAFT CAMSHAFT (INLET CYLINDERS 1-5)	1 req	Avail to order Our Price: $882.84
1	07L109103AP	CAMSHAFT CAMSHAFT (INLET CYLINDERS 6-10)	1 req	Avail to order Our Price: $882.84
2	07L109102AN	CAMSHAFT CAMSHAFT (OUTLET CYLINDERS 1-5)	1 req	Avail to order Our Price: $882.84
2	07L109104Q	CAMSHAFT CAMSHAFT (OUTLET CYLINDERS 6-10)	1 req	Avail to order Our Price: $882.84
3	07L109285K	COVER COVER (LEFT)	1 req	Avail to order Our Price: $188.34
3	07L109286M	COVER COVER (RIGHT)	1 req	Avail to order Our Price: $312.64
4	07L109083F	CAMSHAFT CAMSHAFT ADJUSTER UNIT (INLET)	2 req	Avail to order Our Price: $574.67
5	N91068201	HEXALOBULAR SOCKET HEXAGON SOCKET FLAT HEAD BOLT (M4X10)	4 req	Current Stock: 6 Our Price: $2.00
6	N91042802	12-POINT SOCKET FLANGE BOLT FLAT HEAD MULTI-POINT SOCKET BOLT (M12X1,25X60X30)	4 req	Avail to order Our Price: $6.55
7	079109601E	INTAKE VALVE INLET VALVE (103,97MM)	20 req	Current Stock: 2 Our Price: $56.58
8	07L109629A	RETAINER SPRING SUPPORT	40 req	Avail to order Our Price: $5.81
9	06E109623	SPRING VALVE VALVE SPRING	40 req	Avail to order Our Price: $49.88
10	036109675A	VALVE STEM SEAL VALVE STEM SEAL	40 req	Avail to order Our Price: $22.11
11	06E109641A	VALVE SPRING PLATE SPRING DISC	40 req	Avail to order Our Price: $18.69
12	036109651A	VALVE LOCK COTTER, SPLIT	80 req	Avail to order Our Price: $4.69
13	07L109257	VALVE CONTROL VALVE	4 req	Avail to order Our Price: $149.62
14	07L121455J	PIPE COOLANT PIPE (LEFT)	1 req	Avail to order Our Price: $133.84
14	07L121455L	BREATHER PIPE COOLANT PIPE (RIGHT)	1 req	Avail to order Our Price: $133.84
15	07L109084E	CAMSHAFT CAMSHAFT ADJUSTER UNIT (OUTLET)	2 req	Avail to order Our Price: $574.67
16	07L109611D	EXHAUST VALVE EXHAUST VALVE	20 req	Current Stock: 1 Our Price: $56.58
17	079109409B	ROLLER ROCKER ARM ROLLER ROCKER ARM	40 req	Avail to order Our Price: $92.91
18	N0210756	BANJO BOLT BANJO BOLT (6)	4 req	Avail to order Our Price: $9.60
19	N0138063	O-RING SEAL RING (10X14)	8 req	Avail to order Our Price: $3.35
20		COMPLETE CYLINDER HEAD	0 req
21	WHT005227	HEXALOBULAR SOCKET OVAL HEXAGON SOCKET HEAD BOLT (M6X12)	2 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
