Maintenance Parts:

Brakes

PN Item Diagram
4T0698010 Ceramic Brake Pad Kit
BIADHESIVEE PADS KIT
Avail to order
Our Price: $120.74
4S0698451 Rear Brake Pad Set
Rear Brake Pad Set 1 SET OF BRAKE PADS FOR DISK BRAKE
Avail to order
Our Price: $699.29
Rear Brake Pad Set

Common repairs and upgrades

PN Item Diagram
900000384D NLA (No Longer Available)
INT. 62X CAR COVER WHITE STITCHING INDOOR
Avail to order
Our Price: $398.89
NLA (No Longer Available)
900000384A NLA (No Longer Available)
Huracan Indoor Cover - Green Stitching
Avail to order
Our Price: $398.89
NLA (No Longer Available)
900000384B HURACAN CAR COVER ORANGE STITCHING INDOOR
INT. 62X CAR COVER ORANGE STIT. NOTE: The orange color Lamborghini uses for this cover is very light and is almost yellow. This is normal and their intended color for this cover
Avail to order
Our Price: $398.89
HURACAN CAR COVER ORANGE STITCHING INDOOR
900000384C NLA (No Longer Available)
INT. 62X CAR COVER YELLOW STIT.
Avail to order
Our Price: $398.89
NLA (No Longer Available)
900000384E NLA (No Longer Available)
INT. 62X CAR COVER GREY STIT.
Avail to order
Our Price: $398.89
NLA (No Longer Available)
900000384F NLA (No Longer Available)
INT. 62X CAR COVER RED STITCHING INDOOR
Avail to order
Our Price: $398.89
NLA (No Longer Available)

Drivetrain

PN Item Diagram
079198405E Oil Filter Gallardo/Huracan LP Series
Oil Filter Gallardo LP Series
Avail to order
Our Price: $89.92
Oil Filter Gallardo/Huracan LP Series

Fuel-Air

PN Item Diagram
420133844E ENGINE AIR FILTER HURACAN
AIR FILTER SEE PN 420133844EZ for K&N performance filter
Avail to order
Our Price: $148.14
ENGINE AIR FILTER HURACAN

Ignition

PN Item Diagram
06H905601C SPARK PLUG
SPARK PLUG
Avail to order
Our Price: $36.40
101905631G Spark Plug - Gallardo/Huracan LP Series
Spark Plug Champion
Current Stock: 48
Our Price: $35.14
Spark Plug - Gallardo/Huracan LP Series

Misc

PN Item Diagram
4T1864435E HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR
HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR customizable sticthing or border
Avail to order
Our Price: $865.25
HURACAN SET OF 2 FLOOR MATS PICK BORDER COLOR
4H0805615 TOWING EYE FOR HURACAN
TOWING EYE
Avail to order
Our Price: $41.92
4T0898201 SEE PN 4T0998200A
PAIR OF DOOR LIGHTS WITH LAMBORGHINI SCRIPT WRITING KIT LIGHTS THE GROUND WITH THE LAMBORGHINI SCRIPT ILLUMINATED FROM THE DOOR Replaces - 4E0947415A
Avail to order
Our Price: $221.94
SEE PN 4T0998200A
4T0898200 SEE PN 4T0998200
DOOR LIGHT WITH LAMBORGHINI LOGO KIT Replaces - 4E0947415A
Avail to order
Our Price: $221.94
SEE PN 4T0998200
400093050D CTEK US-CD BATTERY CHARGER
Input 110-120VAC Output Max 4.3A, 12V Back drain less than 1.5Am/month
Avail to order
Our Price: $317.22
CTEK US-CD BATTERY CHARGER
4T0054690 CRUISE CONTROL KIT, LEATHER 610-4
CRUISE CONTROL KIT, LEATHER
Avail to order
Our Price: $1,491.40
4T0054690A CRUISE CONTROL KIT, ALCANTARA 610-4
CRUISE CONTROL KIT, ALCANTARA
Avail to order
Our Price: $1,491.40
4T0864537 TRIM COVER PLATE
TRIM COVER PLATE
Avail to order
Our Price: $75.90
TRIM COVER PLATE

Tools and Tookits

PN Item Diagram
470012257 DEMOUNTING HOOK
DEMOUNTING HOOK
Current Stock: 1
Our Price: $253.70
DEMOUNTING HOOK
Open All

Select Group and TAV

TAV: 505.01.00 - GUIDE

2018 Lamborghini HURACAN LP610-4 COUPE CANADA GUIDE (505.01.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
2 4T0505312A TRACK CONTROL ARM
WISHBONE (CONTACT YOUR AREA MANAGER-RIGHT LOWER)
1 req Avail to order
Our Price: $665.48
2 4T0505311A TRACK CONTROL ARM
WISHBONE (CONTACT YOUR AREA MANAGER-LEFT LOWER)
1 req Avail to order
Our Price: $665.48
3 4T0505323 TRACK CONTROL ARM
WISHBONE (CONTACT YOUR AREA MANAGER-LEFT UPPER)
1 req Avail to order
Our Price: $635.70
3 4T0505324 TRACK CONTROL ARM
WISHBONE (CONTACT YOUR AREA MANAGER-RIGHT UPPER)
1 req Avail to order
Our Price: $1,260.99
4 4T0501529B TIE ROD
CABLE
2 req Avail to order
Our Price: $644.64
5 8K0407625N SEE PN 8K0407625Q
DUOBLE BALL BEARING
2 req Avail to order
Our Price: $1,174.64
5 8K0407625Q ANGULAR CONTACT
DUOBLE BALL BEARING
2 req Avail to order
Our Price: $176.42
6 4S0941273D SENSOR-HEADLIGHT- HI.MSS MAGNE RIDE
LEVEL SENSOR WITH POLES (LEFT)
1 req Avail to order
Our Price: $238.95
6 4S0941274D SENSOR-HEADLIGHT- HI.MSS MAGNE RIDE
LEVEL SENSOR WITH POLES (RIGHT)
1 req Avail to order
Our Price: $238.95
7 AXLE SHAFT (SEE ILLUSTRATION :-REAR 501-010) 1 req
8 4S0407203C BACKING PLATE 1MM
BALANCING PLATE (1,0 MM-1MM)
4 req Avail to order
Our Price: $8.42
8 4S0407203D BACKING PLATE 2MM
BALANCING PLATE (2,0 MM-2MM)
4 req Avail to order
Our Price: $8.42
8 4S0407203E BACKING PLATE 3MM
BALANCING PLATE (3,0 MM-3MM)
4 req Avail to order
Our Price: $8.42
8 4S0407203G BACKING PLATE 0,5MM
BALANCING PLATE (0,5 MM-0,5MM)
4 req Avail to order
Our Price: $8.42
9 WHT004898 HEXAGON FLANGE NUT W.WASHER
HEXAGON COLLAR NUT SELF-LOCKING (M14X1,5-M14X1,5)
4 req Current Stock: 14
Our Price: $6.48
HEXAGON FLANGE NUT  W.WASHER
10 8K0407613B WHEEL HUB
WHEEL HUB
2 req Avail to order
Our Price: $311.90
11 LENGTH-MEASURING DEVICE (CANNOT BE SOLD SEPARATELY - IT IS PART OF REF. 10) 2 req
12 8E0407643A HEXAGON HEAD BOLT M16X72
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M16X72-M16X1,5X72)
2 req Avail to order
Our Price: $14.45
13 N10706902 HEXAGON FLANGE M10X55
HEXAGON FLANGE SCREW (M10X40-M10X55)
8 req Current Stock: 3
Our Price: $6.92
HEXAGON FLANGE    M10X55
13 WHT007142 12 POINT BOLT M10X42
HEXAGON BOLT (M10X40-M10X40)
8 req Avail to order
Our Price: $8.79
14 WHT002059 HEXAGON FLANGE M12X1.5X80.8
BOLT,HEX.HD.WITH SHOUL.(COMBI) (AM12X1,5X80-M12X1,5X80)
8 req Avail to order
Our Price: $5.44
HEXAGON FLANGE M12X1.5X80.8
15 WHT000237A 12-POINT SOCKET
BALL SCREW (M12X45-M12X1,5X45)
8 req Current Stock: 1
Our Price: $6.78
12-POINT SOCKET
16 N10660901 12-POINT SOCKET
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (M10X40-M10X40)
8 req Avail to order
Our Price: $7.37
17 N10405604 HEXALOBULAR SOCKET
OVAL HEXAGON SOCKET HEAD BOLT (M6X14-M6X14)
8 req Avail to order
Our Price: $2.00
18 COMPENSATING PIECE (3 MM - TEMPORARILY NOT AVAILABLE) 4 req
19 WHEEL HUB (NO PART - NOT FOR THIS VERSION) 0 req
20 SHOULDERED BOLT (NO PART - NOT FOR THIS VERSION) 0 req
21 SUSPENSION BLOCKS (NO PART - NOT FOR THIS VERSION) 0 req
22 NUT (NO PART - NOT FOR THIS VERSION) 0 req
23 HUP CAP (NO PART - NOT FOR THIS VERSION) 0 req
24 470698009 GASKET SET
O-RING
2 req Avail to order
Our Price: $10.21

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
