TAV: 871.02.00 - SOFT TOP BOX TRAY

2020 Lamborghini HURACAN PERFORMANTE SPYDER USA SOFT TOP BOX TRAY (871.02.00)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Huracan Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 4T7825147 ROOF CONTAINER + CROSSBEAM
CROSS MEMBER FOR ROOF BOX
1 req Avail to order
Our Price: $22,323.96
1 4T7825147 ROOF CONTAINER + CROSSBEAM
CROSS MEMBER FOR ROOF BOX
1 req Avail to order
Our Price: $22,323.96
2 SOFT TOP BOX TRAY (CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 1) 0 req
2 SOFT TOP BOX TRAY (CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 1) 0 req
3 4T7825402 KIT SEALING ROOF CONTAINER
SEAL FOR CONV. TOP STOWAGE BOX
1 req Avail to order
Our Price: $394.53
3 4T7825402 KIT SEALING ROOF CONTAINER
SEAL FOR CONV. TOP STOWAGE BOX
1 req Avail to order
Our Price: $394.53
4 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
4 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
5 CUP WASHER (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
5 CUP WASHER (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
6 HEXAGON FLANGE SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
6 HEXAGON FLANGE SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 1) 0 req
7 4T7880077 POP-UP KIT
OVERROLL PROTECTION (SX E DX)
1 req Avail to order
Our Price: $6,022.04
7 4T7880077 POP-UP KIT
OVERROLL PROTECTION (SX E DX)
1 req Avail to order
Our Price: $6,022.04
8 OVERROLL PROTECTION (DES. - CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
8 OVERROLL PROTECTION (DES. - CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
9 OVERROLL PROTECTION (SIN. - CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
9 OVERROLL PROTECTION (SIN. - CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
10 NUT (CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
10 NUT (CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 7) 0 req
11 HEXAGON SOCKET HEAD BOLT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
11 HEXAGON SOCKET HEAD BOLT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
12 HOSE CLAMP (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
12 HOSE CLAMP (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
13 COVER PLATE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
13 COVER PLATE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
14 4T7845861 REAR WINDOW MODULE
REAR WINDOW
1 req Avail to order
Our Price: $6,791.09
14 4T7845861 REAR WINDOW MODULE
REAR WINDOW
1 req Avail to order
Our Price: $6,791.09
15 REAR WINDOW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
15 REAR WINDOW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
16 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
16 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
17 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
17 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 14) 0 req
18 4T7959801A RWM MOTOR
WINDOW REGULATOR MOTOR (LEFT LHD)
1 req Avail to order
Our Price: $440.68
18 4T7959801A RWM MOTOR
WINDOW REGULATOR MOTOR (LEFT LHD)
1 req Avail to order
Our Price: $440.68
19 WINDOW REGULATOR MOTOR (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:-LEFT LHD 18) 0 req
19 WINDOW REGULATOR MOTOR (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:-LEFT LHD 18) 0 req
20 NUT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 18) 0 req
20 NUT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 18) 0 req
21 4T7845121 KIT FIRST AND THIRD SEALING FOR RWM
SEAL FOR FRONT WINDOW (UPPER)
1 req Avail to order
Our Price: $507.67
21 4T7845121 KIT FIRST AND THIRD SEALING FOR RWM
SEAL FOR FRONT WINDOW (UPPER)
1 req Avail to order
Our Price: $507.67
22 SEAL (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
22 SEAL (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
23 SEAL (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
23 SEAL (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
24 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
24 BALL SCREW (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 21) 0 req
25 4T7853297 KIT CENTRAL SEALING FOR RWM
GASKETS (CENTRALE)
1 req Avail to order
Our Price: $672.92
25 4T7853297 KIT CENTRAL SEALING FOR RWM
GASKETS (CENTRALE)
1 req Avail to order
Our Price: $672.92
26 4T7898040 KIT LOCATION PARTS WITH FIXING
SEAT BACK TRIM (RIGHT)
1 req Avail to order
Our Price: $207.69
26 4T7898040 KIT LOCATION PARTS WITH FIXING
SEAT BACK TRIM (RIGHT)
1 req Avail to order
Our Price: $207.69
27 ARM (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
27 ARM (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
28 RETAINING BASE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
28 RETAINING BASE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
29 CUP WASHER (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
29 CUP WASHER (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
30 NUT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
30 NUT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
31 RETAINING BASE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
31 RETAINING BASE (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
32 PIN (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
32 PIN (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 26) 0 req
33 HEXAGON SOCKET HEAD BOLT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
33 HEXAGON SOCKET HEAD BOLT (CANNOT BE SOLD SEPARATELY INCLUDED IN REF.:- 7) 0 req
34 4T7998671B WIRE HARNESS CROSSBEAM
WIRING SET FOR ROOF CONSOLE
1 req Avail to order
Our Price: $410.90
34 4T7998671B WIRE HARNESS CROSSBEAM
WIRING SET FOR ROOF CONSOLE
1 req Avail to order
Our Price: $410.90
35 4T7998671 WIRE HARNESS ROOF CONTAINER
WIRING SET FOR ROOF CONSOLE
1 req Avail to order
Our Price: $555.31
35 4T7998671 WIRE HARNESS ROOF CONTAINER
WIRING SET FOR ROOF CONSOLE
1 req Avail to order
Our Price: $555.31

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
