2016 HURACAN LP580-2 COUPE - USA

Maintenance Parts:

Brakes

PN	Item	Diagram
4S0698451	Rear Brake Pad Set Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE		Avail to order Our Price: $699.29
4T0698010	Ceramic Brake Pad Kit BIADHESIVEE PADS KIT		Avail to order Our Price: $120.74

Common repairs and upgrades

PN	Item
900000384A	NLA (No Longer Available) Huracan Indoor Cover - Green Stitching	Avail to order Our Price: $398.89
900000384D	NLA (No Longer Available) INT. 62X CAR COVER WHITE STITCHING INDOOR	Avail to order Our Price: $398.89
900000384E	NLA (No Longer Available) INT. 62X CAR COVER GREY STIT.	Avail to order Our Price: $398.89
900000384F	NLA (No Longer Available) INT. 62X CAR COVER RED STITCHING INDOOR	Avail to order Our Price: $398.89
900000384B	HURACAN CAR COVER ORANGE STITCHING INDOOR INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover	Avail to order Our Price: $398.89
900000384C	NLA (No Longer Available) INT. 62X CAR COVER YELLOW STIT.	Avail to order Our Price: $398.89

Drivetrain

PN	Item	Diagram
079198405E	Oil Filter Gallardo/Huracan LP Series Oil Filter Gallardo LP Series		Avail to order Our Price: $89.92

Fuel-Air

PN	Item	Diagram
420133844E	ENGINE AIR FILTER HURACAN AIR FILTER SEE PN 420133844EZ for K&N performance filter		Avail to order Our Price: $148.14

Ignition

PN	Item	Diagram
06H905601C	SPARK PLUG SPARK PLUG		Avail to order Our Price: $36.40

Misc

PN	Item
400093050D	CTEK US-CD BATTERY CHARGER Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month	Avail to order Our Price: $317.22
4T0072192B	Aero Kit RWD Huracan LP580-2 Coupes and Spyders includes: front splitter, side skirts, rear diffuser, rear wing, and fixing parts. Fender louvers not included	Avail to order Our Price: $13,392.99
4H0805615	TOWING EYE FOR HURACAN TOWING EYE	Avail to order Our Price: $41.92
4T0864537	TRIM COVER PLATE TRIM COVER PLATE	Avail to order Our Price: $75.90
4T0898200	SEE PN 4T0998200 DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T0898201	SEE PN 4T0998200A PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A	Avail to order Our Price: $221.94
4T1864435E	HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border	Avail to order Our Price: $865.25

Tools and Tookits

PN	Item	Diagram
470012257	DEMOUNTING HOOK DEMOUNTING HOOK		Current Stock: 1 Our Price: $253.70

Open All

Select Group and TAV

< Previous Next >

TAV: 121.07.00 - OIL PUMP

2016 Lamborghini HURACAN LP580-2 COUPE USA OIL PUMP (121.07.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	07L115009AM	PUMP OIL PUMP	1 req	Avail to order Our Price: $5,590.30
2	079121119C	SEAL RING SEAL	1 req	Avail to order Our Price: $18.09
3	079121115AT	THERMOSTAT HOUSING COOLANT REGULATOR HOUSING WITH THERMOSTAT (85C-95C)	1 req	Avail to order Our Price: $728.01
4		THERMOSTAT (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 3- 3)	0 req
5		OIL SUMP (SEE ILLUSTRATION :- 103-010)	0 req
6	WHT003868	SCREW SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD (M6X25)	1 req	Avail to order Our Price: $24.28
7	WHT003874	SCREW PLUG SEAL BOLT WITH SEALING RING (PLASTIC)	1 req	Avail to order Our Price: $5.96
8		SEAL (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 7- 7)	0 req
9	N10700201	HEXALOBULAR SOCKET ROUND HD. SCREW (M6X22)	1 req	Current Stock: 17 Our Price: $3.13
10	N91020803	SLEEVE DOWEL SLEEVE (8M7X10)	1 req	Avail to order Our Price: $2.53
11	07L121119B	SEAL RING SEAL (32X32X3,5)	1 req	Avail to order Our Price: $21.29
12	07L115446A	MOULDED SEAL SEAL (26X26X3,5)	1 req	Avail to order Our Price: $20.32
13	WHT003731	O-RING O-RING (27X3,5)	2 req	Avail to order Our Price: $28.59
14	07L103081	OIL STRAINER OIL STRAINER	8 req	Avail to order Our Price: $29.11
15	WHT003732	O-RING O-RING (24X3,5)	8 req	Avail to order Our Price: $28.59
16	N0138115	SEAL RING SEAL RING (10X13,5)	2 req	Current Stock: 3 Our Price: $5.66
17	N0160243	SCREW SEALING PLUG (M10X1)	2 req	Avail to order Our Price: $5.81
18	07L121057T	COOLANT HOSE COOLANT HOSE	1 req	Avail to order Our Price: $20.40
19	07L121133M	ADAPTER WATER CONNECTION	1 req	Avail to order Our Price: $66.85
20	06B145917	SPRING CLAMP SPRING BAND CLAMP (35X12)	1 req	Current Stock: 4 Our Price: $5.66
21	N90687101	SPRING CLAMP SPRING BAND CLAMP (32X12)	1 req	Avail to order Our Price: $8.20
22	N10196103	HEXALOBULAR SOCKET FILLISTER HEAD BOLT WITH MULTI-POINT SOCKET HEAD (M6X18)	2 req	Avail to order Our Price: $2.00
23	N90544501	O-RING SEAL RING (27X3)	1 req	Current Stock: 4 Our Price: $4.02
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
