1972 Lamborghini Jarama USA Brakes System (Pipelines) (17.31.32)

Maintenance Parts:

Belts

PN	Item	Diagram
004608478	Belt Belt		Avail to order Our Price: $110.33
004504532	Belt Belt		Current Stock: 1 Our Price: $54.12
001604645	Belt Belt		Current Stock: 3 Our Price: $24.01
004009744	Power Steering Belt Power Steering Belt		Avail to order Our Price: $112.42

Brakes

PN	Item	Diagram
003106765	Brake Pads Front - Jarama - Miura Front Brake Pads		Avail to order Our Price: $331.45
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $76.40

Drivetrain

PN	Item	Diagram
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Current Stock: 3 Our Price: $46.75
002104719	Drive Plate Drive Plate		Avail to order Our Price: $848.33
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $27.59
001504611	Oil Filter Oil Filter		Avail to order Our Price: $494.99

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $487.51

Fuses-Bulbs-Relays

PN	Item	Diagram
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W		Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb		Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)		Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W		Current Stock: 10 Our Price: $2.09
001605819	Relay Relay		Current Stock: 1 Our Price: $43.32
006617089	10 W Bulb 10 W Bulb		Avail to order Our Price: $15.51
006617103	3w Bulb 3w Bulb		Avail to order Our Price: $6.92

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,119.19
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $96.32

Misc

PN	Item	Diagram
006715235	Windsc.Wip.Blade Windsc.Wip.Blade		Avail to order Our Price: $66.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut		Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement		Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.		Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $145.52

Open All

Select Group and TAV

< Previous Next >

TAV: 17.31.32 - Brakes System (Pipelines)

1972 Lamborghini Jarama USA Brakes System (Pipelines) (17.31.32)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	003206718	This item is no longer available	1 req
0	003106716	NLA (No Longer Available)	1 req	*See Description
1	003206386	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
2	003206717	This item is no longer available	1 req
3	003201436	Pipe to Rear CaliperHose	2 req	Avail to order Our Price: $89.91
4	003201484	Brake Hose Bracket	2 req	Avail to order Our Price: $13.50
5	WHT003055	Washer 13x24x1.2 Din137/B C72	4 req	Current Stock: 10 Our Price: $2.00
6	008101218	Special Screw M12x37	4 req	Avail to order Our Price: $23.19
7	008401305	Washer 13x22x* C 72	1 req	Avail to order Our Price: $2.00
8	003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each	4 req	Avail to order Our Price: $76.40
9	003101437	Front Caliper Pipe To Hose	2 req	Avail to order Our Price: $92.88
10	WHT003055	Washer 13x24x1.2 Din137/B C72	4 req	Current Stock: 10 Our Price: $2.00
11	008101219	NLA (No Longer Available)	4 req	*See Description
12	008200806	M8 Uni 5588/8g/Z Nut	16 req	Current Stock: 25 Our Price: $2.00
13	008410808	Brake Lock Plate	8 req	Avail to order Our Price: $19.40
14	008100833	Screw M8x1.25x21 8g	16 req	Current Stock: 4 Our Price: $2.76
15	003106715	NLA (No Longer Available)	1 req	*See Description
16	008401305	Washer 13x22x* C 72	1 req	Avail to order Our Price: $2.00
17	003106765	Brake Pads Front - Jarama - Miura	4 req	Avail to order Our Price: $331.45
18	008200806	M8 Uni 5588/8g/Z Nut	16 req	Current Stock: 25 Our Price: $2.00
19	008410809	Brake Lock Plate	8 req	Avail to order Our Price: $13.27
20	008100833	Screw M8x1.25x21 8g	16 req	Current Stock: 4 Our Price: $2.76
21	003106387	Ventilated Front Brake Disc	2 req	Avail to order Our Price: $4,213.68
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
